ICC EXCEL Installation And Maintenance Instructions Manual page 18

EXCEL OFFSET TABLE - Use this table if you are not
installing an adjustable length between the elbows.
LENGTH BETWEEN
OFFSETS
5 INCH Ø
NO LENGTH
6" Length
12" Length
18" Length
24" Length
48" Length
24" + 12"
48" + 12"
48" + 18"
48" + 24"
48" + 24" + 12"
48" + 48"
6 INCH Ø
NO LENGTH
6" Length
12" Length
18" Length
24" Length
48" Length
24" + 12"
48" + 12"
48" + 18"
48" + 24"
48" + 24" + 12"
48" + 48"
7 INCH Ø
NO LENGTH
6" Length
12" Length
18" Length
24" Length
48" Length
24" + 12"
48" + 12"
48" + 18"
48" + 24"
48" + 24" + 12"
48" + 48"
8 INCH Ø
NO LENGTH
6" Length
12" Length
18" Length
24" Length
48" Length
24" + 12"
48" + 12"
48" + 18"
48" + 24"
48" + 24" + 12"
48" + 48"
EXCEL Canada
15° Elbows
RISE OFFSET
9 1/4 1 1/4
13 1/4 2 1/4
19 3 3/4
25 5 1/2
30 3/4 7
53 3/4 13 1/4
40 1/2 9 1/2
63 3/4 15 3/4
69 1/2 17 1/2
75 1/4 19
85 1/4 21 1/2
98 1/2 25 1/4
9 1/2 1 1/4
13 1/2 2 1/4
19 1/4 4
25 1/4 5 1/2
31 7
54 13 1/4
40 3/4 9 3/4
64 15 3/4
69 3/4 17 1/2
75 1/2 19
85 1/2 21 3/4
98 3/4 25 1/4
9 3/4 1 1/4
13 3/4 2 1/2
19 1/2 4
25 1/2 5 1/2
31 1/4 7
54 1/2 13 1/4
41 9 3/4
64 1/4 16
70 17 1/2
75 3/4 19
85 3/4 21 3/4
99 25 1/4
10 1 1/4
14 2 1/2
19 3/4 4
25 3/4 5 1/2
31 1/2 7
54 3/4 13 1/4
41 1/4 9 3/4
64 1/2 16
70 1/4 17 1/2
76 1/4 19
86 21 3/4
99 1/4 25 1/4
30° Elbows
RISE OFFSET
10 1/2 2 3/4
14 1/4 5
19 1/4 8
24 1/2 11
29 3/4 14
50 1/2 26
38 3/4 19
59 1/2 31
64 1/2 34
69 3/4 37
78 3/4 42 1/4
90 1/2 49
11 3
14 3/4 5
19 3/4 8
25 11
30 1/4 14
51 26
39 1/4 19 1/4
60 31 1/4
65 34 1/4
70 1/4 37 1/4
79 1/4 42 1/4
91 49 1/4
11 1/2 3
15 1/4 5 1/4
20 1/4 8 1/4
25 1/2 11 1/4
30 3/4 14 1/4
51 1/2 26 1/4
39 3/4 19 1/4
60 1/2 31 1/4
65 1/2 34 1/4
70 3/4 37 1/4
79 3/4 42 1/2
91 1/2 49 1/4
12 3 1/4
15 3/4 5 1/4
20 3/4 8 1/4
26 11 1/4
31 1/4 14 1/4
52 26 1/4
40 1/4 19 1/2
61 31 1/2
66 34 1/2
71 1/4 37 1/2
80 1/4 42 1/2
92 49 1/2
18
All dimensions are in inches
45° Elbows
RISE
11 1/4
14 1/4
18 1/2
22 3/4
27
44
34 1/4
51 1/4
55 1/2
59 3/4
67
76 3/4
12
15
19 1/4
23 1/2
27 3/4
44 3/4
35
52
56 1/4
60 1/2
67 3/4
77 1/2
12 3/4
15 3/4
20
24 1/4
28 1/2
45 1/2
35 3/4
52 3/4
57
61 1/4
68 1/2
78 1/4
13 1/2
16 1/2
20 3/4
25
29 1/4
46 1/4
36 1/2
53 1/2
57 3/4
62
69 1/4
79
Owner's Manual
OFFSET
4 3/4
7 3/4
12
16 1/4
20 1/2
37 1/2
27 3/4
44 3/4
49
53 1/4
60 1/2
70
5
8
12 1/4
16 1/2
20 3/4
37 3/4
28
45
49 1/4
53 1/2
60 3/4
70 1/2
5 1/4
8 1/4
12 1/2
16 3/4
21
38
28 1/4
45 1/4
49 1/2
53 3/4
61
70 3/4
5 1/2
8 1/2
12 3/4
17
21 1/4
38 1/4
28 1/2
45 1/2
49 3/4
54
61 1/4
71
