SureShade RTX Installation Instructions & Owner's Manual
Pull-out boat shade
Hide thumbs
Also See for RTX:
- Installation instructions manual (8 pages) ,
- Installation instructions manual (4 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SureShade RTX
Summary of Contents for SureShade RTX
- Page 1 S U R E S H A D E T E C H N I C A L D O C U M E N T A T I O N RTX Pull-Out Boat Shade Installation Instructions & Owner’s Manual...
-
Page 2: Table Of Contents
CONTENTS Introduction ………………………………………………….….3 Customer Support……………………………….……….…….3 Warranty Information…………………………………….….3-4 Important Instructions………………………………………….5 Safety Warnings………………………………………..……….5 Tools Required…………………………….…………………….5 Installation - Mounting Clamps…………..………………….6 Installation – Measuring for Placement…………………….7 Installation - Mounting the Actuators………………..……..8 Installation - Attach Roller and Crossbars………………….9 Installation – Tension the Roller………………….………….10 Shade Operation…………………………………………..….11 Care and Maintenance…………………………….……….12 Page 2... -
Page 3: Introduction
Thank you for purchasing a SureShade retractable shade for your boat. Invented by boaters for boaters, SureShade is the new standard for shade on boats. Our automated or manual retractable shade systems are featured on over 50 boat brands as factory or aftermarket installations. - Page 4 SureShade technician or an experienced marine technician approved by SureShade. The remedy of repair or replacement of parts or materials that are found to be defective in factory materials or workmanship covered by this limited warranty shall constitute the owner’s sole and exclusive remedy against SureShade for any claims...
-
Page 5: Important Instructions
You may also submit a service request via email at service@sureshade.com. Do NOT attempt to repair shade on your own or you could risk voiding the warranty. -
Page 6: Installation - Mounting Clamps
Installing RTX Pull-Out Boat Shade The following instructions detail how to properly install SureShade RTX Pull-Out Boat Shade system for DIY or aftermarket installations. SureShade RTX can be installed aftermarket on a hardtop, arch, tower or T-Top. Installation instructions will vary per application. -
Page 7: Installation - Measuring For Placement
1. Measure Width for Placement Each RTX is custom-built to match the width and curvature (if any) of your top. Be aware that the outside width includes two stationary actuators with a pair of mounting clamps. These actuators require an area 4 inches wide by 18 inches long to mount properly on each side. -
Page 8: Installation - Mounting The Actuators
2. Mounting the Actuators • Position the actuators and mounting brackets on desired location (underside or topside), making sure these cylinders are parallel. Keeping the roller and crossbars attached at this point helps to ensure the mounting width ends up correct. -
Page 9: Installation - Attach Roller And Crossbars
3. Attach Roller and Crossbars With the actuators installed, you can reattach the roller and crossbars. Loosen and rotate the roller clamp on the actuator to line up with the roller mounting screws at each end of the roller. You might need to loosen the mounting clamps for the actuators to rotate each actuator to get the mid-crossbar and pull-bar connecting screws to line up properly. -
Page 10: Installation - Tension The Roller
4. Tension the Roller To enable the SureShade to retract properly and remain taut when deployed, the canvas roller is spring-loaded. You might need to add tension or “preload” the roller to make sure that the SureShade assembly operates correctly. To do this,... -
Page 11: Shade Operation
5. Shade Operation To test the RTX extension, center yourself in the middle of the push/pull bar for even leverage. Lift the framework up and aft to reduce friction for easier movement and extend until all locking pins are engaged. -
Page 12: Care And Maintenance
SureShade sunshade systems are built with quality marine-grade construction and materials; however, just like other parts of your boat, SureShade canvas systems need to be shielded from snow and other harsh winter weather conditions to protect the canvas and mechanical components. - Page 13 Revised editions will be available for free download at lci1.com. Manual information is considered factual until made obsolete by a revised version. Please recycle all obsolete materials. For all concerns or questions, please contact SureShade, a Lippert Components Company Ph: (877) 333-8323 |...
