CHIEF QMP1T Installation Instructions Manual

Music stand table top

Advertisement

Quick Links

I N S T A L L A T I O N I N S T R U C T I O N S
Music Stand Table Top
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
QMP1T

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QMP1T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CHIEF QMP1T

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Music Stand Table Top Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description QMP1T...
  • Page 2: Important Safety Instructions

    ACCESSORY: AN ACCESSORY is the secondary Chief this accessory to support video equipment such as product which is attached to a primary Chief product, and may televisions or computer monitors. have a component attached or setting on it. IMPORTANT ! :...
  • Page 3: Installation Instructions

    Installation Instructions QMP1T DIMENSIONS DIMENSIONS: INCHES LEGEND Tighten Fastener Open-Ended Wrench Apretar elemento de fijación Llave de boca Befestigungsteil festziehen Gabelschlüssel Apertar fixador Chave de bocas Serrare il fissaggio Chiave a punte aperte Bevestiging vastdraaien Steeksleutel Serrez les fixations Clé à fourche...
  • Page 4: Tools Required For Installation

    QMP1T Installation Instructions TOOLS REQUIRED FOR INSTALLATION 5/32" (included) 3/8" 3/8" 1/8" (included) PARTS B (1) [Attachment plate] C (1) [Table bracket] A (1) [Table brace] D (1) [Table top] E (2) F (2) L (6) K (1) [Array clamp, outer]...
  • Page 5 Installation Instructions QMP1T ASSEMBLY Fasten the table top (D) to the table bracket assembly using six #10 x 5/8" Phillips wood screws (M) and six #10 washers (P) into the pre-drilled holes. (See Figure 3) Attach table bracket (C) to attachment plate (B) by inserting stud fastener on attachment plate through upper hole in table bracket, and use one 10-24 x 1/2"...
  • Page 6: Cable Management

    QMP1T Installation Instructions Cable Management NOTE: There are four cable tie holes in the table bracket. Cable ties (Q) may be added for cable management of keyboard cables, mouse cables and other miscellaneous cables. (See Figure 5) Table top Cable tie holes...
  • Page 7 Installation Instructions QMP1T...
  • Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
