Immergas Victrix Pro 80 2ErP Instruction And Warning Book page 42

Victrix Pro 120 2ErP.
HEAT OUTPUT HEAT OUTPUT
(kW)
111.0
108.0
105.0
102.0
99.0
96.0
93.0
90.0
87.0
84.0
81.0
78.0
75.0
72.0
69.0
66.0
63.0
60.0
57.0
54.0
51.0
48.0
45.0
42.0
39.0
36.0
33.0
30.0
27.0
24.0
21.0
18.0
15.0
12.0
11.0
N.B.
- The power data provided in the table is ob-
tained with 0.5 m long intake/exhaust pipe.
- Gas flow rates refer to heating output below a
temperature of 15°C and pressure of 1013 mbar.
- Burner pressure values refer to use of gas at
15°C.
- The number of revs for the fan on the display
is expressed in revs / 50 (Ex.: 1000 revs = 20).
BURNER GAS FLOW
RATE
(kcal/h) (m /h)
3
95460 12.07
92880 11.74
90300 11.41
87720 11.08
85140 10.75
82560 10.42
79980 10.09
77400 9.76
74820 9.43
72240 9.10
69660 8.78
67080 8.45
64500 8.13
61920 7.80
59340 7.48
56760 7.15
54180 6.83
51600 6.51
49020 6.18
46440 5.86
43860 5.54
41280 5.21
38700 4.89
36120 4.57
33540 4.24
30960 3.92
28380 3.60
25800 3.27
23220 2.95
20640 2.62
18060 2.30
15480 1.97
12900 1.64
10320 1.32
9460 1.21
METHANE (G20)
REVS
FAN
(n°)
7000
6810
6620
6430
6240
6050
5870
5680
5500
5320
5140
4970
4790
4620
4440
4270
4100
3930
3760
3590
3430
3260
3100
2930
2770
2610
2450
2290
2130
1970
1820
1660
1510
1350
1300
42
PROPANE (G31)
BURNER GAS FLOW REVS
RATE FAN
(kg/h) (n°)
8.86 7000
8.62 6800
8.37 6600
8.13 6400
7.89 6200
7.65 6010
7.40 5810
7.16 5620
6.92 5440
6.68 5250
6.44 5070
6.20 4880
5.97 4700
5.73 4530
5.49 4350
5.25 4170
5.01 4000
4.78 3830
4.54 3660
4.30 3490
4.06 3330
3.83 3160
3.59 3000
3.35 2840
3.12 2680
2.88 2520
2.64 2360
2.40 2200
2.16 2050
1.92 1900
1.69 1750
1.45 1600
1.21 1450
0.97 1300
0.89 1250
