PARTS LIST Description Spec. Description Spec. Main frame Bushing Front stabilizer Ø6.0*40 Slide rail SPHC,T=2.0 Meter Rear stabilizer Sensor wire PA,black Support for computer Sensor holder Support Plate Magnet Ø10*5 Tank plate Spacer for mesh belt wheel Ø16* Ø10.2*69 Plate for bushing SPHC,T=3.0 Short spacer Ø16* Ø10.2*16...
Page 5
ASSEMBLY INSTRUCTIONS #66 M8*15 4pcs #71 OD20*ID8.5*1.5 4pcs S13-17 STEP 1: NOTE: We recommend having 2 people to assemble the product. Turn over the Slide Rail (No. 3) as above.Attached the Rear Stabilizer (No.4) to the Slide Rail (No.3) with 4 Washers (No.71) and 4 Outer Hex Screws (No.66). Tighten with Spanner (No.75).
Page 6
ASSEMBLY INSTRUCTIONS #68 M4*12 2pcs S13-17 STEP 2: Attach L & R End Caps (No.25 & 26) to Front Stabilizer (No.2). Then tighten with 2 Cross Screws (No.68) using Spanner (No.75).
Page 7
ASSEMBLY INSTRUCTIONS #60 M8*15 8pcs #71 OD20*ID8.5*1.5 8pcs STEP 3: Keep the Main Frame (No.1) upright. Attach Front Stabilizer (No.2) to Main Frame (No.1) using 8 Washers (No.71) and 8 Screws (No.60). Tighten with Allen Wrench (No.74). Note: You can put 3~4 screws into the holes first, and start tightening by hand. After all the screws are put in, then tighten with the tool.
Page 8
ASSEMBLY INSTRUCTIONS #35 Stopper 2pcs #58 M8*15 4pcs #60 M8*15 2pcs #71 OD20*ID8.5*1.5 2pcs #82 Left Endcap 1pc #83 Right Endcap 1pc STEP 4: Slide the Seat (No.36) onto the Slide Rail (No.3). Attach the Slide Rail (No. 3) to the Main Frame (No. 1) using 4 Flat Screws (No. 58). Secure the Stopper (No.35) with 2 Screws (No.60) and Washers (No.71).Insert all 6 screws partially into the holes first, and then tighten with Allen Wrench (No.74).
Page 9
ASSEMBLY INSTRUCTIONS #60 M8*15 4pcs #71 OD20*ID8.5*1.5 4pcs STEP 5: Attach Meter Complete(No.46) to Main Frame (No.1) using 4 Washers (No.71) and 4 Screws (No.60). Tighten with Allen wrench (No.74). The assembly is complete!
Page 10
HOW TO FILL AND EMPTY THE TANK 1. Remove the Fill Plug (No.33) from the Upper Tank Cover (No.12). 2. To fill tank with water, refer to Fig. A. Insert the Funnel (No.77) into the tank, then use a cup or the Siphon Pump (No.76) and a bucket to fill the tank. Use the water level gauge on the side of the tank to measure desired water level in the tank.
ADJUSTMENT GUIDE There are 3 hooks (A, B, C) for the bungee cord, located on the inside of the frame under the water tank. If you hook the bungee cord on to B or C, it increases the assisted return of the mesh belt.
Page 12
ADJUSTMENT GUIDE PEDAL ADJUSTMENT The pedal strap is adjustable and can be personalized to fit the user’s foot size. To adjust the pedal strap, remove the Velcro end of the strap from the mesh side by pulling it upward then to the left. Once removed, you may increase the opening of the pedal strap by pulling the mesh end up and to the right.
Page 13
ADJUSTMENT GUIDE v ADJUSTING THE BALANCE Adjust the End Caps on the Rear Stabilizer (No.4) of the machine if the machine is unbalanced during use.
Page 14
ADJUSTMENT GUIDE v STORAGE CAUTION! Move the Seat (No.36) to front of Slide Rail (No.3) first or it will glide down when raising the rower up! CAUTION! Move with caution when you raise the rower up, as your head may touch the Rear Stabilizer (No.
Page 15
EXERCISE METER 【 FUNCTION BUTTONS 】 UP▲/ DOWN▼:To press these two buttons through available selection. adjust the function value upward and downward. ENTER: To confirm your selection. During training, press the button to scan each display function. START / STOP: To start and stop your selected workout program. RESET:...
Page 16
【 OPERATION 】 1. Install 2PCS AA batteries→one long beep for 2 seconds →in the meanwhile, segment test for 2 seconds (Fig.1). Then, the monitor enters into the CLOCK & CALENDAR MODE.(Fig.2). 2. Firstly, you may enter into the CLOCK field to set YEAR (in the area of STROKES); MONTH (in the area of CALORIES);...
Page 17
Fig.5 Fig.6 B. Press START KEY to START and STOP will disappear. The USER & PC will display in the matrix.(Fig.6).the monitor will STOP when one have reached the distance of race which has been set before, then the matrix displays “PC WIN or USER WIN”(Fig.7) and may display the state of the energy after 6 seconds.
Page 18
