B U I LT- I N
O V E R A L L D I M E N S I O N S
Over-and-Under Models
O V E R - A N D -
U N D E R
Model 611
Model 611G
with Glass Door
Model 650
Model 650G
with Glass Door
Model 611
Width
Height 84" (2138)
Depth
Illustrations shown in stainless steel design.
7
23 / "
8
3
/ "
8 (10) (606)
FRAME
BEHIND
EXTENSION FRAME
90˚
B
3
6
I N S TA L L A T I O N S P E C I F I C AT I O N S
84"
(2134)
30"
30"
(762) (762)
Model 611G
with Glass Door
30" (762) Width 30" (762)
Height 84" (2138)
24" (610) Depth 24" (610)
I N S TA L L A T I O N S P E C I F I C A T I O N S
Over-and-Under Models
Model 611
A) Rough Opening Width 29
B) Min Door Clearance
Model 611G
A) Rough Opening Width 29
B) Min Door Clearance
Model 650
A) Rough Opening Width 35
B) Min Door Clearance
Model 650G
A) Rough Opening Width 35
B) Min Door Clearance
Dimensions are for finished rough openings.
Door swing clearances are based on
stainless steel door and handle dimensions.
84"
(2134)
36"
(914)
Model 650
Width 36" (914)
Height 84" (2138)
Depth 24" (610)
1
/ " (749)
2
1
30 / " (765)
8
1
/ " (749)
2
1
30 / " (765)
8
1
/ " (902)
2
1
36 / " (916)
16
1
/ " (902)
2
1
36 / " (916)
16
83"
(2108)
MIN HEIGHT
REQUIRED TO
FINISHED
FLOORING
(LEVELERS IN)
84" 84"
(2134) (2134)
36"
(914)
Model 650G
with Glass Door
Width 36" (914)
Height 84" (2138)
Depth 24" (610)
24"
EXTEND
(610) WATER LINE
ROUGH APPROX 36" (914)
OPENING FROM BACK WALL
DEPTH
SHUT-OFF
VALVE
TOP VIEW
7"
E
(178)
6"
(152)
LOCATE ELECTRICAL
WITHIN SHADED AREA
A
ROUGH OPENING WIDTH
1
75 / "
2
(1918)
LOCATE WATER SUPPLY
WITHIN SHADED AREA
3"
(76)
18" 6"
(457) (152)
W

FRONT VIEW

24"
(610)
3
83 / "
4 (2127)
ROUGH OPENING
HEIGHT TO
FINISHED
FLOORING WITH
STANDARD
11" (279) GRILLE
