Implant Assembly - Zimmer Biomet Arcos Modular Femoral Revision System Surgical Technique

Figure 31

Implant Assembly

With the trial still assembled in the sterile field,
assemble the distal stem and proximal body implants
to match the orientation of the assembled trial
(Figure 31).
Note: If utilizing the 190 mm stem, ensure the bevel
at the distal tip of the stem is oriented anteriorly.
Arcos Broach/Calcar Proximal Body Surgical Technique
15 |
Figure 32
When the desired orientation of the implants has been
achieved, thread the green proximal body inserter to
the assembled implant and impact the taper junction
with at least three blows of the mallet on the back table
(Figure 32).
