Summary of Contents for Eaton iCube

  • Page 2 OBLIGATION OF EATON. THE CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or other-wise for any special, indirect, incidental or consequential...
  • Page 3 About this manual Thank you for choosing Eaton iCube micro data center (MDC). This user manual introduces how to install the MDC cabinets, components, and cooling units and how to control the MDC using the web UI. Commissioning and troubleshooting information is also provided.

  • Page 4: Table Of Contents

    Install the integrated cooling unit ...................... 37 5.2.1 Connect the drainpipe .......................... 37 5.2.2 Charge the refrigerant .......................... 37 5.2.3 Connect the soft air duct or air chimney ....................40 Install split cooling units ........................42 EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 5 View PDM details and control PDM ....................75 7.7.1 Check PDM topology ..........................75 7.7.2 Set the PDM address ........................... 75 7.7.3 View real-time PDM data ........................76 7.7.4 View PDM information .......................... 76 EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 6 7.16 Shut down the MDC ........................104 7.17 Restart the MDC ..........................105 7.18 Modify password ..........................106 7.19 Set system time ..........................107 7.20 Set automatic logout interval ......................108 7.21 Set screen off interval ........................109 EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 7 Appendix A Turn on the cooling unit with a manual operator ..............127 Turn on the integrated cooling unit with a manual operator ............127 Turn on the split cooling unit with a manual operator ..............128 Appendix B Acronyms and abbreviations ....................130 EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 9: Safety Precautions

    • This product is recommended for commercial or other professional use. • This product is to be used for its design purposes only and Eaton will not accept any responsibility of misuse. • The areas inside the product cabinet are restricted areas. Eaton recommends that access to restricted areas be given to authorized employees only.
  • Page 10 Potential risks Operate the product only after disconnecting it from all power sources. • Before opening internal components for maintenance, disconnect the mains switch and all power • supplies to the UPS. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 11: Product Overview

    • Quick cabinet deployment and flexible configurations Eaton iCube is designed for use in environment requiring micro data centers, computers, or server rooms for small and medium businesses and branch offices. It comes with a choice of single cabinet and row or multiple cabinet system. All devices that meet EIA-310-D standards can be installed in the cabinet.

  • Page 12: Model Number Definition

    Model number definition EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 13: System Assembly

    4 x C19 (1PCS) EM3MS10K8S *7 kW 9PX11KiP E08SE/ PDM-10K Basic type IEC32A-20x C13, EW10E 4 x C19 (5PCS) EM5MS20K8S(2) *14 kW 9SX20KP E08SE/ PDM-20K Basic type IEC32A-20x C13, EW10E *2 4 x C19 (9PCS) EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 14 30° C to 40° C. When using three-phase power, pay attention to the principle of equal load distribution of each phase and try to distribute the load evenly in each cabinet. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 15: System Specifications

    Power distribution unit (PDU) Monitored and managed PDU as an option 0U monitoring module integrating user screen - single Control monitoring server cabinet/row cabinet Monitoring subsystem Web page (Google Chrome recommended) Remote monitoring Mobile APP (Android only) EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 16 An emergency gravity drain is provided to prevent overflow alarms. Gravity drainage can be performed by manually opening the manual water valve of the cooling unit. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 17 Temperature and humidity of 3.5 kW integrated cooling unit (with self-evaporative kit) EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 18: System Electrical Diagram

    Two spare terminals, one for mains backup circuit and one for UPS backup circuit, are available to meet additional customer requirements. To connect the spare terminals, connect the wires from the back end of the power distribution module (PDM). Spare terminals EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 19: Monitoring System

    Monitoring system Monitor circuit EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 20: Environment Requirements

    -25º C to +55º C (battery excluded) Storage environment Indoor/clean (no dust, etc.) Operating temperature 0º C to 40º C Ambient humidity 5%RH to 95% RH (no condensation) ≤ 3000 m (consult us for usage over 1000 m) Altitude EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 21: Installation Preparation

    Antistatic gloves Insulation tape Multimeter Electroprobe Used for protection Used for protection Used for insulation tape Used to test circuits Used to test circuits when assembling when installing the when connecting wires components cooler EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 22: Package

    1008 46.5 Accessory kits are listed as below. No. Name Unit Remarks Accessory kit Including battery cables, installation screws, and cable ties Upper cable tray 1 One set per cabinet (applicable for row cabinets) EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 23: Transportation And Unpacking

    Step 4 Close the front and rear doors. Slowly push the cabinet down along the pallet It is recommended that at least two operators perform this step to ensure safety. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 24 —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 25: Requirements About Installation Site

    See the bottom dimensions of the MDC cabinet in the following figures. (unit: mm) Bottom of a 42U 600 mm cabinet Bottom of a 42U 800 mm cabinet (unit: mm) Bottom of a row (multiple) cabinet system EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 26 (unit: mm) Installation site planning diagram (top view) (unit: mm) Installation site planning diagram (side view) EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 27: Cabinet Installation And Electrical Wiring

    Place the main cabinet and IT cabinets in order according to the number marked on the lower right of the front cabinet door. Secure and fix adjacent cabinets with cabinet screws and rivets (6 pieces per adjacent cabinet). Connect the ground wires of two adjacent cabinets. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 28 Step 3 Install the top cable trays. Step 4 Install the side panel, removed in step 1, on the end cabinet. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 29: Connect Components And Cables

    #2 IT cabinet, the same for #3 IT cabinet and so forth. Follow this principle to connect all the PDUs to the terminal blocks. Note that cables must be connected between the same labels (L→L, N→N, PE→PE). EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 30: Connect Power Cords To Cooling Units

    Connect the network cable (labeled with AC PORT) left on the top of cooling unit cabinet 1 to the PORT1 port at the rear of cooling unit 2 and so forth for the remaining cabinets, as shown in the following figure. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 31 Connect the network cable (labeled with PLAN identifier) left on the top of cooling unit cabinet 1 to the PLAN port at the rear of cooling unit 2, and so forth for the remaining cabinets, as shown in the following figure. Group control communication wires are as follows: EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 32: Connect And Configure Electronic Locks

    Address settings for other cabinets (thee/five cabinets) are similar. Address/Location No. 1 No. 2 No. 3 No. 4 No. 5 No. 6 Address No. 0 Address No. 1 Address No. 2 Address No. 3 Address No. 4 EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 33: Connect And Configure Temperature And Humidity Sensors

    Connect and configure temperature and humidity sensors To connect temperature and humidity sensors: Step 1 Connect the cable (labeled with T/H2) left on the top of cabinet 1 to the T/H2 IN port in front of the cabinet 2. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 34 Address No. 3 Address No. 4 Address No. 5 Address No. 6 Address No. 7 Address No. 8 Address No. 9 Address No. 10 The following figure shows an example with the address set to 2. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 35: Connect Smoke Sensors

    (labeled with Smoke sensor 1) left on the top of cabinet 5 to it, as shown in the following figure. 4.2.7 Connect the lighting system Connect ambient lighting cables on the top of two adjacent cabinets. The following figure shows the four-core ambient lighting cables with plug-in terminals. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 36: Connect A Fire Extinguishing Module (Optional)

    4.2.8.2 Connect cables to the fire extinguishing module Step 1 Install the fire extinguishing module on the cabinet top. Step 2 Connect the RJ45 interface of a cable to the RJ45 port at the back of the fire extinguishing module. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 37: Connect External Cables

    PDM. To connect with PDM, the input cables must be configured with OT terminals as shown in the figures below. OT terminals are available in the accessory kit provided by Eaton, or you can use your own. For single cabinets equipped with 3.5 kW integrated cooling unit, one extended cable with red terminals for easy connection with utility power is provided on the PDM.
  • Page 38 21 kW 100A/3P RVV5*25 mm² /AWG4# The MDC provides an RJ45 northbound port on the top of the cabinet. You can use a standard network cable to connect it to your local area network (LAN). EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 39: Link Fire Alarms

    12 V active dry contact signals can be used as the smoke-sensing signals. Wiring method: Connect 4-core signal cables to contacts 1/2/3/4 of smoke sensor (contacts 1/2 are for 12 VDC power supply, and contacts 3/4 are for alarm output). EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 40: Installation Of Cooling Units

    Used to vacuumize during Vacuum cooling and solenoid check valve installation and pump split cooling maintenance. Absolute pressure of units 12 Pa For integrated Philips cooling and —— —— screwdriver split cooling units EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 41 (bell mouth) valve. Copper pipe Used to expand the flare to expander Pipe expansion for For split connect the refrigerant (copper pipe cup mouth cooling units pipes. connection) EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 42 Used for leveling during For split —— Spirit level installation. cooling units Crimping Used to crimp OT and For split —— tool tubular terminals. cooling units EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 43 – Use other methods as required Power cord to connect the 3x2.5 mm For split cooling units indoor and outdoor units Signal lines to connect the 2x1.5 mm For split cooling units indoor and outdoor units EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 44 – For split cooling units Oil trap 5.3.3 Connect pipes. – When the outdoor unit is higher than the indoor unit by more than 6m, install an oil trap every 6m to 7.5m. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 45: Install The Integrated Cooling Unit

    See the steps below: Step 1 Use a Phillips screwdriver to remove the three screws at the rear filter of the unit, remove the cover panel, and take out the air filter. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 46 The high-pressure gauge should be connected to the high-pressure needle valve, and the low-pressure gauge should be connected to the low-pressure needle valve. Connect the red pipe to the high-pressure gauge and blue pipe to the low-pressure gauge. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 47 Step 5 Tighten the pressure gauge connection, and open the high- and low-pressure valves. After the pipeline is emptied, the refrigerant is charged. Wait until the charging completes. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 48: Connect The Soft Air Duct Or Air Chimney

    The following figure shows the connection. Or you can use a sheet metal air chimney (optional kit 760-16038) as below to vent the hot air directly to the top ceiling, which is more aesthetic and suitable for computer room. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 49 You can also connect the air chimney with the soft air duct by using a square to round pipe adapter, as shown below. Note It is recommended that the hot air be exhausted outside, otherwise the indoor temperature will gradually rise and the cooling capacity of cooling unit will be derated. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 50: Install Split Cooling Units

    The distance between the holes of left and right brackets must be consistent with that between the holes in the cooling unit base. The following figures shows the dimensions of the cooling outdoor units. • EW06E (unit: mm) Front view Side view EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 51 Step 1 Fix the left bracket with one M10x100 (or bigger) expansion screw. Step 2 Use a spirit level to locate the position of the right bracket horizontally and fix bolts on the right bracket. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 52: Connect Pipes

    5 mm per 1m). When the outdoor unit is lower than the indoor unit, the liquid pipe is drawn out from the outdoor unit and slopes downward, and its inclination is the same as that of the gas pipe. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 53 Release nitrogen from the indoor unit before connecting. If there is no nitrogen discharged, contact our customer service. – Prepare the copper tubes used to connect indoor and outdoor units. The copper tubes must be clean, free of impurities and moisture. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 54 E08SE Pipe length D (mm) L (mm) D (mm) L (mm) 9.52 12.7 9.52 12.7 9.52 15.88 9.52 12.7 9.52 15.88 12.7 12.7 9.52 15.88 12.7 12.7 9.52 15.88 12.7 12.7 9.52 15.88 12.7 EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 55 Step 1 Use a wrench to unscrew the large and small valve nuts. Step 2 Align the copper pipe flare with the center of the globe valve. Step 3 Screw the tube nut by hand until it cannot be turned, then tighten it with a wrench. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 56 • After insulating the copper pipe, secure it to the square hole on the cabinet using cable ties. Top piping Bottom piping EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 57 • After insulating copper pipes, secure it to the square hole on the cabinet using cable ties. Top piping Bottom piping EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 58: Electrical Connection

    The indoor unit is equipped with power terminals as shown in the following figure. XT1 is connected to the main power supply of the unit. XT2-L, N and PE are connected to the outdoor power supply, and XT2-A+ and B- are connected to the outdoor unit communication cable. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 59 The following table lists the recommended cable for connecting the outdoor unit. Model Maximum operating current Recommended specification of power and communication cables EW06E 7.99 A 3x2.5 mm + 2x1.5 mm EW10E 13.8 A 4x2.5 mm + 2x1.5 mm EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 60: Connect The Drainpipe

    Step 3 Close and open the vacuum pressure gauge for several times and check that the pointer of the pressure gauge and sound of vacuum pump do not change a lot. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 61 3L vacuum pump to meet the requirement. This duration is obtained based on previous experiments. If you use a vacuum pump lower than 3L, extend the vacuumizing time appropriately. Needle valves of E04SE EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 62: Charge Refrigerant

    If the pipe connecting indoor and outdoor units is longer than 10 m, additional refrigerant needs to be charged. R410A refrigerant charge within 10m pipe length Type R410A refrigerant (kg) Remarks E04SE+EW06E Charged on site E08SE+EW10E EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 63: Install Low-Temperature Components (Optional)

    The low-temperature components are applicable in the ambient temperature of -40℃ to +45℃. The following figures show a low-temperature component for example. The actual component may be different. Low-temperature component outline (unit: mm) EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 64 0.5m to 2m. The bottom of the low-temperature component should be at the same height as that of the outdoor unit or slightly lower than that of the outdoor unit. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 65 EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 66 When a one-way valve is added to the pipeline, it is necessary to vacuumize the pipes in the front and back of the one-way valve. The globe valve of the indoor unit must be opened during vacuumizing. Rack-mounting cooling unit E04SE Rack-mounting cooling unit E08SE EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 67 Rack-mounted cooling unit E08SE: unit charging capacity without low-temperature components + 2.5 kg 5.3.8.6 Calculate refrigeration oil amount The amount of refrigeration oil to be added can be calculated using the following table: Model Refrigeration oil E04SE+EW06E 200 mL E08SE+EW10E 250 mL EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 68: Operation And Commissioning

    Step 4 Use a clamp ammeter to measure the running current of the integrated cooling unit or split outdoor unit. The running current must be lower than the rated current. For the split cooling unit, check that the outdoor unit is free from abnormal noise and vibration. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 69: Test Record And Form

    (affected by temperature of indoor unit temperature environment) (affected by load) Remarks Generally, the temperature difference between inlet and outlet air of the indoor unit/integrated cooling unit is about 15℃ when it is fully loaded. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 70: Turn On/Off The Mdc

    Check that the power and communication cables to outdoor unit/indoor unit/integrated cooling unit are properly connected. • For the outdoor unit, check that it is fixed in place, and there are no obstructions affecting its ventilation. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 71: Turn On The Mdc

    Turn on the MDC CAUTION Installation or commissioning of the MDC must be performed by Eaton’s customer service engineers or authorized Eaton specialists. To turn on the MDC: Step 1 Switch on the system main input. Step 2 Switch on the UPS input circuit breaker on the PDM.

  • Page 72: Turn Off The Mdc

    Step 3 Turn off the UPS switch and disconnect the UPS’s input and output switches on the PDM. Turn off the battery switch. Step 4 Disconnect the main switch controlling the system input. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 73: General Operations On The Hmi Or Computer

    User interface overview The following figure shows the overview of the user interface. * indicates that the menu can be accessed only by authorized accounts. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 74: Log In To/Log Out Of The Mdc System

    You will be required to change the default password when you log in to the MDC system for the first time. If you forget your password, contact Eaton’s service personnel. 7.2.2 Log in to the MDC through a computer (wireless connection) Step 1 Obtain the IP address that will be used for the MDC in the LAN.
  • Page 75 MDC system for the first time. – If you forget your password, contact Eaton’s service personnel. – If you cannot select I agree to all license terms and conditions of this user agreement upon your first login, scroll down to finish reading the agreement and zoom out the screen.

  • Page 76: Log In To The Mdc Through A Computer (Wired Connection)

    MDC system for the first time. – If you forget your password, contact Eaton’s service personnel. – If you cannot select I agree to all license terms and conditions of this user agreement upon your first login, scroll down to finish reading the agreement and zoom out the screen.

  • Page 77: Change Ip Address Of The System

    Step 3 Tap IP config, enter the IP address and gateway, and then tap Modify. Wait for about 10 seconds for the configuration to take effect. Step 4 Shut down and restart the monitoring server. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 78: Set Wireless Parameters

    Refer to section 7.2 to log in to the system. Step 2 Tap Setting in the left menu bar and then tap Network, as shown below. Step 3 Tap Wireless, and set parameters as required. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 79: View System Information

    When the status column is displayed in orange, at least one common alarm is generated. When the status column is displayed in red, at least one critical alarm is generated. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 80: View Ups Details And Control Ups

    Refer to section 7.2 to log in to the system, and tap UPS in the bottom menu. Step 1 Step 2 Tap Details in the lower right corner of the page. Step 3 Tap EPO under Control. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 81: View Real-Time Ups Data

    Step 2 Tap Details in the lower right corner of the page. Step 3 Scroll down to locate the Device Info module. Note The device information may vary with the presettings. The following figure shows an example. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 82: Perform Inspection On The Ups

    Refer to section 7.2 to log in to the system, and tap UPS in the bottom menu. Step 2 Tap Details in the lower right corner of the page. Step 3 Scroll down to locate the Alarm module. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 83: View Pdm Details And Control Pdm

    Power in the bottom menu. Step 2 Tap Details in the lower right corner of the page. Step 3 Tap Address setting under Control, set an address value, and tap Send. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 84: View Real-Time Pdm Data

    Step 2 Tap Details in the lower right corner of the page. Step 3 Scroll down to locate the Device Info module. Note The device information may vary with the presettings. The following figure shows an example. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 85: View Pdm Alarms

    Refer to section 7.2 to log in to the system, and tap Power in the bottom menu. Step 2 Tap Details in the lower right corner of the page. Step 3 Scroll down to locate the Alarm module. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 86: View Cooling Unit Details And Control The Cooling Unit

    By default, the return air mode is used. If you want to enable the supply air mode, following the steps below. The default mode is recommended. Step 1 Refer to section 7.2 to log in to the system, and tap A/C in the bottom menu. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 87: Set Temperature

    Step 2 Tap Details in the lower right corner of the page. Step 3 In the Control module, tap A/C address setting. Step 4 Set a value in the range of 1 to 255 and tap Send. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 88: View Real-Time Data Of Cooling Unit

    Step 2 Tap Details in the lower right corner of the page. Step 3 Scroll down to locate the Device Info module. Note The device information may vary with the presettings. The following figure shows an example. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 89: Perform Inspection On The Cooling Unit

    Refer to section 7.2 to log in to the system, and tap A/C in the bottom menu. Step 1 Step 2 Tap Details in the lower right corner of the page. Step 3 Scroll down to locate the Alarm module. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 90: View Environment Details

    Step 1 Step 2 Tap Details in the lower right corner of the page. Now you can see the real-time data of ambient lights under Real-time Data. The following figure shows an example. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 91: View Environment Alarms

    Refer to section 7.2 to log in to the system, and tap Environment in the bottom menu. Step 2 Tap Details in the lower right corner of the page. Step 3 Scroll down to locate the Alarm module. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 92: View Door Lock Details And Control Door Locks

    Refer to section 7.2 to log in to the system, and tap Door in the bottom menu. Step 1 Step 2 Tap Details in the lower right corner of the page. Step 3 Scroll down to locate the Alarm module. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 93: View And Export Current Alarms

    By default, all levels of alarms are displayed on this page. You can select Notification, Warning Alarms, Critical Alarms, and Fault to view alarms by level. If you log in to the system using a computer, you can click Export to download the displayed alarms. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 94: View And Export Historical Alarms

    7.12.2 View and export historical alarm report To view historical alarm report, refer to section 7.2 to log in to the system, tap History in the left menu bar, and select the Historical Alarm Report tab, as shown below. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 95: View And Export Historical Signal Report

    Historical Signal Report tab, and set filters as required. The following table describes the filters available on this page. Filter Description Specifies the time when the signals were generated. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 96 – Daily Average: Average data on each day is displayed. If you log in to the system using a computer, you can click Export to download displayed alarms as an Excel file. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 97: Manage Accounts

    Step 2 Tap Setting in the left menu bar and then tap Authority Management. Step 3 Tap Add Account. Step 4 Enter the account name and password, choose the valid time and permission level, and tap Add. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 98: Modify Account Permissions

    Step 2 Tap Setting in the left menu bar and then tap Authority Management. Step 3 Tap Modify Rights. Step 4 Select an account, and then select required permissions for the account, and tap Save. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 99: Modify An Account

    Step 2 Tap Setting in the left menu bar and then tap Authority Management. Step 3 Tap in the line of the account to be modified. Step 4 Modify Account Name, Password, and Valid Time as required, and tap Modify. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 100: Delete An Account

    Refer to section 7.2 to log in to the system. Step 2 Tap Setting in the left menu bar and then tap Authority Management. Step 3 Tap in the line of the account to be modified. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 101: Configure The Snmp Interface

    Step 5 Tap to modify IP addresses and permissions as required and tap Save. Or, tap to add another group of read/write/Trap IP addresses and tap Add. Then, tap Save. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 102 Step 6 Tap Restart Cfg. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 103: Set Alarm Notifications

    If you want to remove the SIM card, gently press it to pop it out. Step 2 Refer to section 7.2 to log in to the system. Step 3 Tap Setting in the left menu bar and then tap Alarm Notification. Step 4 Tap Personnel Management. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 104: Set Email Addresses For Receiving Alarm Notifications

    Step 2 Tap Setting in the left menu bar and then tap Alarm Notification. Step 3 Tap Setting Mail. Step 4 Set required parameters in the Setting Mail dialog box, and tap Setting. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 105 – Real time: Alarm notification emails are sent in real time. – Days: Alarm notification emails are sent once every day. – Week: Alarm notification emails are sent once every week. – Monthly: Alarm notification emails are sent once every month. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 106 Enter to obtain the of the mailbox to set the IP address of each parameters. email server. Step 5 Tap Personnel Management. Step 6 Tap Add Account. Then, set Name, Phone, and Email, and tap Add. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 107: Set An Sms Message Filter

    Step 2 Tap Setting in the left menu bar and then tap Alarm Notification. Step 3 Tap Add SMS Filter. Step 4 Set Event Status, Event Level, Recipient, and Equipment as required, and tap Add. Step 5 Set a filter name and tap Add. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 108 Step 4 Set Event Status, Event Level, Recipient, and Equipment as required, and click Edit. —End To delete an existing filter: Step 1 Refer to section 7.2 to log in to the system. Step 2 Tap Setting in the left menu bar and then tap Alarm Notification. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 109: Set A Mail Filter

    To add a filter: Step 1 Refer to section 7.2 to log in to the system. Step 2 Tap Setting in the left menu bar and then tap Alarm Notification. Step 3 Tap Add Mail Filter. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 110: Configure Gateway Parameters

    This operation is only available for authorized accounts. Default settings are recommended. Step 1 Refer to section 7.2 to log in to the system. Step 2 Tap Setting in the left menu bar and then tap Alarm Notification. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 111 Step 3 Tap Serial Port Parameter Setting. Step 4 Set Serial Port Number, Serial Port Parameter, and SMS Type as required and tap Setting. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 112: Shut Down The Mdc

    Step 1 Refer to section 7.2 to log in to the system. Step 2 Tap Setting in the left menu bar and then tap Shutdown. Step 3 Tap OK in the pop-up dialog box. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 113: Restart The Mdc

    Refer to section 7.2 to log in to the system. Step 1 Step 2 Tap Setting in the left menu bar and then tap Restart. Step 3 Tap OK in the pop-up dialog box. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 114: Modify Password

    Refer to section 7.2 to log in to the system. Step 1 Step 2 Tap Setting in the left menu bar and then tap Modify Password. Step 3 Specify Original Password, New Password, and Determine Password. Then, tap Modify. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 115: Set System Time

    Step 1 Refer to section 7.2 to log in to the system. Step 2 Tap Setting in the left menu bar and then tap Time Setting. Step 3 Set time and tap OK. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 116: Set Automatic Logout Interval

    Step 2 Tap Setting in the left menu bar and then tap Logout Time Config. Step 3 Select a time interval and tap Modify. If you want to keep users logged in, select No Logout. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 117: Set Screen Off Interval

    Step 2 Tap Setting in the left menu bar and then tap Standby Setting. Step 3 Select a time interval and tap Modify. If you want to keep the screen on, select Always On. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 118: Check Mdc Version And Sn

    To check the product version, firmware version, and serial number of the MDC, refer to section 7.2 to log in to the system, tap Setting in the left menu bar and then tap About. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 119: Maintenance

    Check whether the UPS is working in a bypass mode. Under normal circumstances, the UPS will operate in the online mode. If the UPS is operating in a bypass mode, confirm the cause. Possible causes may include: – Manual switching – UPS overload – UPS error EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 120 If the UPS is operating in battery discharge mode, confirm the cause. Possible causes may include: – Mains power failure – Manual switching – Battery test – UPS failure EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 121: Periodic Maintenance Of The Cooling System

    The filter needs to be cleaned every three months. For details about how to take out and install the filter, see 9.2.1 Replace a filter of the cooing unit. Note For more information, contact our service personnel. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 122: Recommend Periodic Maintenance Of Monitoring System

    Step 8 Check whether the location of the water leakage sensor is moved. Step 9 Check whether the smoke sensor operates normally and the interface functions normally. Step 10 Check whether the electronic door locks can be opened normally. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 123: Troubleshooting

    If the problem persists, contact our customer service center. If you need to report bugs, errors, or issues to Eaton’s customer service center, please take note of and report the following information: •...
  • Page 124 The door lock is not connected properly. properly. Abnormal communication with the door lock The address of the door lock is set Check and set the DIP switch of the door incorrectly. lock properly. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 125: Replacement Of Common Parts

    Step 1 Loosen the screws on the front cover panel and remove the cover panel. Step 2 Loosen the screws on the filter, remove the filter and replace it with a new one. Step 3 Install the upper cover panel by fixing the screws on it. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 126: Replace A Temperature And Humidity Sensor

    —End 9.2.3 Replace a water leakage detector The water leakage detector is placed at the bottom of the main cabinet’s rear rail. When disassembling it, press down on the rail buckle. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 127: Replace An Electronic Door Lock

    Step 3 Replace the original door lock with a new one, adjust its position, and fix it with screws. Step 4 Connect the network cables with the new lock. Note Check the cable labels to ensure that the cables are connected correctly. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 128: Replace A Smoke Sensor

    Step 2 Disconnect the power plug on the light. Step 3 Replace the illuminating light with a new one. Step 4 Connect the power plug on the light. Step 5 Connect the power plug on the PDU to turn it on. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 129: Replace Ambient Lights

    Plugs for single cabinet and main cabinet in multiple cabinet system Step 4 Remove the ambient lights and cables and replace them with the new ones. Step 5 Connect the plug pair and install the covers. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 130: Replace The Ups

    Step 5 Press the UPS shutdown button to turn off the UPS. Step 6 Remove the input and output cables and other signal cables at the rear of the UPS, bundle them briefly, and then take out the UPS. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 131: Replace Internal Components Of The Pdm

    In this section, the replacement of the DC module is described with PDM-6K as an example. The replacement steps for other models are similar. Note Replacing the DC module does not require disconnecting the main power supply, and the customer's back-end equipment continues to operate normally. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 132 Step 2 Remove the front panel. Disconnect cables on the switch, and open the buckle to remove the switch. Step 3 Connect cables to the new switch by referring to the original cable connection. Step 4 Install the front panel and connect power supply again. —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 133: Replace The Monitor

    Step 4 Reinstall the new monitor to the front door of the cabinet, and fix the screws on the left and right mounting ears. Step 5 Reconnect the monitoring and power cables by following the way they were connected before. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 134: Replace Other Components Of Split And Integrated Cooling Units

    If you have taken a picture in Step 2, see the picture for reference. Step 5 Turn on the DC switch on the PDM. —End 9.2.11 Replace other components of split and integrated cooling units Obtain service manuals from our official website (www.eaton.com) for details. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 135: Appendix A Turn On The Cooling Unit With A Manual Operator

    Appendix A Turn on the cooling unit with a manual operator The manual operator is an option provided by Eaton. You can purchase it as required. Turn on the integrated cooling unit with a manual operator Step 1 Connect the manual operator to the B, A, -, and + terminals of the cooling unit.

  • Page 136: Turn On The Split Cooling Unit With A Manual Operator

    User Settings page. Then, set Return Temp to a low value (recommended: at least 3℃ lower than the actual return air temperature). Note If the temperature is set too high, the air compressor will fail to start. Step 4 Press the button on the manual operator. EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 137 —End EATON ICUBE UM.ICUBE October 2023 www.eaton.com...

  • Page 138: Appendix B Acronyms And Abbreviations

    Appendix B Acronyms and abbreviations Abbreviation/Acronym Full Form human machine interface micro data center power distribution unit power distribution module power usage effectiveness uninterruptible power systems EATON ICUBE UM.ICUBE October 2023 www.eaton.com...
  • Page 139 Photos and pictures also do not warrant a specific layout or functionality. Their use in whatever form is subject to prior approval by Eaton. The same applies to Trademarks (especially Eaton, Moeller, and Cutler-Hammer). The Terms and Conditions of Eaton apply, as referenced on Eaton Internet pages and Eaton order confirmations.
