Page 2
SER 7836-A Control Valve Late Models Early Models Figure 2 Control Valve Model 7836 Series - Exploded View Revision (1-13) Alemite LLC 1-800-548-1191 - http://www.partdeal.com - info@partdeal.com...
Page 3
Part numbers with an X prefix indicate a quantity of ten (10) designates a repair kit item Repair Kits Part No. Kit Symbol Description 398723 Kit, Repair (for Valve Model 7836-A) 393761 Kit, Repair (for Valve Model 7836-C1) Alemite LLC Revision (1-13) 1-800-548-1191 - http://www.partdeal.com - info@partdeal.com...
Page 4
7. Remove Link (16) from Handle (23). nents of the valve assembly. Prior to performing any maintenance procedure, Step for Model 7836-A the following safety precautions must be observed. 8. Remove Pin (3) that secures Valve Assembly (4) to the Rod.
Page 5
Control Valve SER 7836-A 1. Install O-Ring (21) onto Swivel Assembly (22). 4. Install each Pin (24) through the Handle and into the Body. 2. Screw the Swivel Assembly into Body (9). • Make sure each Pin is centered. • Tighten the Swivel Assembly securely.
Page 6
8. Install Link (16) onto the pins of the Handle. 20. Adjust the Nut on the Rod until the Handle moves freely 1/8 " (3.2 mm) at the bottom. Steps for Model 7836-A • See Figures 3 and 4. 9. Install Valve Assembly (4) onto the Rod.
Page 7
Control Valve SER 7836-A Test NOTE: Apply air pressure to allow the pump to begin to cycle. Slowly increase the air pressure to achieve the desired material WARNING pressure. 1. Point the control valve into an appropriate collection Do not exceed the lowest pressure rating container.
Page 8
Solutions Continuous product flow 1. Foreign material between Valve Assembly 1. Disassemble, clean, and inspect (4) and Valve Seat (2) [Model 7836-A] seat area. Check mating surfaces 1. Foreign material between Valve Seat (6) and replace sealing components and valve seal within Valve Assembly (7) as necessary.
