INSTALLATION
8. INITIATING THE SURESHADE ATF-SG INTELLIGENT CONTROL
BOX (ICB)
The SureShade ATF-SG ICB was designed for plug and play setup. It is factory-programmed to the speci ed
extension length and ships ready to go in operation mode.
This document contains the proper sequence for initiating the ICB when installing the ATF-SG shade on the
boat. Make sure the actuators are properly mounted and the ICB is secured before proceeding with these
steps.
1. Plug in boat power to the ICB. Refer to the LED light on the control box. Once the controller is powered
up it will rst ash the shade length in green (i.e. 5 ashes for 5-foot shade, 6 ashes for 6-foot shade,
etc.). Then the LED will ash yellow for the model of shade (i.e. 1 ash for SG model, 2 ashes for ATF).
The LED will then ash 3 red ashes repeatedly. You have successfully connected the boat power to the
ICB and can proceed.
N OTE:
•
If the LED fl ashes YELLOW at this step (prior to connecting either actuator), you have either an incorrectly wired
rocker switch or a stuck switch relay. DO NOT PROCEED WITH CONNECTING ACTUATORS until you have the LED
blinking RED three times.
•
If the LED stays a solid YELLOW at this step (prior to connecting either actuator) you do not have suffi cient voltage
(less than 9.4 V). The shade will not run at any voltage under 10V.
2. Plug the starboard actuator connector into the
to the LED light on the control box — when the
connected the starboard actuator to the ICB and can proceed.
3. Plug in the port actuator connector to the
light on the control box — when the
port actuator to the ICB and you have completed the initiation of the ICB.

9. INITIATING THE REMOTE KEY FOB

N OTE: This can be performed only when both the actuators are disconnected.

USING THE MOMENTARY ROCKER SWITCH

1. Press and hold the Extend button until the status LED turns yellow.
2. Next press and release the Retract button three (3) times and then
press the Deploy button. The status LED should turn solid red.
3. The remote can now be paired with the controller.
4. Press a button on a remote. If the status LED blinks green it is now
paired.
ATF Installation Guide
GREEN STARBOARD CONNECTOR
light blinks RED one
ORANGE PORT CONNECTOR
light remains solid GREEN, you have successfully connected the
36
on the ICB. Refer
time, you have successfully
on the ICB. Refer to the LED
