INSTALLATION AND MAINTENANCE
A MAJOR CAUSE OF CHIMNEY RELATED FIRES IS FAILURE TO MAINTAIN
REQUIRED CLEARANCES (AIR SPACE) TO COMBUSTIBLE MATERIALS. IT IS OF
UTMOST IMPORTANCE THAT THIS CONNECTOR BE INSTALLED ONLY IN
ACCORDANCE WITH THESE INSTRUCTIONS.
Allowable Flue Gas Temperatures
Maximum Continuous
Brief Forced Firing
Tested To
EXCELPrime is used to connect a solid, liquid and gas fired appliances,
including wood burning stoves, freestanding fireplaces, and furnaces to a pre-
fabricated metal or masonry chimney. EXCELPrime is intended for interior use
only.
Contact local building or fire officials about local restrictions and building
inspections in your area.
Always follow the wood burning stove manufacturer's installation instructions.
Keep these installation and operating instructions in a safe location for future
reference.
EXCELPrime has been tested and listed by
Intertek Testing Services as per Standard ULC-S641
ETL Listing #4005717
EXCELPrime
18" Clearance Stove Pipe
INSTRUCTIONS
ICC INDUSTRIAL CHIMNEY COMPANY INC.
1200°F
650°C
1700°F
925°C
2100°F
1150°C
400 J-F K
Q
UEBEC
Tel.: 450 565-6336
, S
. J
ENNEDY
T
EROME
, C
, J7Y 4B7
ANADA
fax: 450 565-6519
www.icc-rsf.com
(SW-II_2017-10)
