Planet MCU-1400 Quick Manual

VERIFY THE CONTENTS INSIDE PACKAGE BOX
The package box should contain the items indicated below plus MCU-1400/1900. If any item is missing or damaged, please contact the seller immediately
Quick Installation Guide
STEP 1: Fasten 4 screws (2 on each side) to attach the rails
onto the chassis
STEP 3: Hold the system firmly and fasten the system
to the rack
Note: Make sure that you hold the system firmly while
fastening the system to the rack
STEP 5: Fasten the L-shape bracket to the rack

Quick Guide

CD-ROM Rail x 2 L-shape bracket x 2
STEP 2: Mount the system onto the rack
Note: Be careful to avoid unit drop and get hurt
in installation
STEP 4: Mount the L-shape bracket onto the rail
in the back of the system
STEP 6: Fasten the L-shape bracket to the rail
Note: Follow the above procedures in reverse order to
dismount the system from the rack if necessary
MCU-1400/1900
Power cord
