16 4-Port Gigabit Ethernet Layer 3 Switching Module (GBIC) Quick Start Guide
Figure 2 illustrates installation in a 7-slot chassis.
Figure 2 Installing a 4-port Gigabit Ethernet Layer 3 Switching Module (GBIC)
into a 7-slot Chassis
4-Port Gigabit Ethernet
Layer 3 Switching Module
R
7
6
5
4
3
2
1
CoreBuilder 9000
9
8
Spring-loaded
screws
®
