8. Connect the pump to the Molex connector J5, near the
You can also use the original pumps instead of an external pump.
9. Disconnect the lower end of the SIT from the pump.
10. Connect the lower side of the SIT to a 50 cm piece of black
11. Connect the other end of the tube to the external pump, as
10100125 - A
E P , which supplies 24 volts to the pump.
LECTRIC ANEL
ink tubing, as shown below.
shown above.
© Matan Digital Printers Ltd
Filter
Black tubing
External Pump
