2008-2014 Suzuki King Quad 750

I n s t a l l a t i o n I n s t r u c t i o n s

PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION

IFC20031.01

www.powercommander.com

2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com

Parts List

Power Commander FC

USB Cable

Installation Guide

Dynojet Decals

Velcro

Alcohol swab

THE IGNITION MUST BE TURNED

OFF BEFORE INSTALLATION!

YOU CAN ALSO DOWNLOAD THE PCFC

CONTROL CENTER SOFTWARE AND

LATEST MAPS FROM OUR WEB SITE AT:

www.powercommander.com

2008-2014 Suzuki King Quad 750 - 1

Table of Contents

Do you have a question about the Power Commander V and is the answer not in the manual?

Page 1 2008-2014 Suzuki King Quad 750 2008-2014 Suzuki King Quad 750 Installation Guide Dynojet Decals I n s t a l l a t i o n I n s t r u c t i o n s Velcro Alcohol swab...
Page 2 SELECTING THE MAP POSITION The Dynojet Power Commander Fuel Controller (PCFC) comes loaded with up to ten maps. Using a #1 Phillips screwdriver, turn the map select dial to toggle between the loaded maps. Refer to the map position table for the maps included in your PCFC.
Page 3 FIG.A Remove the seat. Remove the covers on the left hand side of the quad as shown in Figure A. FIG.B Using the supplied velcro, secure the PCFC under the seat as shown in Figure B. Make sure to clean both surfaces with the alcohol swab before attaching. FIG.C harness Route the PCFC harness to the left side of the quad and go through the hole...
Page 4 FIG.D Unplug the stock wiring harness from the fuel injector as shown in Figure D. Unplug the stock wiring harness from the Throttle Position Sensor (TPS) as shown in Figure D. FIG.E Attach the connectors from the PCFC to the stock wiring harness and injector as shown in Figure E.
