Step 21: Partially fasten the Mount to the Wall using (4) Lag Bolts,
(4) Washers, and (4) Lag Bolt Cover Washers.
Step 22: Level the Mount off of the Screen Back Plate, ensure it is level relative to the mantel or floor, then
completely fasten Lag Bolts.
Important Note:
If the mount is unlevel, use the Slotted Holes for the Lag Bolts to adjust its position. If the
mount is still unlevel, the cutout may need to be expanded. Finer adjustments for the level of the TV can
be made separately and are covered later in Adjustments section of this Instruction Manual.
Step 23: Place the (4) Lag Bolt Covers over each Lag Bolt Cover Washer
when finished.
14
