RB-LCD10-2
10,1"-Touchscreen Display Manual
1. GENERAL INFORMATION
Dear customer,
thank you very much for choosing our product. In fol-
lowing, we will introduce you to what to observe while
starting up and using this product.
Should you encounter any unexpected problems dur-
ing use, please do not hesitate to contact us.
Advertisement
Related Manuals for Joy-it RB-LCD10-2
Summary of Contents for Joy-it RB-LCD10-2
- Page 1 RB-LCD10-2 10,1"-Touchscreen Display Manual 1. GENERAL INFORMATION Dear customer, thank you very much for choosing our product. In fol- lowing, we will introduce you to what to observe while starting up and using this product. Should you encounter any unexpected problems dur-...
- Page 2 2. ASSEMBLY OF DISPLAY 2.1 Assembly of the Display Take out the display, the foot and the socket neck from the package. Insert the metallic rectangle of the socket neck into the matching conduction on the display case (near the USB imprint). Fixate the socket neck by tightening the round washer, which is located directly in front of the metallic rectan- gle.
- Page 3 2.2 Assembly of a Raspberry Pi If you wish to operate the display with a Raspberry Pi , you can use the mounting platform provided for this purpose. Remove the provided mounting platform and attach your Raspberry Pi onto it. After you have fixated your Raspberry Pi, place the mounting plate on the back of the display and mount it to it (screw holes 9 - Vesa).
- Page 4 Connection to a device First, plug the power supply into the display. Then, con- nect the display with the device, which should be used, using the HDMI cable. To use the Touch functions as well, the display must also be connected with the device to be used with the pro- vided USB cable.
- Page 5 Install the LCD image on your SD card with the help of „Win32 Disk Imager“-program, which you can find as preinstalled Raspbian system for your Raspberry Pi as download by the following link: https://joy-it.net/de/products/RB-LCD10-2 1. Choose Image 2. Choose Device 3. Write SD card with image 3.2 Manual Installation &...
- Page 6 following command: Below the Point [pi4], you have to comment out fol- lowing command: dtoverlay=vc4-fkms-v3d. This should look like the following: [pi4] # Enable DRM VC4 V3D driver on top of the dispmanx display stack <- This setting has to be commented out #dtoverlay=vc4-fkms-v3d with #...
- Page 7 In order to display the image correctly when the display is started with the Raspberry Pi, the „config.txt“-file has to be edited first. Open it with the following command: sudo nano /boot/config.txt Now enter the following lines at the end of the file. Afterwards, you can save the file using the key combina- tion CTRL+O and exit the file with the combination CTRL+X.
- Page 8 Then restart your Raspberry Pi: sudo reboot Before your can start the calibration tool, you have to create the file for the calibration settings (please write the command in one line !): sudo nano /usr/share/X11/xorg.conf.d/99- calibration.conf Now enter the following settings in this file: Section "InputClass"...
- Page 9 the previously created file „99-calibration.conf“. For this, please enter the following command (in one line): sudo nano /usr/share/X11/xorg.conf.d/99- calibration.conf Enter the following content here and amend the four values of the "calibration" option with those, which have been outputted to you in the previous step: Section "InputClass"...
- Page 10 3.3 Usage with a desktop PC Connect the display with the provided power supply. Then, connect your computer with the display, using an HDMI– or VGA-cable, depending on your preference. You can further connect your computer with the Touch interface using the USB cable, if the operation via Touchscreen is desired.
- Page 11 Afterwards, choose the tab "Display" :...
- Page 12 Now activate the multiple monitor function: After activation, you will be prompter to perform anoth- er calibration. If this does not take place automatically, please proceed as follows:...
- Page 13 Select the Tab "Tools" :...
- Page 14 Now please click on 4-Point-Calibration, to perform a new calibration: If there is a problem arising with the detection of the USB- touch screen drivers, the eGalax Touch driver must be uninstalled and reinstalled. During the installation, make sure that you have the USB cable connected with the computer and the Touch interface of the display.
-
Page 15: Additional Information
We will send you a parcel stamp with which you can send us your old device free of charge. For using this, please contact us via e-mail at pickup@joy-it.net or via tele- phone at 02845 93 60 -23. Information on packaging: Please pack your old device safe for transport. - Page 16 We support you after purchase, of course. Should you have any outstanding questions or problems, please contact us via e-mail, telephone and ticket-support- system. E-mail: service@joy-it.net Ticket-System: http://support.joy-it.net Telephone: +49 (0)2845 98469 – 66 (10 - 17 o'clock) For further information, please visit our website: www.joy-it.net...
