Santa Fe Kitchen Cart with Metal Shelves
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Stock # SFKCWMS
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or e-mail your request to parts@whalenfurniture.com
Date 2016-01-07 Rev. 2 Factory: FOCIDI
1-866-942-5362
www.whalenstyle.com
LOT NUMBER:
DATE PURCHASED: /
/
Advertisement
Related Manuals for Whalen SFKCWMS
Summary of Contents for Whalen SFKCWMS
- Page 1 LOT NUMBER: DATE PURCHASED: / Santa Fe Kitchen Cart with Metal Shelves Stock # SFKCWMS ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Santa Fe Kitchen Cart with Metal Shelves (SFKCWMS) DATE OF MANUFACTURE: January 2016 MADE IN CHINA FITS UP TO MOST 55"...
- Page 3 Stock # SFKCWMS Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Section (1) B- Metal Shelf (2) C- Left Front / Right Back Leg (2)
- Page 4 Stock # SFKCWMS Assembly Instructions Drawer Handle with Bolts (2 used in this step) ⑥ 1. Unpack the unit and confirm that you have all the hardware and required parts. 2. Place the Top Section (A) on a level and protective surface.
- Page 5 Stock # SFKCWMS Assembly Instructions Flat Washer Lock Washer Ø1/4" x 1-1/4" Bolt (8 used in this step) (8 used in this step) (8 used in this step) ⑤ ④ ② 5. Align and attach four Legs (C and D) to the apron corners of the Top Section (A), using eight 1-1/4"...
- Page 6 Stock # SFKCWMS Assembly Instructions 3 4 5 Flat Washer Ø1/4" x 1-3/4" Bolt Lock Washer (4 used in this step) (4 used in this step) (4 used in this step) ⑤ ③ ④ 6. Attach the Side Handles (E) to the side panels of the Top Section (A) with four 1-3/4" Bolts (3) and four Washers (4 and 5).
- Page 7 Stock # SFKCWMS Assembly Instructions Ø1/4" x 5/8" Bolt (8 used in this step) ① 7. Fasten the Metal Bars (F) between the Legs (C and D) with eight 5/8" Bolts (1). 1-866-942-5362 Please call for replacement parts or assistance:...
- Page 8 Stock # SFKCWMS Assembly Instructions 8. Securely screw the Casters (G and H) to the bottom of Legs (C and D) with the enclosed open wrench. Make sure that two Locking Casters (G) are located at the same short end.
- Page 9 Stock # SFKCWMS Assembly Instructions Ø1/4" x 5/8" Bolt Flat Washer Lock Washer (8 used in this step) (8 used in this step) (8 used in this step) ① ⑤ ④ 9. Flip the assembled unit at its back edges. Fit the Metal Shelves (B) between the Legs (C and D) making sure the metal tabs overlap the threaded inserts on Legs (C and D).
- Page 10 Stock # SFKCWMS Assembly Instructions 12. Ask for assistance to stand the assembled unit upright. 13. Now, insert the removed drawers into the Top Section (A) to finish the assembly. To place the drawer back, simply push the ball bearing cart all the way to the end of the slides (on both sides), and align the slide runners on the drawer with the slides track on the unit.
- Page 11 Stock # SFKCWMS Assembly Instructions NOTE: You must install the Strip Stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 14. Remove the paper backing of Stop Rail (I), then properly align the Stop Rail with the top edge of the stopper template on Top Panel (A).
-
Page 12: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
