All-Aluminum Z-Articulating Cap Sill Field Replacement Instructions
Required Tools and Materials
1.
Flathead Screw Driver or Stiff Scraper:
To remove old Z-Series sill cap.
protect
2.
Small Wood Block: To
aluminum sill deck when prying off
adjustable sill cap
.
3.
Measuring Tape: For sizing new sill cap
and door bottom before cutting to proper
length.
Standard Door (Single) Replacement Kit Contents
1S
(1) 3/0 Z-Articulating Cap
6
7
(1) 3/0 Mylar Strip
(1) Z-AC Door Bottom Gasket
French (Double Door) Replacement Kit Contents
1F
(1) 6/0 Z-Articulating Cap
7
6
(2) Z-AC Door Bottom Gasket
(2) 3/0 Mylar Strip
Rev Date 5.11.16
4.
Pencil: To mark cap and door bottom.
5.
Cutting Tool: Chop /Miter Saw recommended
to trim cap and door bottom to proper length.
6.
1/2" crown Staples: To secure Door bottom
to panel.
2R
2L
3
(1) Right Z-End Base
(1 )Left Z-End Base
Mull Stiffener
Mull Stiffener
2R
2L
(1) Right Z-End Base
(1) Left Z-End Base
Mull Stiffeners
Mull Stiffeners
8
(1) Bottom Pad for
Astragal Boot
F I E L D R E P L A C E M E N T I N S T R U C T I O N S
™
ADDITIONAL TOOLS FOR FRENCH DOORS
1.
7/8" Diameter Drill Bit
4
1 pair of (2)
(1) Left and (1) Right
Corner Pads
Active Mull Stiffener
Gaskets
3
4
(3) Corner Pads
(1) Left and (1) Right Active
Mull Stiffener Gaskets
9
Astragal Lower Trim Cap
(1) White & (1) Bronze
5
(1) Kerfed Door Bottom & (1) Staple On Door Bottom
5
(2) Kerfed Door Bottoms & (2) Staple On Door Bottoms
1
