MOTO GUZZI WOULD LIKE TO THANK YOU
for choosing one of its products. We have compiled this booklet to provide a comprehensive overview of your vehicle's quality features. Please read it
carefully before riding the vehicle for the first time. It contains information, tips and precautions for using your vehicle. It also describes features, details
and devices to assure you that you have made the right choice. We believe that if you follow our suggestions, you will soon get to know your new vehicle
well and that it will continue to give you satisfactory service for many years to come. This booklet forms an integral part of the vehicle; should the vehicle
be sold, it must be transferred to the new owner.
MGX-21
Ed. 02_07/2016 Cod. 2Q000205 (IT-FR-DE-NL-ES-EN)

Advertisement

Table of Contents
loading

Related Manuals for MOTO GUZZI MGX-21 2016

Summary of Contents for MOTO GUZZI MGX-21 2016

  • Page 1 MOTO GUZZI WOULD LIKE TO THANK YOU for choosing one of its products. We have compiled this booklet to provide a comprehensive overview of your vehicle's quality features. Please read it carefully before riding the vehicle for the first time. It contains information, tips and precautions for using your vehicle. It also describes features, details and devices to assure you that you have made the right choice.
  • Page 2 The instructions in this manual have been prepared to offer mainly a simple and clear guide to its use; it also describes routine maintenance procedures and regular checks that should be carried out on the vehicle at an authorised Moto Guzzi Dealer or Workshop, The booklet also contains instructions for simple repairs.
  • Page 3 Personal safety Failure to completely observe these instructions will result in serious risk of personal injury. Safeguarding the environment Sections marked with this symbol indicate the correct use of the vehicle to prevent dam- aging the environment. Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious damage to the vehicle and sometimes even the invalidity of the guarantee The symbols illustrated above are very important.

  • Page 5: Table Of Contents

    INDEX GENERAL RULES............... Opening the saddle............... 51 Carbon monoxide..............USB Port................52 Fuel..................Identification................52 Hot components..............USE....................55 Warning lights................ Checks..................56 Used engine oil and gearbox oil..........10 Refuelling.................. 58 Brake and clutch fluid............11 Rear shock absorbers adjustment..........60 Battery hydrogen gas and electrolyte........
  • Page 6 Braking system fluid top up........... 87 Checking clutch fluid..............88 Topping up clutch fluid............88 Use of a new battery............. 88 Checking the electrolyte level..........89 Charging the battery.............. 90 Long periods of inactivity............90 Fuses..................91 Lamps..................93 Headlight adjustment............. 95 Front direction indicators............

  • Page 7: General Rules

    MGX-21 Chap. 01 General rules...

  • Page 8: Carbon Monoxide

    Carbon monoxide CAUTION EXHAUST EMISSIONS CONTAIN CARBON MONOXIDE, A POISONOUS GAS WHICH CAN CAUSE LOSS OF CONSCIOUSNESS AND EVEN DEATH. CAUTION CARBON MONOXIDE IS ODOURLESS AND COLOURLESS, THEREFORE IT CANNOT BE DETECTED BY SMELL, SIGHT OR OTHER SENSES. DO NOT BREATHE IN EXHAUST FUMES UNDER ANY CIRCUMSTANCES.

  • Page 9: Hot Components

    KEEP OUT OF THE REACH OF CHILDREN. IF THE VEHICLE FALLS OR IS ON A STEEP INCLINE FUEL CAN LEAK. Hot components The engine and the exhaust system components get very hot and remain in this con- dition for a certain time interval after the engine has been switched off. Before handling these components, make sure that you are wearing insulating gloves or wait until the engine and the exhaust system have cooled down.

  • Page 10: Used Engine Oil And Gearbox Oil

    AVOID ANY POSSIBLE DAMAGE. PERFORM THE MOTOR OIL LEVEL CHECK. IF THE INSUFFICIENT MOTOR OIL PRESSURE LIGHT REMAINS DESPITE THE ABOVE PROCEDURE BEING PER- FORMED CORRECTLY, CONTACT AN AUTHORIZED Moto Guzzi Dealer TO HAVE THE SYSTEM CHECKED. Used engine oil and gearbox oil...

  • Page 11: Brake And Clutch Fluid

    Brake and clutch fluid BRAKE AND CLUTCH FLUIDS CAN DAMAGE THE PLASTIC OR RUBBER PAIN- TED SURFACES. WHEN SERVICING THE BRAKING OR THE CLUTCH SYSTEM PROTECT THESE COMPONENTS WITH A CLEAN CLOTH. ALWAYS WEAR PROTECTIVE GOGGLES WHEN SERVICING THESE SYSTEMS. BRAKE AND CLUTCH FLUIDS ARE EXTREMELY HARMFUL FOR YOUR EYES.

  • Page 12: Reporting Of Defects That Affect Safety

    BATTERY LIQUID IS CORROSIVE. DO NOT POUR OR SPILL ON PLASTIC COM- PONENTS IN PARTICULAR. ENSURE THAT THE ELECTROLYTIC ACID IS COM- PATIBLE WITH THE BATTERY BEING ACTIVATED. Reporting of defects that affect safety Unless otherwise specified in this Use and Maintenance Booklet, do not remove any mechanical or electrical component.

  • Page 13: Vehicle

    MGX-21 Chap. 02 Vehicle...
  • Page 14 02_01...

  • Page 15: Arrangement Of The Main Components

    02_02 Arrangement of the main components (02_02) Key: 1. Headlight unit 2. Front left turn indicator 3. Windscreen 4. Instrument panel 5. Left rear-view mirror 6. Clutch pump 7. Left light switch 8. Fuel tank cap 9. Fuel tank 10. Rider/passenger saddle 11.
  • Page 16 12. Left side saddle pannier 13. Licence plate light 14. Left silencer 15. Rear tone wheel 16. Rear ABS sensor 17. Left hand passenger footrest 18. Side stand 19. Left rider footrest 20. Gear lever 21. Engine oil level dipstick 22.

  • Page 17: Dashboard

    NOTE ELECTRICAL COMPONENTS FUNCTION ONLY WHEN THE IGNITION KEY IS SET TO "ON" 02_03 Dashboard (02_03) Key: 1. Clutch control lever 2. Ignition switch /steering lock...
  • Page 18 3. Instruments and gauges 4. Front brake lever 5. Throttle grip 6. Light switch/high-beam flasher button 7. Daytime/night lights switch 8. "MUTE" button/radio menu 9. Left selector/cruise control 10. Turn indicator button 11. horn button 12. MGMP button 13. Radio selector 14.

  • Page 19: Instrument Panel

    02_04 Instrument panel (02_04) Dashboard key: 1. Speedometer 2. Multifunctional digital display 3. Warning lights 4. Rpm indicator 5. Multifunctional digital display 6. Warning lights CAUTION A PROLONGED DIRECT EXPOSURE OF THE DASHBOARD TO SUNLIGHT WHILE THE ENGINE IS STOPPED MAY RESULT IN TEMPORARY REDUCTION...
  • Page 20 The vehicle is supplied with two keys already programmed. The instrument panel ac- cepts a maximum of four keys at the same time: contact an Official Moto Guzzi Dealer to enable these keys or to disable a key that has been lost.

  • Page 21: Light Unit

    4. MI warning light (orange) 5. Cruise control indicator light (green) 6. ABS (Anti-lock Braking System) warning light (orange) 7. MGCT (Moto Guzzi Traction Control) warning light (orange) 8. Turn indicator warning light (green) 9. Low fuel warning light (orange) 10.

  • Page 22: Digital Lcd Display

    02_12, 02_13, 02_14, 02_15, 02_16) Turning the ignition key to the position "ON", in both instruments are switched on for two seconds: • The Moto Guzzi logo; • all warning lights; • backlighting. When the daytime light function is activated the back lighting switches off after the key is turned ON.
  • Page 23 Only with the vehicle at standstill: • Menu • MGCT (Moto Guzzi Traction Control) The standard settings that can be viewed on the left display are: 1. FM radio 2. AM radio (enabled/disabled by the user) 3. USB audio (audio player for USB flash drives) 4.
  • Page 24 When the thresholds of the maintenance intervals have been exceeded an adjustable spanner icon will appear (3) left of the right display. To reset the service is necessary to take it to an Authorized Moto Guzzi Dealer and Office. Icon ignition: every 10,000 km (6,214 mi)
  • Page 25 FUEL LEVEL In the right display, it is visible the fuel level in the tank by means of a series of notches (6). NOTE THE FUEL LEVEL INDICATION MAY CHANGE DEPENDING ON THE INCLINA- TION OF THE MOTORCYCLE WHEN IT IS ON THE SIDE STAND AS OPPOSED TO WHEN IT IS IN MOTION.
  • Page 26 BATTERY VOLTAGE In this mode the correct battery voltage can be viewed 02_15 TIME SETTINGS The clock can be programmed with this option. Press and hold the "MODE" selector in the centre to access the function. Within this function, each time the "MODE" se- lector is pressed up or down, the time will be increased or decreased by one hour.

  • Page 27: Alarms

    "URGENT" and "SERVICE" words alternately being shown on the right display. See an Official Moto Guzzi Dealer as soon as possible. In these cases the ECU activates a safety procedure limiting vehicle performance in order to allow the rider to go to an Official Moto Guzzi Dealer at a reduced speed.
  • Page 28 IF THE SIGNAL APPEARS AFTER ENGINE IGNITION (THE WARNING LIGHT IS FLASHING), AN OIL PRESSURE FAULT IS SIGNALLED; SWITCH OFF THE EN- GINE IMMEDIATELY AND TAKE THE MOTORCYCLE TO AN Official Moto Guzzi Dealer USING A ROADSIDE ASSISTANCE VEHICLE. ELECTRONIC CONTROL UNIT DISCONNECTED ALARM...

  • Page 29: Mapping Selection

    TURN INDICATORS MALFUNCTION When the instrument panel detects a failing turn indicator, the warning light flashes twice as fast and the problem is signalled on the right display. 02_22 ALARMS PROLONGED BRAKING In case of accidental pressing of one of the two brakes for more than thirty seconds while the vehicle is driving more than 20 Km/h (12.43 mph) the instrument panel shows the fault displaying the wording "BRAKE"...
  • Page 30 CAUTION ONLY EXPERT RIDERS, RIDING ON ROADS WITH GOOD GRIP ARE ADVISED TO USE THIS MODE. IT IS NOT RECOMMENDED FOR WET SURFACES AND/OR ROADS WITH LOW GRIP. The PIOGGIA mode is designed for use of the vehicle on wet surfaces or in conditions of poor grip.

  • Page 31: Control Buttons

    • (6) INSTANT FUEL CONSUMPTION • (7) AVERAGE IN RESERVE • (8) BATTERY VOLTAGE • (9) CLOCK • (10) MENU (only with the vehicle at standstill) • (11) MGCT (Moto Guzzi Traction Control) (only with the vehicle at standstill) 02_27...

  • Page 32: Advanced Functions

    With the following options: TRIP ODOMETER, TRAVELLING TIME, AVERAGE TRAVELLING SPEED, AVERAGE FUEL CONSUMPTION pressing in and holding the central "MODE" selector resets all the indications stored in the active TRIP LOG. Advanced functions (02_28, 02_29, 02_30, 02_31, 02_32, 02_33, 02_34, 02_35) The following functions (MENU and MGCT) are selectable only when the vehicle is at standstill.
  • Page 33 • CALIBRATING To calibrate the MGCT system (Moto Guzzi Traction Control), ride the vehicle on flat, straight section of road for approximately 10 seconds in second gear and at a speed of 30 +/- 2 km/h (18.64 +/- 1.24 mph) until the message "CALIBRATION" is no longer 02_30 shown on the display.
  • Page 34 IF TYRES OTHER THAN THOSE INDICATED IN THIS USE AND MAINTENANCE BOOKLET ARE USED, TO OBTAIN THE SAME PERFORMANCE FROM THE MGCT SYSTEM THE SETTING LEVELS OF THE SYSTEM ITSELF MAY NEED TO BE MODIFIED. NOTE TURN THE IGNITION SWITCH OFF TO ABORT THE CALIBRATION PROCE- DURE.
  • Page 35 SERVICE This function interfaces with the systems present on the motorcycle and diagnose them. For this, it is necessary to go to a Moto Guzzi Service Centre. LANGUAGE The right display language can be selected with this function. The available options are: •...
  • Page 36 DEUTSCH • ESPAÑOL MGCT (Moto Guzzi Traction Control) MGCT is a system which controls slipping of the rear wheel in the event of a brief loss of grip, for the purpose of increasing vehicle stability. While MGCT improves vehicle control, it does not allow the physical handling limits of the vehicle to be exceeded.
  • Page 37 Warning light key: • Lamp off: with system activated with vehicle in motion or system activated after exceeding 5 Km/h (3.11 mph) after key-on; • Lamp lit continuously: system deactivated deliberately by rider, or deacti- vated as a result of a malfunction; •...
  • Page 38 IF THIS OCCURS, CONTACT AN OFFICIAL Moto Guzzi dealer. IF THE GAP FOR ONE OR BOTH SENSORS IS NOT WITHIN THE TOLERANCE INDICATED BELOW, TAKE THE MOTORCYCLE TO AN Official Moto Guzzi Deal- Characteristic Distance between tone wheel and front sensor...

  • Page 39: Ignition Switch

    Distance between tone wheel and rear sensor 0.3 - 2.00 mm (0.012 - 0.079 in) Ignition switch (02_36) NOTE KEEP THE SPARE KEY IN DIFFERENT PLACE, NOT WITH THE VEHICLE. The ignition switch is on the front part of the fuel tank near the headstock. The vehicle is supplied with two keys (one is the spare key).

  • Page 40: Locking The Steering Wheel

    LOCK (1): The steering is locked. It is not possible to start the engine or switch on the lights. The key can be extracted OFF (2): The engine and lights cannot be set to work. The key can be extracted. ON (3): the engine may be started.

  • Page 41: Parking Lights

    Parking lights (02_38) The vehicle has front and rear parking lights. Considering that it is preferable to park the vehicle in adequate and well-lit areas, parking lights are very useful when parking the vehicle in a dark or poorly lit area and when the vehicle needs to be visible. To turn on the parking lights: •...

  • Page 42: Switch Direction Indicators

    Switch direction indicators (02_40) Move the switch to the left, to indicate a left turn; move the switch to the right to indicate a right turn. Press the switch centrally to deactivate the turn signal. CAUTION IF THE WARNING LIGHT WITH ARROWS FLASHES QUICKLY, IT MEANS THAT ONE OR BOTH TURN SIGNALS LIGHT BULBS ARE BURNT OUT.

  • Page 43: High/Low Beam Selector

    High/low beam selector (02_41) In the mode with daytime lights activated: • the light switch functions are disabled except for the high beam flasher func- tion • In the right hand position the high beam flashes in case of danger or emer- gency.

  • Page 44: Daytime/Night Lights Switch

    Daytime/night lights switch (02_43) • Directing the switch downward the rider, the night lights are activated • Directing the switch to central position turns on the high beam/low beam night lights • Directing the switch forwards activates the high beam/low beam lights and, where provided, the fog lights.

  • Page 45: Start-Up Button

    Start-up button (02_45) By pressing the button, the starter motor will crank the engine, with the motor started, the engine calibrations selector function resumes. IT IS POSSIBLE TO START THE ENGINE WITH ONLY THE HANDLE THROTTLE RELEASED OR TURNED. 02_45 Engine stop switch (02_46) It acts as a safety or emergency switch.

  • Page 46: Button Cruise Control

    Button Cruise Control (02_47, 02_48) Cruise control is an electronic system that keeps the vehicle at a constant speed se- lected by the rider. To turn the system (switching from OFF to ON state) it is required to centrally press the cruise control selector with a long press (longer than 1 second), the system power is indicated by the warning light on the dashboard in flashing mode.
  • Page 47 (24.85 mph) for the sixth gear with respect to the selected speed without turning off the system (e.g. passing). If the increase in speed exceeds 30 km/h (18.64 mph) for the third, fourth and fifth gear and 40 km/h (24.85 mph) for the sixth gear, it will cause a system deactivation (change from SET to ON, flashing light).

  • Page 48: System Abs

    System ABS (02_49) The ABS system is a device that prevents wheel locking in case of an emergency braking, thus increasing vehicle stability when braking, compared with a conventional braking system. The ABS system enhances control over the vehicle, taking into consideration never to exceed the physical limits of vehicle grip on the road.
  • Page 49 ABS is functioning. If the ABS disabled indication remains: NOTE IF THIS OCCURS, CONTACT AN OFFICIAL Moto Guzzi dealer NOTE THE ABS SYSTEM HAS BEEN DESIGNED AND DEVELOPED, CONSISTENTLY WITH THE REST OF THE VEHICLE, TO BE USED ON TARMAC ROADS AND IT IS NOT SUITABLE FOR OFF-ROAD USE.
  • Page 50 SUCH BEHAVIOUR IS TO BE CONSIDERED NORMAL AND DOES NOT CREATE MALFUNCTIONS IN THE SYSTEM. IF THE GAP FOR ONE OR BOTH SENSORS IS NOT WITHIN THE TOLERANCE INDICATED BELOW, TAKE THE MOTORCYCLE TO AN Official Moto Guzzi Deal- Characteristic Distance between tone wheel and front sensor 0.3 - 2.00 mm (0.012 - 0.079 in)

  • Page 51: Glove-Box

    Glove-box (02_50) Side panniers cover opening • Rest the vehicle on its stand. • Introduce the key (1) in the lock near the pannier cover handle (3). • Turn the key (1) anticlockwise. • Lift the handle (2), freeing the lock from the hook of the cover (3). •...

  • Page 52: Usb Port

    USB Port In the central part of the dashboard, close to the steering, is a USB socket. Lift the protective cover to use. Via the USB port using a special cable, it is possible to charge a phone battery. TO AVOID THAT WATER AND/OR HUMIDITY CAN DAMAGE THE USB PORT, USE THE PROTECTIVE COVER EVEN WHEN THERE IS A DEVICE CONNECTED.
  • Page 53 CAUTION THE MODIFICATION OF THE IDENTIFICATION CODES IS A SERIOUS PUNISH- ABLE CRIME. HOWEVER, THE LIMITED WARRANTY FOR NEW VEHICLES WILL BE VOID IF THE VEHICLE IDENTIFICATION NUMBER (VIN) HAS BEEN MODI- FIED OR NOT PROMPTLY DETERMINED. FRAME NUMBER The chassis number is stamped on the right hand side of the headstock. Chassis No.

  • Page 55: Use

    MGX-21 Chap. 03...

  • Page 56: Checks

    THE VEHICLE, FOR CORRECT AND SAFE OPERATION. FAILURE TO DO SO MAY LEAD TO SEVERE PERSONAL INJURY OR VEHICLE DAMAGE. DO NOT HESITATE TO CONTACT AN Official Moto Guzzi Dealer IF YOU DO NOT UN- DERSTAND HOW SOME CONTROLS WORK OR IF MALFUNCTIONING IS DE- TECTED OR SUSPECTED.
  • Page 57 warning lights and/or symbols are turned off. Wheels/ tyres Check that tyres are in good conditions. Check inflation pressure, tyre wear and potential damage. Centrifugal Check for proper operation. Check clutch lever free play and fluid level. Check for leaks. The clutch must work without gripping and/or slipping.

  • Page 58: Refuelling

    Tone wheels Check that the tone wheels are perfectly clean good conditions. Refuelling (03_02) To refuel: • Introduce the key (1) in the fuel tank cap lock (2). • Turn the key anticlockwise, then pull and remove the fuel cap. •...
  • Page 59 WHEN FILLING THE TANK COMPLETELY, DO NOT FILL BEYOND THE LOWER EDGE OF THE RECESS (SEE FIGURE). DURING REFUELLING AVOID FUEL LEAKAGES, WHICH MAY CAUSE DAMAGE TO THINGS OR PERSONS AND FIRE HAZARD. DURING REFUELLING, AVOID THE USE OF ELECTRIC DEVICES AND/OR MO- BILE PHONES, BECAUSE FUEL VAPOURS MAY CAUSE DAMAGE TO OBJECTS AND/OR PERSONAL INJURIES.

  • Page 60: Rear Shock Absorbers Adjustment

    10 clicks clockwise from fully open. CAUTION THE ADJUSTMENT AND PRELOAD IS REALIZED AT DISCRETION OF THE 03_03 USER. Moto Guzzi ADVISES TO KEEP THE ADJUSTMENTS DESCRIBED ABOVE. CAUTION TO PREVENT DAMAGE TO THE ADJUSTER SCREWS (1), NEVER FORCE THEM BEYOND THE END OF TRAVEL IN EITHER DIRECTION.

  • Page 61: Justering Af Greb Til Forbremse

    CAUTION IF THE FRONT BRAKE LEVER MUST BE REMOVED, CHECKED AND CHANGED 03_05 BY AN Official Moto Guzzi Dealership Rear brake pedal adjustment CAUTION FOR REMOVAL AND REPLACEMENT OF REAR BRAKE PEDAL, CONTACT AN Official Moto Guzzi Dealer...

  • Page 62: Running In

    CAUTION THE CLUTCH LEVER MUST BE REMOVED, CHECKED AND CHANGED BY AN Official Moto Guzzi Dealership Running in Running in is essential to ensure the durability of the vehicle. During the first 1,500 Km (932.06 mi), observe the following rules to ensure the reliability and performance of the vehicle throughout its lifetime: •...

  • Page 63: Starting Up The Engine

    AFTER THE SPECIFIED MILEAGE, TAKE THE VEHICLE TO AN Official Moto Guzzi Dealer FOR THE CHECKS INDICATED IN THE "AFTER RUN-IN" TABLE IN THE SCHEDULED MAINTENANCE SECTION TO AVOID INJURING YOURSELF, OTHERS AND /OR DAMAGING THE VEHICLE. Starting up the engine (03_07, 03_08) This vehicle must be used with care, prudence and respect.

  • Page 64: Moving Off / Riding

    • Get on the motorcycle, assuming the correct driving posture. • Make sure that the side stand has been fully retracted. • Operate the front or rear brake (or both). • Operate the clutch lever and make sure that the transmission is in neutral. If the transmission is in neutral, the green coloured light "N"...
  • Page 65 PASSED THE ECU WILL PREVENT STARTING FOR ANOTHER 3 SECONDS AND ONLY THEN WILL IT BE POSSIBLE TO START THE MOTORCYCLE. CAUTION WHEN TRAVELLING WITHOUT PASSENGERS, MAKE SURE THE PASSENGER FOOTRESTS ARE FOLDED UP. CAUTION PASSENGERS MUST BE SUITABLY INSTRUCTED ON HOW TO BEHAVE TO PREVENT DANGEROUS SITUATIONS WHEN RIDING.
  • Page 66 • With a closed throttle grip (Pos. A) and the engine idling, pull the clutch lever. • Push the gearbox lever (1) downward to select the first gear. • Release the clutch lever (activated during start-up). CAUTION WHEN TURNING OFF THE VEHICLE, DO NOT RELEASE THE CLUTCH TOO QUICKLY OR SUDDENLY, AS THIS COULD CAUSE THE ENGINE TO STOP OR THE VEHICLE TO REAR UP ON THE BACK WHEEL.
  • Page 67 • When riding downhill and under braking, using engine compression to in- crease braking power. • When going uphill, when the engaged gear does not suit the speed (high gear, moderate speed) and the number of engine revs falls. CAUTION DOWNSHIFT ONE GEAR AT A TIME;...

  • Page 68: Stopping The Engine

    DOWNHILL COULD CAUSE THE BRAKE PADS TO OVERHEAT, WHICH RE- DUCES BRAKING AND LIMITS BRAKING POWER. IT IS RECOMMENDED TO USE THE ENGINE COMPRESSION, DOWNSHIFTING AND USING BOTH BRAKES INTERMITTENTLY. WHEN DRIVING DOWNHILL, NEVER RIDE WITH THE ENGINE TURNED OFF. WHEN RIDING ON WET SURFACES OR SURFACES WITH POOR GRIP (SNOW, ICE, MUD, ETC.) USE MODERATE SPEED, AVOID SUDDEN BRAKING OR MA- NOEUVRES THAT MAY CAUSE TO A LOSS OF TRACTION AND POSSIBLY TO...

  • Page 69: Parking

    Parking It is very important to select an adequate parking spot, in compliance with road signals and the guidelines described below. CAUTION PARK ON SAFE AND LEVEL GROUND TO PREVENT THE VEHICLE FROM FALL- ING. DO NOT LEAN THE VEHICLE AGAINST A WALL OR LAY IT ON THE GROUND. ENSURE THAT THE VEHICLE AND, IN PARTICULAR, PARTS OF THE VEHICLE WHICH MAY BECOME HOT (ENGINE, OIL RADIATOR AND LINES, EXHAUST SYSTEM, BRAKE DISCS) ARE NOT A HAZARD TO PERSONS OR CHILDREN.
  • Page 70 If the noise produced by the exhaust system increases, get immediately in touch with the Dealer or with a Moto Guzzi authorised repair shop. NOTE DO NOT TAMPER WITH THE EXHAUST SYSTEM.

  • Page 71: Stand

    Stand (03_13, 03_14) BEFORE SETTING OFF, MAKE SURE THE STAND HAS BEEN COMPLETELY RETRACTED TO ITS POSITION. DO NOT REST THE RIDER OR PASSENGER WEIGHT ON THE SIDE STAND. THE SIDE STAND MUST ROTATE FREELY. IF NECESSARY GREASE THE JOINT. SIDE STAND If the stand has been folded up for any manoeuvre (for example, when the vehicle is in motion), place the vehicle on the stand again as follows:...

  • Page 72: Suggestion To Prevent Theft

    A safety switch is installed on the side stand to inhibit ignition or to stop the engine when a gear is engaged and the side stand is lowered. 03_14 Suggestion to prevent theft CAUTION WHEN USING A DISC LOCKING DEVICE, PAY UTMOST ATTENTION TO RE- MOVE IT BEFORE RIDING.

  • Page 73: Safe Driving

    WARNING IN MANY CASES, STOLEN VEHICLES CAN BE IDENTIFIED BY DATA IN THE USE / MAINTENANCE BOOKLET. Safe driving Some simple tips are provided below that will enable you to use your motorcycle on a daily basis in greater safety and peace of mind. Your skill and your mechanical knowledge are the basis of a safe ride.
  • Page 74 CAUTION THE VEHICLE MUST BE GUIDED BY THE EXTENT REQUIRED BY LAW. IF RID- ING THE MOTORCYCLE EQUIPPED WITH Moto Guzzi ORIGINAL ACCESSO- RIES PROVIDED FOR THE DEDICATED MODEL (INCREASED WINDSHIELD) MODERATE THE MAXIMUM SPEED WITHIN 160 km/h (99.45 mph).IN CASE OF...

  • Page 75: Basic Safety Rules

    CAUTION STOP THE VEHICLE MAINLY USING THE FRONT BRAKE. THE REAR BRAKE MUST ONLY BE USED TO BALANCE THE BRAKING EFFECT, AND ONLY TO- GETHER WITH THE FRONT BRAKE. Basic safety rules (03_15, 03_16, 03_17, 03_18, 03_19) The following recommendations should receive your maximum attention, because they are provided to increase your safety, and decrease damage to people, things and vehicles, in the case of a fall of the rider or passenger from the vehicle and/or from the fall or overturning of the vehicle.
  • Page 76 In any case, the passenger should mount and dismount the vehicle using caution to avoid causing the vehicle or the rider to lose balance. CAUTION THE RIDER TO INSTRUCT THE PASSENGER ABOUT THE PROPER WAY TO MOUNT AND DISMOUNT FROM THE VEHICLE. THE VEHICLE INCLUDES PASSENGER FOOTRESTS WHICH SHOULD BE USED DURING MOUNTING AND DISMOUNTING.
  • Page 77 MOUNTING • Grip the handlebar properly and mount the vehicle without placing your weight upon the side stand. CAUTION IN THE CASE THAT YOU ARE NOT ABLE TO REST BOTH FEET ON THE GROUND, PUT THE RIGHT FOOT ON THE GROUND, (IN THE CASE OF A LOSS OF BALANCE THE LEFT SIDE IS "PROTECTED"...
  • Page 78 • Use the heel of your left foot to completely open the side stand. CAUTION IN THE CASE THAT YOU ARE NOT ABLE TO REST BOTH FEET ON THE GROUND, PUT THE RIGHT FOOT ON THE GROUND, (IN THE CASE OF A LOSS OF BALANCE THE LEFT SIDE IS "PROTECTED"...

  • Page 79: Maintenance

    MGX-21 Chap. 04 Maintenance...

  • Page 80: Foreword

    In general terms, scheduled maintenance can be carried out by the owner; however, some operations may require specific tools and technical training. For periodic main- tenance, servicing or technical advice, contact an Official Moto Guzzi Dealer for prompt and accurate service.

  • Page 81: Engine Oil Top-Up

    THE ENGINE'S OIL LEVEL CHECK MUST BE REALIZED WITH THE ENGINE HOT OR AFTER RUNNING FOR ABOUT 15 km (9.32 mi), OUT OF TOWN (ENOUGH TO WARM UP ENGINE OIL). • Shut off the engine. • Keep the vehicle upright with both wheels on the ground. •...

  • Page 82: Engine Oil Change

    Top up oil until reaching the correct level. Engine oil change CAUTION THE ENGINE OIL MUST BE CHECKED AND CHANGED BY AN Official Moto Guzzi Dealership Engine oil filter replacement CAUTION THE ENGINE OIL FILTER MUST BE CHECKED AND CHANGED BY AN Official Moto Guzzi Dealership...

  • Page 83: Bevel Gear Pair Oil Level

    Bevel gear pair oil level CAUTION THE CARDAN OIL MUST BE CHECKED AND CHANGED BY AN Official Moto Guzzi Dealership Gearbox oil level CAUTION THE GEARBOX OIL MUST BE CHECKED AND CHANGED BY AN Official Moto Guzzi Dealership. Tyres (04_03, 04_04, 04_05) This vehicle is fitted with tyres without inner tubes (Tubeless).
  • Page 84 CAUTION CHECK TYRE INFLATION PRESSURE REGULARLY AT AMBIENT TEMPERA- TURE. THE MEASUREMENT MAY BE INCORRECT IF TYRES ARE WARM. CHECK TYRE PRESSURE MAINLY BEFORE AND AFTER A LONG TRIP. AN OVER-INFLATED TYRE WILL PROVIDE A HARSH RIDE AS SURFACE UNEVEN- NESS IS NOT CUSHIONED AND IS SENT TO THE HANDLEBAR, THUS REDUC- ING GRIP AND ROAD HOLDING SPECIALLY WHEN CORNERING.
  • Page 85 CHECK THAT THE INFLATION VALVES HAVE THEIR CAPS FITTED TO AVOID UNEXPECTED FLAT TYRES. REPLACEMENT, REPAIR, MAINTENANCE AND BALANCING OPERATIONS ARE HIGHLY IMPORTANT AND SO THEY SHOULD BE CARRIED OUT USING THE SPECIFIC TOOLS AND WITH THE ADEQUATE KNOWLEDGE. HAVE YOUR TYRES AND WHEELS SERVICED AT AN OFFICIAL DEALER OR A SPECIALISED TYRE WORKSHOP.

  • Page 86: Spark Plug Dismantlement

    Spark plug dismantlement CAUTION FOR REMOVAL, CHECK, AND REPLACEMENT OF THE SPARK PLUGS CON- TACT AN OFFICIAL Moto Guzzi Dealer. Removing the air filter CAUTION TO REMOVE, CHECK AND REPLACE THE AIR FILTER, CONTACT AN Official Moto Guzzi Dealer. Checking the brake oil level (04_06, 04_07) Front brake fluid check •...

  • Page 87: Braking System Fluid Top Up

    If the brake pads and/or brake discs do not have to be replaced, have the braking system checked at an Official Moto Guzzi Dealership. Rear brake fluid check • Keep the vehicle upright so that the fluid in the reservoir is at the same level as the plug.

  • Page 88: Checking Clutch Fluid

    Top-up if the fluid does not reach at least the "MIN" reference mark. 04_08 Topping up clutch fluid CAUTION FOR THE TOP-UP OF THE CLUTCH FLUID, CONTACT AN Official Moto Guzzi Dealer Use of a new battery (04_09, 04_10) •...

  • Page 89: Checking The Electrolyte Level

    CAUTION UPON REFITTING, CONNECT THE LEAD TO THE POSITIVE TERMINAL (+) FIRST AND AFTERWARDS THE LEAD TO THE NEGATIVE TERMINAL (-). CHECK THAT THE BATTERY LEADS AND TERMINALS ARE: • IN GOOD CONDITION (NOT CORRODED OR COVERED BY DEPOSITS); • COVERED BY NEUTRAL GREASE OR PETROLEUM JELLY.

  • Page 90: Charging The Battery

    Charging the battery • Remove the battery. • Get an adequate battery charger. • Set the battery charger for the recharge type indicated. • Connect the battery to the battery charger. CAUTION WHEN RECHARGING OR USING THE BATTERY, BE CAREFUL TO HAVE THE ROOM ADEQUATELY AIRED.

  • Page 91: Fuses

    In winter or when the vehicle is out of use for prolonged periods, check charge level frequently (about once a month) to prevent deterioration. • Recharge it fully with an ordinary charge. If the battery is still on the vehicle, disconnect the cables from the terminals. Checking and cleaning terminals and leads •...
  • Page 92 To check: • Set the ignition switch to 'OFF' to avoid an accidental short circuit. • Remove the saddle. • Remove the fuse box cover. • Take out one fuse at a time and check if the filament is broken. •...

  • Page 93: Lamps

    Secondary fuses The secondary fuses are located in the central part of the motorcycle, under the rider saddle, on the right side. 1. Low/high beam lights, brake lights, passing, fog lights (where provided), day- time running lights, hazard button lighting, horn (15 A). 2.
  • Page 94 Bulb layout In the headlamp there are: • LED daytime running lights (lateral) • one low beam headlight bulb (upper); • one high-beam headlight bulb (lower). CAUTION LOOSEN THE SCREW (1) BEFORE ACTING ON THE SCREWS (2). 04_15 Front headlamp bulb replacement •...

  • Page 95: Headlight Adjustment

    NOTE INSERT THE BULBS INTO THE BULB HOLDER, MAKING SURE THE REFER- ENCE FITTINGS MATCH. Headlight adjustment (04_18, 04_19) NOTE IN COMPLIANCE WITH LOCAL LEGAL REQUIREMENTS, SPECIFIC PROCE- DURES MUST BE FOLLOWED WHEN CHECKING LIGHT BEAM ADJUSTMENT. For a quick check of the correct direction of the front light beam: •...

  • Page 96: Front Direction Indicators

    To carry out vertical adjustment of the light beam: • Stand the motorcycle in a vertical position • Loosen the screw on the left side of the projector • Then turn the headlight until the beam is at the desired position NOTE CHECK THAT THE LIGHT BEAM VERTICAL DIRECTION IS CORRECT.

  • Page 97: Rear Optical Unit

    IF THE BULB HOLDER «4» IS STICKS OUT ITS FITTING, INSERT IT AGAIN COR- RECTLY BY MATCHING THE BULB HOLDER RADIAL OPENING WITH THE SCREW SEAT. Rear optical unit CAUTION THE REAR LIGHT UNIT MUST BE CHECKED AND CHANGED BY AN Official Moto Guzzi Dealership...

  • Page 98: Rear Turn Indicators

    Rear turn indicators CAUTION FOR DISASSEMBLY, VERIFICATION AND REPLACEMENT OF REAR INDICA- TORS PLEASE CONTACT AN Official Moto Guzzi Dealership Number plate light CAUTION THE LICENCE PLATE LIGHT MUST BE REMOVED, CHECKED AND CHANGED BY AN Official Moto Guzzi Dealership Rear-view mirrors (04_22, 04_23) DO NOT RIDE WITH REAR-VIEW MIRRORS INCORRECTLY SET.

  • Page 99: Front And Rear Disc Brake

    Rear-view mirrors removal: • Rest the vehicle on its stand • Loosen the locking nut • Slide up and remove the complete rear-view mirror unit Repeat the procedure to remove the other rear-view mirror, if necessary. UPON REFITTING AND BEFORE TIGHTENING THE LOCKING NUT, MAKE SURE 04_22 THAT THE REAR VIEW MIRROR SUPPORT STEM IS ALIGNED WITH THE HAN- DLEBAR.
  • Page 100 REPLACE DIRTY PADS AND CLEAN AGAIN THE DIRTY DISC USING A TOP QUALITY DEGREASING PRODUCT. CAUTION TAKE YOUR VEHICLE TO AN Official Moto Guzzi Dealer TO HAVE THE FRONT WHEEL REMOVED. CAUTION CHECK BRAKE PADS FOR WEAR MAINLY BEFORE EACH RIDE.

  • Page 101: Periods Of Inactivity

    If the friction material thickness (even of one front or rear pad) is reduced to a value of about 1.5 mm (0.059 in) (or even if one of the wear indicators is not very visible), contact an Official Moto Guzzi Dealer to replace all the brake callipers. 04_25 Periods of inactivity (04_26) Take some measures to avoid the side effects of not using the scooter.
  • Page 102 Cover the vehicle but do not use plastic or waterproof materials. CAUTION TO AVOID BATTERY DETERIORATION, FOLLOW THE PROCEDURE DESCRI- BED FOR PROLONGED INACTIVITY. 04_26 AFTER STORAGE NOTE TAKE THE PLASTIC BAGS OFF THE EXHAUST PIPE OPENING. • Uncover and clean the vehicle. •...

  • Page 103: Cleaning The Vehicle

    Cleaning the vehicle (04_27, 04_28) Moto Guzzi recommends using quality products for cleaning the vehicle. The use of unsuitable products can damage vehicle components. For cleaning do not use sol- vents such as "nitro thinner", "cold cleaning agents", or similar fuels, or cleaning products that contain alcohol.
  • Page 104 To keep the motorcycle bright, wash it regularly, especially if used in areas with high levels of pollution or mud. Aggressive stains from tree resins, gasoline, oil, brake fluid or bird excrement in general. must be removed immediately, otherwise permanent stains on the paint can appear. After washing is easy to identify marks and residual stains, remove these from the bodywork using a soft cloth, of a non-abrasive polish brand.
  • Page 105 TO CLEAN THE HEADLIGHTS USE A SPONGE SOAKED IN WATER AND MILD DETERGENT, RUBBING THE SURFACE GENTLY AND RINSING FREQUENTLY WITH PLENTY OF WATER. DO NOT POLISH MATT-PAINTED SURFACES WITH POLISHING PASTE. THE VEHICLE SHOULD NEVER BE WASHED IN DIRECT SUNLIGHT, ESPECIALLY DURING SUMMER, OR WITH THE BODYWORK STILL HOT AS THE CAR SHAMPOO CAN DAMAGE THE PAINTWORK IF IT DRIES BE- FORE BEING RINSED OFF.
  • Page 106 Clean the rubber parts using water and mild shampoo (brand-name, suitable for car bodies) THE USE OF SILICONE SPRAY TO CLEAN THE RUBBER SEALS MAY CAUSE DAMAGE. DO NOT USE OTHER PRODUCTS CONTAINING SILICON FOR CLEANING THE MOTORCYCLE Clean the motorcycle frequently if exposed to adverse conditions, such as: •...
  • Page 107 CAUTION BEFORE WASHING THE WINDSCREEN, SOFTEN THE DIRT WITH WATER. THEN CLEAN THE INSTRUMENT PANEL WITH A SOFT CLOTH MOISTENED WITH WATER. CAUTION AFTER CLEANING YOUR MOTORCYCLE, BRAKING EFFICIENCY MAY BE TEM- PORARILY AFFECTED DUE TO THE PRESENCE OF WATER ON THE FRICTION SURFACES OF THE BRAKING CIRCUIT.
  • Page 108 CAUTION DO NOT USE WATER (OR LIQUIDS) AT TEMPERATURES OVER 40°C (104°F) WHEN CLEANING THE VEHICLE PLASTIC PARTS. DO NOT AIM HIGH PRES- SURE AIR/WATER JETS OR STEAM JETS DIRECTLY ON THESE COMPO- NENTS. DO NOT USE ALCOHOL OR SOLVENTS TO CLEAN ANY RUBBER OR PLASTIC SADDLE COMPONENTS USE WATER AND MILD SOAP.

  • Page 109: Transport

    Transport (04_29) NOTE BEFORE TRANSPORTING THE VEHICLE, IT IS NECESSARY TO EMPTY THE FUEL TANK ADEQUATELY, CHECKING THAT THEY ARE DRY. DURING TRANSPORT, THE VEHICLE SHOULD BE UPRIGHT AND SECURELY ANCHORED AND SHOULD HAVE THE FIRST GEAR ENGAGED SO AS TO AVOID 04_29 POSSIBLE FUEL, OIL OR COOLANT LEAKS.

  • Page 111: Technical Data

    MGX-21 Chap. 05 Technical data...
  • Page 112 WEIGHT AND DIMENSIONS Max. length 2,560 mm (100.79 in) Maximum width at handlebar 920 mm (36.22 in) Maximum height 1,275 mm (50.20 in) Maximum high with accessories 1,390 mm (54.72 in) Wheelbase 1,700 mm (66.93 in) Kerb weight 356 kg (784.84 lb) ENGINE Type traverse-mounted...
  • Page 113 Centrifugal hydraulically controlled single- plate dry clutch with incorporated flexible coupling Lubrication Pressure-fed, controlled by valves and trochoidal pump Air filter cartridge-type dry filter Water cooling, air and oil cooled with independent trochoidal pump and oil pressure control valve Timing diagram single overhead camshaft with roller tappets and rocker-operated valves...
  • Page 114 Engine oil change filter replacement: 4,010 cm³ (244.71 cu Gearbox oil 430 cm³ (26.24 cu in) in case of replacement Gearbox oil 500 cm³ (30.51 cu in) in case of overhaul Transmission oil 250 cm³ (15.26 cu in) Seats Maximum carrying load 551 kg (1,214.75 lb) (rider + passenger + luggage) TRANSMISSION...
  • Page 115 Final drive with cardan shaft and bevel gear, ratio: 10/36 / = 1 :3.600 FUEL SYSTEM Fuel system Electronic injection Marelli (IAW 7SM2) Venturi diameter: 52 mm (2.05 in) Fuel Unleaded petrol max E10 (95 RON) CHASSIS Type Tubular made of steel, closed double cradle, with elastokinematic engine mounting system for vibration isolation.
  • Page 116 SUSPENSIONS Front 44.8 mm (1.76 in) diameter hydraulic telescopic fork with radial brake calliper mounting bracket. Front wheel travel 107.7 mm (4.24 in) Rear Swingarm with dual shock absorbers adjustable in the preload spring Rear wheel travel 116 mm (4.57 in) BRAKES Front Ø...
  • Page 117 Front wheel 3,50"x 21" Rear wheel 5.50" x 16" TYRES Tyres Dunlop Elite 3 Front 120/70 R21 62V Inflation pressure (front) 2.5 bar (250 Kpa) (36.3 PSI) Inflation pressure with passenger 2.5 bar (250 Kpa) (36.3 PSI) (front) Rear 180/60 R16 80H Inflation pressure (rear) 2.7 bar (270 Kpa) (39.2 PSI) Inflation pressure with passenger...
  • Page 118 ELECTRICAL SYSTEM Battery YTX20-BS 12 V - 18 Ah Alternator (permanent magnet 12 V - 550 W type) Main fuses 40- 30- 10A Secondary fuses 15 (4) - 10 - 20 - 7.5 A Front daylight running lights (Halogen) low beam light 12V - 55W / H3 (Halogen) high beam light 12V - 55W / H7...
  • Page 119 Fuel reserve warning light High beam warning light Neutral gear warning light General alarm warning lamp MI warning light Stored radio stations indicator light LED USB indicator light Bluetooth indicator light...

  • Page 121: Programmed Maintenance

    MGX-21 Chap. 06 Programmed maintenance...

  • Page 122: Scheduled Maintenance Table

    Correct maintenance is fundamental for ensuring the longevity of your vehicle and maintaining optimum function and performance. For this purpose, Moto Guzzi has formulated a series of checks and scheduled serv- ices (at the owner's expense), are summarised in the table given in the following page.
  • Page 123 (6) Lubricate if you are riding in the rain, on wet roads or after the vehicle has been washed. (7) Replace at whichever of the following occurs first: 40,000 km (24,854 mi) or 4 years SCHEDULED MAINTENANCE TABLE km x 1,000 (mi x 1,000) (0.9) (6.2) (12.4)
  • Page 124 km x 1,000 (mi x 1,000) (0.9) (6.2) (12.4) (18.6) (24.9) (31.1) (37.3) (43.5) (49.7) Clutch fluid (2) Gearbox oil Fork oil (7) Engine oil Final drive oil Clutch lever pin (6) Tyres - pressure / wear (1) Valve clearance adjustment Wheels Bolts and nuts tightening Battery terminals tightening...

  • Page 125: Table Of Recommended Products

    Table of recommended products (06_02) Piaggio & C. S.p.A. prescribes eni products for the scheduled maintenance of its vehicles 06_02 ECOMMENDED PRODUCTS TABLE Product Description Specifications ENI i-RIDE PG RACING 10W-60 Engine oil SAE 10W - 60. As an alternative for recommended oils, top-branded oils that meet or exceed the requirements of CCMC G-4 A.P.I.

  • Page 127: Special Fittings

    MGX-21 Chap. 07 Special fittings...

  • Page 128: Accessories Index

    Accessories index For this vehicle, dedicated accessories and clothing are available. For additional info please refer to your dealer or visit our site: www.motoguzzi.it...
  • Page 129 TABLE OF CONTENTS Start-up: 45 Stop switch: 45 ABS: 48 Engine oil: 10, 80–82 Maintenance: 79, 121, 122 Accessories: 128 Engine stop: 45 Maintenance Table: 122 Advanced functions: 32 Mirrors: 98 Air filter: 86 Technical data: 111 Alarms: 27 Turn indicators: 98 Fork: 60 Tyres: 83 Fuel: 8...
  • Page 130 The reliability of the vehicle also depends on its mechanical conditions. Checking the vehicle before riding it, its regular maintenance and the use of original Moto Guzzi spare parts only are essential...

Table of Contents
