Cables
•
Motor Cable 1m (2) – Black cable with white, six-pin plugs. Use this cable to connect the Actuator to the Control Box.
•
Power Cable – Connects Control Box to power outlet. Three feet long.
•
RF Cable (only present if you ordered the RF version of the Lift System) – Use to connect the RF Receiver to the Control
Box. Ends have RJ-45 connectors. One-foot long.
Hardware
1. Four (4) – 3/8" x 3" Lag Screws w/Washers
2. Four (4) – #10 x 0.25" Phillips Screws
3. Four (4) – Zip Ties
4. Two (2) – Adhesive Rubber Bumpers
5. Four (4) – Lag Screw Covers
6. Four (4) – Lag Screw Cover Washers
7. Assorted TV Hardware
a. Four (4) – 6 x 20mm PHMS
b. Four (4) – 6 x 35mm PHMS
c. Four (4) – 8 x 20mm PHMS
d. Four (4) – 6 x 35mm PHMS
e. Four (4) – ¼" Plastic Spacers
f. Eight (8) – 1/8" Plastic Spacers
g. Four (4) – Steel M6 Washers
Parts List, continued
