5G Home Router
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Verizon 5G Home Router

Summary of Contents for Verizon 5G Home Router

  • Page 1 5G Home Router User Guide...
  • Page 2 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Rf Exposure Statement

    Use of another adapter could result in damage to the unit. The following power adaptor is qualified for use with this Verizon 5G Home Router: This unit must be powered by LUCENT TRANS, model 1A95 or equivalent UL...

  • Page 4: Table Of Contents

    2.2 Configuring the 5G Home Router ....................5 2.3 Connecting Other Devices ....................... 6 2.4 Pairing your mobile device and turning the 5G Home Router into a Bluetooth speaker ..7 Chapter 3 Accessing the Web User Interface ..................8 3.1 Login ……………………………………………………………………………………………………………………………………………….

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction This chapter includes a list of items included with the 5G Home Router (LVR1), an overview of the 5G Home Router’s features, and a description of the user interface and ports on the 5G Home Router. Unboxing Information Inside the product package for the 5G Home Router (LVR1), you should find the following items: •...
  • Page 6 3. Volume Adjustment Buttons Touch-sensitive volume adjustment buttons are located on the left and right sides of the touchpad on top of the 5G Home Router. The “+” button raises volume, while the “-” button lowers volume. 4. Mute Button A touch-sensitive mute button is located near the upper edge of the touchpad above the action button.
  • Page 7 5G Home Router connected to CPE, but no Animation Internet connection (5G node might be Red/Amber down) 5G Home Router connected to CPE, Wi-Fi Solid and Internet working well. White (turns off after 30 seconds) Firmware upgrade Fast Blink Usual Functions...

  • Page 8: Back Panel

    Back Panel WAN Port The WAN Port (the red Ethernet port) connects the 5G Home Router to a 5G CPE using an Ethernet cable. 2. LAN Ports Three LAN ports (one 2.5 Gbps port on the rightmost and two 1 Gbps ports in the middle) enable you to connect devices to the 5G Home Router via Ethernet cables.

  • Page 9: Chapter 2 Connecting The 5G Home Router

    5G Home Router. 3. Plug an Ethernet cable into the WAN port on the back of the 5G Home Router, and plug the other end of the Ethernet cable into an Ethernet port on your CPE.

  • Page 10: Connecting Other Devices

    Ensure that the devices you wish to connect wirelessly to the 5G Home Router have Wi- Fi capability. 2. Make sure the devices are using the same SSID and password as the 5G Home Router by launching each of the devices’ wireless applications.

  • Page 11: Pairing Your Mobile Device And Turning The 5G Home Router Into A Bluetooth Speaker

    2. Press the WPS button on a WPS-enabled device you wish to pair, making sure the device is within range of the 5G Home Router. 3. The circular LED light of the 5G Home Router will illuminate blue for two seconds to indicate pairing success.

  • Page 12: Chapter 3 Accessing The Web User Interface

    After connecting and turning on the 5G Home Router, a Sign In screen will appear. Enter your admin password to log into the Home Page of the 5G Home Router’s Web GUI. If you forget your password, you can answer one of the security questions to reset the password to factory default settings.

  • Page 13: Home Page/Main Section

    In the upper right panel of the screen, the Network Map presents a list of devices that are currently connected to the 5G Home Router. Below that, the screen is divided into three columns: Wi-Fi on the left, System Settings in the middle, and Firewall and Help on the right.
  • Page 14 The Change Admin Password section enables you to change the Admin password that is used to sign in to the 5G Home Router’s Home Page. Type the desired admin password in the New Admin Password field, then type the admin password again in the Confirm Password field. Click...
  • Page 15 Click Close to close the Admin Settings window. 3.2.3 My Verizon You will be directed to My Verizon, where you can manage your account online. With My Verizon, you can also pay your bill, check your usage and view your order status. 3.2.4 Restarting the 5G Home Router To restart the 5G Home Router, click the drop-down arrow and select Restart 5G Home Router.

  • Page 16: Wi-Fi Settings

    Wi-Fi Settings Click the > arrow on the bottom-right side of the Wi-Fi column in the Home Page to bring up the Wi-Fi page. On this page, you can adjust settings for the Primary Wi-Fi Network, Guest Wi-Fi Network, Wi-Fi Advanced Settings, and WPS. 3.3.1 Primary Wi-Fi Network Slide the Enable switch to the right to activate the Primary Wi-Fi network.
  • Page 17 6. Wi-Fi name (SSID) The Wi-Fi name (SSID) is the name of the wireless network broadcasting from the 5G Home Router. In order for devices to connect to the local network over a wireless link, they must select this network name from the list of detected wireless networks in the area. 7.
  • Page 18 3.3.2 Guest Wi-Fi Network Slide the Enable switch to the right to activate the Guest Wi-Fi network. The switch will turn blue when the guest network is enabled. To turn off the Guest Wi-Fi network, slide the switch to the left.
  • Page 19 Check the box if you want to broadcast the SSID. The SSID will be displayed when you search for available networks. 17. Wi-Fi network encryption Select one security method from the drop-down menu. The encryption types include None, WEP- 64, WPA2-Personal, and WPA-WPA2-Personal. 3.3.3 Wi-Fi Advanced Settings 18.
  • Page 20 19. Airtime Allocation Slide the Enable switch to the right to activate this function. The switch will turn blue when airtime allocation is enabled. To disable airtime allocation, slide the switch to the left. When ATF is enabled, the system needs to be restarted for it to take effect. In the Airtime Allocation Policy pull-down menu, two policy options are available: Fair and Strict.

  • Page 21: Connected Devices

    3.3.4 20. Primary Wi-Fi WPS WPS allows rapid wireless connection between the 5G Home Router and other WPS-compatible devices. You can trigger the WPS function on Primary Wi-Fi by clicking on the Primary Wi-Fi WPS button. Connected Devices This section displays information about the devices connected to the APs, illustrated through a Network Map, as well as the AP list and Connected Devices table.
  • Page 22 3.4.1 Network Map The Network Map illustrates the mesh network comprising the connected APs, their names, as well as their respective connection status. The number in the circle indicate the number of clients currently connected to the AP. 3.4.2 AP List The section presents detailed information of each AP, including the name of the AP, wireless radio channel information, health of the connection status, usage of the 2.4 GHz and 5 GHz Wi-Fi, backhaul usage, and the number of connected clients.
  • Page 23 The Block Device switch allows you to block or allow computers or devices from establishing a connection to the 5G Home Router. To block a device, slide the Block Device switch to the right. The switch will be blue when the feature is enabled.
  • Page 24 The Reserve DHCP IP switch enables the 5G Home Router to assign the same IP address to a specific device whenever that device connects to your network. To reserve DHCP IP, slide the Reserve DHCP IP switch to the right.

  • Page 25: Firewall

    Firewall A firewall is used to prevent traffic from entering and/or leaving the areas of your network. In this section you can select Low for minimum level of security, Medium for typical level of security, and High for maximum level of security. 3.5.1 Port Forwarding Port Forwarding can be used to open certain ports of a device to communicate with an Internet...
  • Page 26 on. To turn off this function, slide the switch to the left. To access this page, click Port Forwarding on the General Information page. From the Port Forwarding page, enter the appropriate forwarding options listed on the page, then click Add to save your changes, or click Cancel to discard any changes you made. Click Close to close this page.
  • Page 27 Configured Ports This table displays the ports that have been configured. 26. Application The created rule name will be displayed here. 27. Port From This shows the value of the start port. 28. Protocol This shows the protocol selected for the corresponding port forwarding rule. 29.

  • Page 28: Parental Controls

    3.5.2 DMZ (De-Militarized Zone) allows you to specify a DMZ host IP to redirect requests to a virtual DMZ host in order to enhance the security of the local area network. To enable DMZ, slide the DMZ enable switch to the right. If this function is enabled, threats from external networks will be directed to the DMZ instead of the network.
  • Page 29 This function can be used to block computers or devices from accessing certain websites through the 5G Home Router. The websites that have been blocked are displayed on the screen. To add a website to the block list, click Add Website and enter the website in the input field.

  • Page 30: System Settings

    System Settings 3.7.1 General Information The General Information page provides device information on the 5G Home Router, including the device name, IMEI, model, and more.
  • Page 31 3.7.2 History Log The History Log page provides various activity records of your 5G Home Router. To access this page, click History Log on the General Information page. 3.7.3 Backup & Restore...
  • Page 32 In this section, enter the desired info in the following fields: 33. 5G Home Router IP address Specify a range of IP addresses the 5G Home Router may assign to devices. The default LAN IP configuration is 192.168.0.1. 34. Subnet Mask...
  • Page 33 DHCP assigns LAN IP addresses for connected devices. You can specify the range of IP addresses the 5G Home Router may assign to devices. Click the DHCP switch to turn the DHCP function on or off. You can also enter the desired information in the following fields: 36.
  • Page 34 Use this function to set the time zone and enable automatic time updates. In the Time Zones field, select your local time zone. The 5G Home Router automatically detects daylight saving times for selected time zone. Define the time server addresses by clicking Add.

  • Page 35: Diagnostic

    Diagnostic You can perform a throughput test between two APs here. Select AP1 and AP2 and click the Run button to begin the throughput test. The results will be displayed in the Results section, which also shows Ping, throughput from AP1 to AP2 and vice versa.

  • Page 36: Chapter 4 Product Specifications

    Chapter 4 Product Specifications Wi-Fi 2.4GHz 802.11ax 4x4 MIMO  5GHz low band 802.11ax 4x4 MIMO  5GHz high band 802.11ax 4x4 MIMO  Backward compatible with 11ac/11n/11b  Bluetooth  Memory DDR4 RAM 2GB  Storage eMMC 8GB  Dimension Height: 235.8 mm ...
