Santa Fe Kitchen Cart with Wine Rack
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Stock # SFKCWWR
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenstyle.com
Or e-mail your request to parts@whalenfurniture.com
Date 2016-01-07 Rev. 2 Factory: FOCIDI
LOT NUMBER:
DATE PURCHASED: /
/
Advertisement
Related Manuals for Whalen SFKCWWR
Summary of Contents for Whalen SFKCWWR
- Page 1 LOT NUMBER: DATE PURCHASED: / Santa Fe Kitchen Cart with Wine Rack Stock # SFKCWWR ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Santa Fe Kitchen Cart with Wine Rack (SFKCWWR) DATE OF MANUFACTURE: January 2016 MADE IN CHINA FITS UP TO MOST 55"...
- Page 3 Stock # SFKCWWR Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (1) B- Middle Shelf (2) C- Bottom Shelf with Wine Bottle Holder (1)
- Page 4 Stock # SFKCWWR Assembly Instructions Ø1/4" x 3/4" Bolt (8 used in this step) ① NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier.
- Page 5 Stock # SFKCWWR Assembly Instructions Ø1/4" x 1-1/2" Bolt (2 used in this step) ② 4. Attach the Bottom Stretcher (E) between the bottom rails of both Side Frames (D) with two 1-1/2” Bolts (2). Tighten the bolts with the enclosed Allen wrench. As shown.
- Page 6 Stock # SFKCWWR Assembly Instructions 5. Flip over the assembled unit at its long edge. 6. Depend on the desired configuration, insert and fit the Bottom Shelf (C) onto the bottom rails of both Side Frames (D) making sure the threaded inserts on Bottom Shelf align with the drilled holes on Side Frames properly.
- Page 7 Stock # SFKCWWR Assembly Instructions Ø1/4" x 1-1/2" Bolt (4 used in this step) ② 7. Fasten the Bottom Shelf (C) to the bottom rails of both Side Frames (D) with four 1-1/2" Bolts (2). 1-866-942-5362 Please call for replacement parts or assistance:...
- Page 8 Stock # SFKCWWR Assembly Instructions Ø1/4" x 1-1/2" Bolt (8 used in this step) ② 8. Repeat the same procedure to attach the Middle Shelves (B) to the middle rails of Side Frames (D). 9. Ask for assistance to stand the assembled unit upright.
- Page 9 Stock # SFKCWWR Assembly Instructions NOTE: You must install the Strip Stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 10. Remove the paper backing of Stop Rail (F), then properly align the Stop Rail with the top edge of the stopper template on Top Panel (A).
-
Page 10: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
