1-6-2. MVS-7000X

Use the following connectors, cables or equivalents when connecting cables to the unit.
Model name Panel indication
MKS-8160X OUTPUTS 25 to 44
MKS-7171X DME OUTPUTS
1 to 20
MKS-8110X DME INPUTS
1 to 20
MVS-7000X OUTPUTS
1 to 24
45 to 48
PRIMARY INPUTS
1 to 20
FC OUT 1 to 4
MSD1, 2
1, 2
REF IN
REMOTE 1 to 4
GPI D-sub 25-pin,
Female
1, 2
NETWORK A(CTRL)
NETWORK B(DATA)
FM DATA
FM DEVICE 1, 2
*1: The following crimp contact is required for the plug.
AWG#18 to #22 : 1-566-493-21
AWG#22 to #24 : 1-564-774-11
AWG#24 to #30 : 1-564-775-11
*2: Conforms to the IEEE 802.3 Ethernet 100BASE-TX or 1000BASE-T standards.
1-16
Connector name Matching connector and cable
Name
BNC, 75 Ω Belden 1694 coaxial cable
BNC, 75 Ω Belden 1694 coaxial cable
D-sub 9-pin, D-sub 9-pin, Male
Female Connector 9-pin, Male
Junction Shell 9-pin
D-sub 25-pin, Male D-sub 25-pin, Male
Connector 25-pin, Male
Junction Shell 25-pin
_
RJ-45 Modular
Jack *2
_
USB TypeA
Receptacle 4-pin
Sony part No.
_
_
1-560-651-00 *1
1-561-749-00
1-560-904-11 *1
1-563-377-11
_
_
MVS-8000X/7000X
