CEAG Style 21011 LED CG-S
Montage- und Betriebsanleitung CEAG Style 21011 LED CG-S
Mounting and Operating Instructions CEAG Style 21011 LED CG-S
Zielgruppe: Elektrofachkraft
Target group: Skilled electricians
Verwendungszweck: nicht für Allgemeinbeleuchtung in privaten Haushalten
Intended Application: not suitable for general lighting in private households

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CEAG Style 21011 LED CG-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eaton CEAG Style 21011 LED CG-S

  • Page 1 CEAG Style 21011 LED CG-S Montage- und Betriebsanleitung CEAG Style 21011 LED CG-S Mounting and Operating Instructions CEAG Style 21011 LED CG-S Zielgruppe: Elektrofachkraft Target group: Skilled electricians Verwendungszweck: nicht für Allgemeinbeleuchtung in privaten Haushalten Intended Application: not suitable for general lighting in private households...
  • Page 2 CEAG Style 21011 LED CG-S Inhalt 1. Sicherheitshinweise/Normenkonformität . . . 4 2. Aufbau und Maßbilder ....5 3. Kurzbeschreibung/Verwendungsbereich . . . 7 4.
  • Page 3 SICherheITShInweISe SAFeTy InSTrUCTIOnS • Die Leuchte ist bestim mungs gemäß in • The device shall only be used for its unbeschädigtem und einwandfreiem Zu- intended purpose and in undamaged stand zu betreiben! and flawless condition • Als ersatz dürfen nur Originalteile von • Only genuine CeAG spare parts may be CeAG verwendet werden! used for replacement and repair...
  • Page 4 2. Aufbau der Leuchte 2. Structure of luminaire IP54 Abdeckhaube IP54 cover Öffnung für Führungsstift Hole for guide pin Leuchtenkörper Body of luminaire Führungsstift Guide pin Schnellmontagesatz Quick mounting plate Abstandselemente Die 3 beiliegenden Abstandhalter sind zu verwenden Spacer The 3 enclosed spacers have to be used nicht in das Leuchtmittel schauen Do not stare at the light source...
  • Page 5 Kurzbeschreibung/ 3. Brief description/ Verwendungsbereich Scope of application Sicher heitsleuchten für den Betrieb an CEAG Safety luminaire, suitable for operation in CEAG Sicherheitsbeleuchtungsanlagen mit Einzelleuch- safety lighting systems with single luminaire tenüberwachung (Cewa-Guard-Technologie) und/ monitoring (Cewa-Guard-Technology) and/or with oder mit programmierbarer Schaltbarkeit im End- programmable switching mode in the outgoing stromkreis (STAR-Technologie) geeignet.
  • Page 6 4.1 Montage 4.1 Mounting • Zur Montage der Leuchte die Öffnung im Leuch- • In order to install the luminaire, the opening in tenkörper auf den Führungsstift des Schnellmon- the body of the luminaire is placed on the guide tagesatzes aufsetzen pin of the quick mounting plate • Alle vier Ecken am unteren Teil des Leuchten- • All four corners of the body of the luminaire are...
  • Page 7 5. Technische Daten 5. Technical Data Anschlussspannung 220 - 240 V AC, 50/60 Hz, 176 - 275 V DC Power input Gehäusematerial Polycarbonat (850°C glühdrahtbeständig) Housing material Polycarbonat (850°C glow wire resistant) Gehäusefarbe grau RAL 7035 Housing colour grey RAL 7035 0,5 W (230 V / 50 Hz) Standby Verlustleistung / Standby power loss Lichtstrom phiE/phiNenn am...
  • Page 8 Eatons Ziel ist es, zuverlässige, effiziente und sichere Stromversorgung dann zu bieten, wenn sie am meisten benötigt wird. Die Experten von Eaton verfügen über ein umfassendes Fachwissen im Bereich Energiemanagement in verschiedensten Branchen und sorgen so für kundens- pezifische, integrierte Lösungen, um anspruchsvollste Anforderungen der Kunden zu erfüllen.
