B U I LT- I N I N S TA L L A T I O N S P E C I F I C AT I O N S
O V E R A L L D I M E N S I O N S
All Refrigerator | All Freezer Models
73"
(1854)
36"
(914)
Model 601R
All Refrigerator
Width 36" (914)
Height 73" (1854)
Depth 24" (610)
Illustrations shown in stainless steel design.
I N S TA L L A T I O N S P E C I F I C A T I O N S
All Refrigerator | All Freezer Models
Models 601R and 601RG will not require the
water line connection.
Dimensions are for finished rough openings.
Door swing clearances are based on
stainless steel door and handle dimensions.
23
3
/ "
8 (10) (606)
FRAME BEHIND
EXTENSION FRAME
90˚
36
(916)
Dimensions in parentheses are in
millimeters unless otherwise specified.
73"
(1854)
36"
(914)
Model 601RG
All Refrigerator
with Glass Door
Width 36" (914)
Height 73" (1854)
Depth 24" (610)
7
/ "
8
3
72 / "
4 (1848)
ROUGH OPENING
1
HEIGHT TO
/ "
16
FINISHED
FLOORING
73"
(1854)
36"
(914)
Model 601F
All Freezer
Width 36" (914)
Height 73" (1854)
Depth 24" (610)
EXTEND
24"
WATER LINE
(610) APPROX 36" (914)
ROUGH FROM BACK WALL
OPENING (601F ONLY)
DEPTH
SHUT-OFF
VALVE
TOP VIEW
1
35 / "
2 (902)
ROUGH OPENING WIDTH
MINIMUM HEIGHT
LOCATE ELECTRICAL
WITHIN ENTIRE SHADED AREA
LOCATE WATER SUPPLY
WITHIN BOTTOM SHADED
AREA ONLY (601F ONLY)
24" 6"
(610) (152)
3"
(76)
E
11"
(279)
W
FRONT VIEW
A L L R E F R I G E R AT O R
A L L F R E E Z E R
Model 601R
All Refrigerator
Model 601RG
All Refrigerator
with Glass Door
24"
Model 601F
(610)
All Freezer
3
72 / "
4 (1848)
REQUIRED TO
FINISHED
FLOORING
(LEVELERS IN)
5
