CHIEF CM2C40 Specifications

automated mounts
cm2c40
3
1
WHAT YOU nEED TO KnOW
multIple contRol optIons
AMX/Crestron control compatibility
VoltaGe optIons
120V or 230V (for 230V order the CM2C40I)
flexIble InstallatIon
no width constraints
sHIps fullY assembled
RECOMMEnDED ACCEssORIEs
paclR1
paccc1
For a complete list of automated mount accessories see page 81.
CliCk
80
www.chiefmfg.com
32 - 61" ceiling lift
5
2
4
side speaker Adapter
n
Center Channel
n
speaker Adapter
FEATUREs
AutoDrivE
1
ultra fast and quiet travel at over 2" (51 mm)
per second with preset viewing position.
tElEsCoPing DEsign
2
collapses to a stored height of 31" (790 mm)
with approximately 40" (101.6 cm) of travel.
MultiPlE Control oPtions
3
control options include: serial communication,
dry contact control, and ir remote (included).
Q-lAtCh
4
flat panel secures to mount with a latching
flag. easy to connect/disconnect – no tools
needed!
CAblE MAnAgEMEnt
5
unique cable management system allows
cables to move freely with the lift.
sPECIFICATIOns
Extension
Weight Capacity
Color
TECHnICAL DRAWInGs
19"
(483 mm)
19.25"
(489 mm)
23.75"
(603 mm)
CAll
800.582.6480
systEM
™
™ Mounting systEM
31-71" (79-180 cm)
170 lbs (77.1 kg)
Black
7.75"
(197 mm)
28.38"
(721 mm)
Approx.
40" (102 cm)
of travel
2.5"
(64 mm)
(83 mm)
FAX
877.894.6918
3.26"
