Sez. 0 - INTRODUZIONE
manuale utente MGS corsa - pag 0-1

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MGS-01 2010 and is the answer not in the manual?

Questions and answers

Summary of Contents for MOTO GUZZI MGS-01 2010

  • Page 1 Sez. 0 - INTRODUZIONE manuale utente MGS corsa - pag 0-1...
  • Page 2 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten INDICE 0.1. INTRODUZIONE..............................3 0.1.1. PREMESSA............................. 3 0.1.2. ABBREVIAZIONI / SIMBOLI / SIGLE...................... 4 manuale utente MGS corsa - pag 0-2...
  • Page 3 Moto Guzzi ha realizzato questo manuale prestando la massima attenzione alla correttezza e attualità delle informazioni fornite. Tuttavia, in considerazione del fatto che i prodotti Moto Guzzi sono soggetti a continue migliorie di progettazione, potrebbero esserci leggere differenze tra le caratteristiche del veicolo in vostro possesso e quelle descritte nel presente manuale.
  • Page 4 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 0.1.2 ABBREVIAZIONI / SIMBOLI / SIGLE = numero < = minore di > = maggiore di = uguale o minore di = uguale o maggiore di = circa ∞...
  • Page 5 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten = punto morto superiore = dispositivo pneumatico che agisce sulla frizione (Pneumatic Power Clutch) RIGHT SIDE = lato destro = ente automobilistico americano (Society of Automotive Engineers) = Sistema Aria Secondaria TEST = controllo diagnostico...
  • Page 6 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 7 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sez. 1 - INFORMAZIONI GENERALI manuale utente MGS corsa - pag 1-1...
  • Page 8: Table Of Contents

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten INDICE 1.1. STRUTTURA ............................... 3 1.1.1. NORME PER LA CONSULTAZIONE...................... 3 1.1.2. MESSAGGI DI SICUREZZA ........................4 1.1.3. REGOLE GENERALI DI SICUREZZA ....................5 1.1.4. ELEMENTI PERICOLOSI........................
  • Page 9: Struttura

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1. STRUTTURA 1.1.1 NORME PER LA CONSULTAZIONE • Questo manuale è suddiviso in sezioni e capitoli, per ognuno dei quali corrisponde una categoria di componenti principali.
  • Page 10: Messaggi Di Sicurezza

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1.2 MESSAGGI DI SICUREZZA I seguenti messaggi di segnalazione vengono usati in tutto il manuale per indicare quanto segue: Simbolo di avviso relativo alla sicurezza. Quando questo simbolo è presente sul veicolo o nel manuale, fare attenzione ai potenziali rischi di lesioni.
  • Page 11: Regole Generali Di Sicurezza

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1.3 REGOLE GENERALI DI SICUREZZA OSSIDO DI CARBONIO Se è necessario far funzionare il motore per poter effettuare qualche operazione, assicurarsi che questo avvenga in uno spazio aperto o in un locale ben ventilato.
  • Page 12 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten GAS IDROGENO ED ELETTROLITO BATTERIA PERICOLO L'elettrolita della batteria è tossico, caustico e a contatto con l'epidermide può causare ustioni, in quanto contiene acido solforico. Indossare guanti ben aderenti e abbigliamento protettivo quando si maneggia l'elettrolito della batteria.
  • Page 13 Non utilizzare aria compressa per la pulizia dei cuscinetti. IMPORTANTE I cuscinetti devono ruotare liberamente, senza impuntamenti e/o rumorosità, altrimenti devono essere sostituiti. Utilizzare esclusivamente RICAMBI ORIGINALI Moto Guzzi. Attenersi all'impiego dei lubrificanti e del materiale di consumo consigliato. Lubrificare le parti (quando è possibile) prima di rimontarle.
  • Page 14: Elementi Pericolosi

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1.4 ELEMENTI PERICOLOSI CARBURANTE PERICOLO Il carburante utilizzato per la propulsione dei motori a scoppio è estremamente infiammabile e può divenire esplosivo in determinate condizioni. È...
  • Page 15 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten OLIO FORCELLA PERICOLO Modificando la taratura dei dispositivi smorzanti e/o la viscosità dell'olio in essi contenuto, è possibile variare parzialmente la risposta della sospensione. Viscosità olio standard: SAE 5 W. Le gradazioni di viscosità...
  • Page 16 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten FRENI A DISCO PERICOLO I freni sono il dispositivo di sicurezza più importante del veicolo. Per garantire la vostra sicurezza personale, devono essere in condizioni perfette, quindi vanno sempre controllati prima della partenza.
  • Page 17: Rodaggio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1.5 RODAGGIO Il rodaggio del motore è fondamentale per garantirne la successiva durata e il corretto funzionamento. Attenersi alle seguenti indicazioni: • Scaldare il motore fino allo spegnimento della spia blu (1) sul cruscotto che indica il superamento dei 50° C (122° •...
  • Page 18 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 19 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sez. 2 - INFORMAZIONI TECNICHE manuale utente MGS corsa - pag 2-1...
  • Page 20 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten INDICE 2.1. CARATTERISTICHE ............................3 2.1.1. DATI TECNICI ............................3 2.1.2. SCHEDA DI MANUTENZIONE PERIODICA ..................6 2.1.3. TABELLA LUBRIFICANTI ........................9 2.1.4. COPPIE DI SERRAGGIO........................10 2.2.
  • Page 21: Caratteristiche

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.1. CARATTERISTICHE 2.1.1 DATI TECNICI MOTORE - TRASMISSIONE MOTORE Tipo bicilindrico a quattro tempi Numero cilindri Disposizione cilindri a V di 90° Pistoni con 2 fasce ed 1 raschia olio Bielle Carillo 144 mm (5.67 in) Alesaggio...
  • Page 22 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TRASMISSIONE - frizione Sinterizzata bidisco a secco con con comando idraulico - trasmissione primaria Ingranaggi a denti dritti, rapporto: 20/31 = 1:1,55 - cambio a sei rapporti - rapporti cambio: 1a marcia 15/36 = 1:10,822...
  • Page 23 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten PNEUMATICI Ruota Marca Modello Misura Mescola Pressione bar (PSI) Anteriore MICHELIN PILOT 120/60-17 "S1246A 2,1 (30.5) Posteriore MICHELIN PILOT 180/67-17 "S1835A 1.9 (27.6) Anteriore DUNLOP KR106 120/75-17 "587...
  • Page 24: Scheda Di Manutenzione Periodica

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.1.2 SCHEDA DI MANUTENZIONE PERIODICA IMPORTANTE: IN OCCASIONE DEL PRIMO UTILIZZO DEL VEICOLO, A MOTORE ANCORA SPENTO, VERIFICARE IL LIVELLO DEI LIQUIDI: liquido freni , vedi 3.1.1 (LIQUIDO FRENI); liquido frizione, vedi 3.1.2 (LIQUIDO FRIZIONE);...
  • Page 25 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Percorrenze progressive Km (mi) Note Motore Sedi valvole R "R" smerigliatura ad ogni controllo Guide valvola R "R" controllo dimensionale Verifica strutturale "R" il particolare deve risultare esente da testa cricche Alberi a camme...
  • Page 26 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Percorrenze progressive Km (mi) Note Frizione Liquido impianto Asta comando "R" verifica usura frizione R "R" Controllo spessori Dischi frizione Cambio Olio cambio Rinvio primario "R"...
  • Page 27: Tabella Lubrificanti

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.1.3 TABELLA LUBRIFICANTI LUBRIFICANTE PRODOTTO Olio motore CONSIGLIATO: RACING 4T 5 W 40 In alternativa agli oli consigliati, si possono utilizzare oli di marca con prestazioni conformi o superiori alle specifiche CCMC G-4 A.P.I.
  • Page 28: Coppie Di Serraggio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.1.4 COPPIE DI SERRAGGIO ATTENZIONE Gli elementi di fissaggio riportati nella tabella devono essere serrati alla coppia prescritta utilizzando ® una chiave dinamometrica e usando LOCTITE dove indicato.Tutte le coppie indicate rappresentano il valore nominale.
  • Page 29 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Coppia Descrizione Q.tà Misura Note Nm (ftlb) Fissaggio motore al telaio Vite attacco anteriore M12x1,75 80 (59.0) Vite attacco sopra cambio M10x1,5 50 (36.9) Vite attacco asta di reazione al telaio M14x2 120 (88.5) Attacco prigionieri cambio / telaio...
  • Page 30 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Coppia Descrizione Q.tà Misura Note Nm (ftlb) IMPIANTI FRENANTI Impianto anteriore Vite fissaggio pinza freno destra e sinistra M10x1,25 50 (36.9) Vite fissaggio disco freno M8x1,25 30 (22.1) L243...
  • Page 31 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten ATTENZIONE ® Evitare di mettere olio sul filetto dove è prescritto un montaggio con Loctite • Avvitare il tubo sul nipplo. • Avvitare a mano fino a battuta il raccordo. •...
  • Page 32: Strumentazioni

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.2. STRUMENTAZIONI 2.2.1 COMANDI SUL SEMIMANUBRIO DESTRO INTERRUTTORE ARRESTO MOTORE ( ) (1) ATTENZIONE Non intervenire sull'interruttore di arresto motore " " durante la marcia. Ha la funzione di interruttore di sicurezza o emergenza.Con l'interruttore in posizione "...
  • Page 33 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Azionare completamente la leva frizione (3) e posizionare la leva comando cambio in folle (4). • Premendo il pulsante " " (2), il motorino di avviamento fa girare il motore. manuale utente MGS corsa - pag 2-15...
  • Page 34: Cruscotto

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.2.2 CRUSCOTTO Questo computer multifunzione è un sistema di interfaccia dati ad elevate prestazioni studiato per le competizioni; è composto da un display multifunzione, sei spie e due pulsanti. Legenda: DESCRIZIONE FUNZIONE...
  • Page 35 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten CONFIGURAZIONI All'avviamento del motore il cruscotto, dopo un messaggio di accensione, fornisce i dati di configurazione standard (warm up); in alternativa si possono scegliere altre due configurazioni alternative (practice e race) cliccando sul tasto (1).
  • Page 36 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Configurazione race: 11 Velocità 12 Pressione olio motore 13 Temperatura olio motore 14 Lap 15 Tensione batteria IMPORTANTE Il cruscotto è settato per poter visualizzare nel campo (14) il tempo di un giro di pista tramite l'apposito dispositivo ( VISUALIZZAZIONE ODO/TRIP All'avviamento del motore il cruscotto, dopo un messaggio di accensione, fornisce i dati di configurazione;...
  • Page 37 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Dalla visualizzazione ODO/TRIP, cliccando il tasto (1) per meno di cinque secondi si passa dalla schermata di contachilometri parziali (TRIP) e totali (ODO) a quella di contamiglia parziali (TRIP) e totali (ODO) e viceversa. Per azzerare il valore del contachilometri/contamiglia parziale (TRIP), entrare nella visualizzazione ODO/TRIP e premere il tasto (1) per più...
  • Page 38 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 39 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sez. 3 - USO E MANUTENZIONE manuale utente MGS corsa - pag 3-1...
  • Page 40 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten INDICE 3.1. LIVELLI ................................3 3.1.1. LIQUIDO FRENI ............................3 3.1.2. LIQUIDO FRIZIONE ..........................8 3.1.3. OLIO CAMBIO............................10 3.1.4. OLIO TRASMISSIONE.......................... 11 3.1.5. OLIO MOTORE ............................. 12 3.1.6.
  • Page 41: Livelli

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1. LIVELLI 3.1.1 LIQUIDO FRENI RACCOMANDAZIONI IMPORTANTE Questo veicolo è dotato di freni a disco anteriore e posteriore, con circuiti idraulici separati. Le seguenti informazioni sono riferite a un singolo impianto frenante, ma sono valide per entrambi. PERICOLO Improvvise variazioni del gioco o una resistenza elastica sulla leva del freno, sono dovute a inconvenienti all'impianto idraulico.
  • Page 42 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Il serbatoio liquido freno anteriore è situato in prossimità dell'attacco leva freno anteriore. Il serbatoio liquido freno posteriore è situato in prossimità della leva freno posteriore. manuale utente MGS corsa - pag 3-4...
  • Page 43 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten FRENO ANTERIORE CONTROLLO • Posizionare il veicolo in verticale e mantenere il manubrio dritto. • Verificare che il liquido contenuto nel serbatoio superi il riferimento "MIN". MAX = livello massimo MIN = livello minimo Se il liquido non raggiunge almeno il riferimento "MIN":...
  • Page 44 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Sollevare e rimuovere il coperchio (3) completo di viti (1) e guarnizione (4). ATTENZIONE Per non spandere il liquido dei freni durante il rabbocco, si raccomanda di non scuotere il veicolo. Non aggiungere additivi o altre sostanze al liquido.
  • Page 45 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten FRENO POSTERIORE CONTROLLO • Tenere il veicolo in posizione verticale in modo che il liquido contenuto nel serbatoio (6) sia parallelo al tappo (5). • Verificare che il liquido contenuto nel serbatoio superi il riferimento "MIN".
  • Page 46: Liquido Frizione

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.2 LIQUIDO FRIZIONE RACCOMANDAZIONI IMPORTANTE Questo veicolo è dotato di comando frizione di tipo idraulico. ATTENZIONE Improvvise variazioni del gioco o una resistenza elastica sulla leva, sono dovute a inconvenienti all'impianto idraulico.
  • Page 47 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten RABBOCCO ATTENZIONE Pericolo di fuoriuscita liquido. Non azionare la leva comando frizione con il tappo serbatoio liquido frizione (2) allentato o rimosso. PERICOLO Evitare l'esposizione prolungata del liquido comando frizione all'aria. Il liquido comando frizione è...
  • Page 48: Olio Cambio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.3 OLIO CAMBIO CONTROLLO E RABBOCCO ATTENZIONE Il controllo del livello olio cambio deve essere fatto a motore caldo. IMPORTANTE Per riscaldare il motore e portare l'olio in temperatura d'esercizio, non lasciare il motore al minimo dei giri con veicolo fermo.
  • Page 49: Olio Trasmissione

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.4 OLIO TRASMISSIONE CONTROLLO E RABBOCCO • Tenere il veicolo in posizione verticale con le due ruote appoggiate al suolo. • Svitare e togliere il tappo di livello (1). •...
  • Page 50: Olio Motore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.5 OLIO MOTORE CONTROLLO E RABBOCCO ATTENZIONE Il controllo del livello olio motore deve essere fatto a motore caldo. IMPORTANTE Per riscaldare il motore e portare l'olio motore in temperatura d'esercizio, non lasciare il motore al minimo dei giri con veicolo fermo.
  • Page 51: Carburante

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.6 CARBURANTE PERICOLO Il carburante utilizzato per la propulsione dei motori a scoppio è estremamente infiammabile e può divenire esplosivo in determinate condizioni. È opportuno effettuare il rifornimento e le operazioni di manutenzione in una zona ventilata e a motore spento.
  • Page 52: Regolazioni

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2. REGOLAZIONI 3.2.1 TENSIONE CAVI ACCELERATORE La corsa a vuoto della manopola dell'acceleratore deve essere di 2 ÷ 3 mm (0.079 - 0.118 in), misurata sul bordo della manopola stessa.
  • Page 53: Regolazione Leva Comando Freno Anteriore E Leva Comando Frizione

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.2 REGOLAZIONE LEVA COMANDO FRENO ANTERIORE E LEVA COMANDO FRIZIONE IMPORTANTE Le seguenti operazioni si riferiscono ad una sola leva ma sono valide per entrambe. É...
  • Page 54: Regolazione Leva Comando Cambio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.3 REGOLAZIONE LEVA COMANDO CAMBIO La leva comando cambio è posizionata ergonomicamente in fase di assemblaggio del veicolo. Se necessario è possibile personalizzare la posizione della leva: •...
  • Page 55 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten REGOLAZIONE ALTEZZA PEDANA (6) È possibile personalizzare l'altezza della pedana (6) scegliendo tra tre posizioni. Per fare ciò procedere come segue: • Svitare e togliere le due viti (7). •...
  • Page 56 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Svitare e togliere la vite (10). • Spostare la pedana completa di pedale (6) in uno dei tre fori della staffa, modificando in questo modo l'altezza delle pedana (6).
  • Page 57 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Serrare le due viti (7). IMPORTANTE Prima di utlizzare il veicolo controllare la stabilità e la posizione della pedana (6). INVERSIONE INSERIMENTO MARCE PERICOLO L'inserimento delle marce nel cambio installato, per le caratteristiche sportive e per l'uso a cui questo veicolo è...
  • Page 58 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Ruotare il rinvio cambio (12) e inserirlo sull'albero selettore cambio invertendo, in questo modo, il verso di inserimento delle marce. • Serrare la vite (11). manuale utente MGS corsa - pag 3-20...
  • Page 59: Regolazione Leva Freno Posteriore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.4 REGOLAZIONE LEVA FRENO POSTERIORE La leva freno posteriore è posizionata ergonomicamente in fase di assemblaggio del veicolo. Se necessario è possibile personalizzare la posizione della leva: •...
  • Page 60: Regolazione Forcella Anteriore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.5 REGOLAZIONE FORCELLA ANTERIORE La sospensione anteriore è composta da una forcella idraulica collegata tramite due piastre al cannotto dello sterzo. Per l'impostazione dell'assetto del veicolo, ogni stelo della forcella è provvisto di una vite superiore (1) per la regolazione della frenatura idraulica in estensione, una inferiore (2) per la regolazione della frenatura idraulica in compressione e di un dado superiore (3) per la regolazione del precarico della molla.
  • Page 61 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten La prima operazione da eseguire è il settaggio del cedimento (∆) dell'anteriore in funzione del peso del pilota e del tipo di gomme impiegate. Per cedimento (∆) si intende la differenze statica tra le misure di massima estensione della sospensione senza pilota (4) e l'estensione della sospensione con il pilota in assetto di guida (5).
  • Page 62: Regolazione Ammortizzatore Di Sterzo

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.6 REGOLAZIONE AMMORTIZZATORE DI STERZO L'ammortizzatore di sterzo regolabile è provvisto di un pomello (1) per la regolazione della frenatura idraulica. Per la regolazione: • Ruotare il manubrio completamente verso sinistra.
  • Page 63: Regolazione Ammortizzatore Posteriore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.7 REGOLAZIONE AMMORTIZZATORE POSTERIORE La sospensione posteriore è composta da un gruppo molla-ammortizzatore, collegato tramite uni-ball al telaio e tramite i leverismi al forcellone posteriore. Per regolare l'impostazione, l'ammortizzatore è...
  • Page 64 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten La prima operazione da eseguire è il settaggio del cedimento (∆) del posteriore in funzione del peso del pilota e del tipo di gomme impiegate. Per cedimento (∆) si intende la differenze statica tra le misure di massima estensione della sospensione senza pilota (5) e l'estensione della sospensione con il pilota in assetto di guida (6).
  • Page 65 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten da tutto chiuso da tutto chiuso 1.9 bar 29 mm 33 mm Michelin PILOT 180/67-17” S1835A svitare 28 – 32 svitare 5 - 9 (27.6 PSI) (1.14 in) (1.30 in) scatti...
  • Page 66: Regolazione Giuoco Punterie

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.8 REGOLAZIONE GIUOCO PUNTERIE Quando la distribuzione risulta molto rumorosa, controllare il giuoco tra valvole e bilancieri. IMPORTANTE La registrazione va effettuata a motore freddo, con il pistone al punto morto superiore (P.M.S.) in fase di compressione (valvole chiuse).
  • Page 67: Regolazione Tensione Cinghie Distribuzione

    PERICOLO Le operazioni per la regolazione del tensionamento delle cinghie distribuzione potrebbero presentarsi difficoltose e complesse all'operatore inesperto. In caso di necessità, rivolgersi a un Concessionario Ufficiale Moto Guzzi. Volendo comunque procedere personalmente, attenersi alle seguenti istruzioni. ATTENZIONE Attendere fino a che il motore e l'impianto di scarico si sono raffreddati.
  • Page 68 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Rimuovere i due coperchi cinghie. IMPORTANTE Le seguenti operazioni si riferiscono al tensionamento di una sola cinghia di distribuzione ma sono valide per entrambe. Il tensionamento delle cinghie di distribuzione deve sempre essere effettuato con il pistone in posizione di P.M.S.
  • Page 69: Regolazioni Per Uso Con Pioggia

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.10 REGOLAZIONI PER USO CON PIOGGIA In caso di pioggia, per il corretto funzionamento del veicolo, è necessario effettuare le seguenti operazioni: • Svitare e togliere la vite (1). •...
  • Page 70: Spurghi

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.3. SPURGHI 3.3.1 SPURGO FRENO ANTERIORE L'aria, se presente nell'impianto idraulico, agisce da cuscinetto, assorbendo gran parte della pressione esercitata dalla pompa freni e riducendo l'efficacia della pinza in frenata. La presenza dell'aria si manifesta con la "spugnosità"...
  • Page 71 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Togliere il cappuccio di protezione in gomma della valvola di spurgo (1). • Infilare un tubetto in plastica trasparente sulla valvola di spurgo (1) della pinza freno anteriore e infilare l'altra estremità...
  • Page 72: Spurgo Freno Posteriore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.3.2 SPURGO FRENO POSTERIORE L'aria, se presente nell'impianto idraulico, agisce da cuscinetto, assorbendo gran parte della pressione esercitata dalla pompa freni e riducendo l'efficacia della pinza in frenata. La presenza dell'aria si manifesta con la "spugnosità"...
  • Page 73 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Prima di procedere, assicurarsi che sussistano tutte le seguenti condizioni: La pompa deve essere in posizione più alta rispetto all'intero tubo olio e alla pinza; Il serbatoio del liquido sia in posizione più...
  • Page 74: Spurgo Frizione

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.3.3 SPURGO FRIZIONE La presenza dell'aria si manifesta con la "spugnosità" della leva frizione. PERICOLO Il liquido frizione potrebbe causare irritazioni se venisse a contatto con la pelle o con gli occhi. Lavare accuratamente le parti del corpo che venissero a contatto con il liquido, inoltre rivolgersi a un oculista oppure a un medico se il liquido venisse a contatto con gli occhi.
  • Page 75 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten SPURGO POMPA FRIZIONE • Infilare un tubetto in plastica trasparente sulla valvola di spurgo (1) della pompa frizione e infilare l'altra estremità del tubetto in un recipiente di raccolta. •...
  • Page 76 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 77 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sez. 4 - TELAIO manuale utente MGS corsa - pag 4-1...
  • Page 78 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten INDICE 4.1. CICLISTICA ................................ 3 4.1.1. RUOTA ANTERIORE ..........................3 4.1.2. RUOTA POSTERIORE ........................... 6 4.1.3. CARENATURA............................11 4.1.4. PARACOPPA ............................14 4.1.5. SUPPORTO BATTERIA........................16 4.1.6.
  • Page 79: Ciclistica

    In caso di necessità, rivolgersi a un Concessionario Ufficiale Moto Guzzi. Volendo comunque procedere personalmente, attenersi alle seguenti istruzioni: nello smontaggio e nel rimontaggio porre attenzione a non danneggiare le tubazioni, i dischi e le pastiglie dei freni.
  • Page 80 Non azionare la leva del freno dopo aver rimosso la pinza freno, altrimenti i pistoncini della stessa potrebbero fuoriuscire dalle sedi, causando la perdita del liquido freni. Se dovesse accadere rivolgersi a un Concessionario Ufficiale Moto Guzzi, che provvederà ad effettuare un intervento di manutenzione. •...
  • Page 81 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Spingere il perno ruota (4) agendo, con cautela, sull'estremità filettata e utilizzando un martello in gomma se necessario. • Sostenere la ruota anteriore e sfilare manualmente il perno ruota . •...
  • Page 82: Ruota Posteriore

    Le operazioni per lo smontaggio e rimontaggio della ruota posteriore potrebbero presentarsi difficoltose e complesse all'operatore inesperto. In caso di necessità, rivolgersi a un Concessionario Ufficiale Moto Guzzi. Volendo comunque procedere personalmente, attenersi alle seguenti istruzioni. Nello smontaggio e nel rimontaggio porre attenzione a non danneggiare le tubazioni, i dischi e le pastiglie dei freni.
  • Page 83 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Operando dal lato sinistro, svitare e rimuovere il dado del perno ruota posteriore, recuperando al relativa rondella. • Operando dal lato destro, rimuovere il perno ruota posteriore. ATTENZIONE Una volta rimosso il perno, la ruota posteriore e la pinza freno posteriore vanno sostenuti per evitare che l'eventuale caduta li danneggi.
  • Page 84 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Agevolare l'operazione effettuando piccoli spostamenti della ruota posteriore, sfilare la pinza freno ruotandola verso il basso. ATTENZIONE Durante il rimontaggio della pinza, inserire correttamente l'incavo (1) ricavato sulla piastra portapinza (2) sul perno di aggancio (3) ricavato all'interno del forcellone.
  • Page 85 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Sostenendo la scatola di trasmissione, rimuovere la ruota. ATTENZIONE Durante il rimontaggio della ruota, allineare con precisione la tacca presente sull'albero di trasmissione (4) con quella presente sul giunto posteriore (5). manuale utente MGS corsa - pag 4-9...
  • Page 86 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Separare la scatola di trasmissione dalla ruota. manuale utente MGS corsa - pag 4-10...
  • Page 87: Carenatura

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 4.2.3 CARENATURA PERICOLO Pericolo di incendio. Attendere il completo raffreddamento del motore e del silenziatore di scarico. I vapori di carburante sono nocivi alla salute. Assicurarsi, prima di procedere, che il locale in cui si opera abbia un adeguato ricambio d'aria.
  • Page 88 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Rimuovere lo sgancio rapido sul codone. • Operando da entrambi i lati, svitare e rimuovere la vite. manuale utente MGS corsa - pag 4-12...
  • Page 89 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Operando da entrambi i lati, svitare e rimuovere la vite posta sotto il codone. • Afferrare saldamente la carenatura dal foro del tappo carburante e dal codone. •...
  • Page 90: Paracoppa

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 4.2.4 PARACOPPA • Svitare e rimuovere la vite di attacco posteriore (1). • Operando da entrambi i lati, svitare e rimuovere la vite di attacco laterale (2). manuale utente MGS corsa - pag 4-14...
  • Page 91 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Rimuovere il paracoppa. ATTENZIONE Il paracoppa è realizzato in fibra composita di carbonio, materiale estremamente leggero e resistente ma poco elastico. Non farlo cadere, non piegarlo e non forzare gli attacchi durante il rimontaggio. manuale utente MGS corsa - pag 4-15...
  • Page 92: Supporto Batteria

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 4.2.5 SUPPORTO BATTERIA • Rimuovere la carenatura, vedi 4.1.3 (CARENATURA) Sul supporto batteria sono montati: La centralina elettronica Il portafusibili Le bobine di accensione Il relè iniezione La batteria •...
  • Page 93 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Operando dal lato destro svitare e rimuovere la vite (7) di attacco al telaio e il relativo dado. • Operando dal lato sinistro svitare e rimuovere la vite (8) di attacco al reggisella e il relativo dado. manuale utente MGS corsa - pag 4-17...
  • Page 94 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Rimuovere il supporto batteria lasciandolo vincolato ai cablaggi dei componenti montati sullo stesso. • Sotto al supporto batteria è alloggiato il sensore di caduta (9), porre attenzione al corretto posizionamento del sensore.
  • Page 95: Filtro Aria

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 4.2.6 FILTRO ARIA • Rimuovere la carenatura, vedi 4.1.3 (CARENATURA). • Svitare e rimuovere le due viti (1) del coperchio air-box. • Rimuovere il coperchio air-box. ATTENZIONE Il coperchio air-box è...
  • Page 96 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Svitare e rimuovere il dado coperchio filtro aria (2), recuperando la relativa rondella. • Rimuovere il coperchio filtro aria. ATTENZIONE Il coperchio filtro aria è realizzato in fibra composita di carbonio, materiale estremamente leggero e resistente ma poco elastico.
  • Page 97 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Deformare leggermente il filtro per estrarlo agevolmente dal suo alloggiamento. • Tappare il condotto di aspirazione con un panno pulito, per evitare che eventuali corpi estranei entrino nei condotti di aspirazione.
  • Page 98 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 99 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sez. 5 - IMPIANTO ELETTRICO manuale utente MGS corsa - pag 5-1...
  • Page 100 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten INDICE 5.1. SCHEMA................................3 5.1.1. SCHEMA IMPIANTO ELETTRICO......................3 manuale utente MGS corsa - pag 5-2...
  • Page 101 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 5.1. SCHEMA 5.1.1 SCHEMA IMPIANTO ELETTRICO manuale utente MGS corsa - pag 5-3...
  • Page 102 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Legenda: Colore dei cavi: arancio 17 Cruscotto Falcon, azzurro 18 Sensore pressione olio motore, 19 Sensore temperatura olio motore, bianco 20 Sensore di velocità, giallo 21Alternatore 12V 330W, grigio 22 Regolatore di tensione,...
  • Page 103 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten SEZ. 6 - CATALOGO RICAMBI manuale utente MGS corsa - pag 6-1...
  • Page 104 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten INDICE TAVOLA 1 - CARTER MOTORE ........................... 3 TAVOLA 2 - TESTA CILINDRO E VALVOLE ........................ 5 TAVOLA 3 - ALBERO MOTORE............................ 7 TAVOLA 4 - DISTRIBUZIONE I ............................. 8 TAVOLA 5 - DISTRIBUZIONE II ............................
  • Page 105: Tavola 1 - Carter Motore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 34 33 16 4 26 37 TAVOLA 1 - CARTER MOTORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Basamento motore nero 02000750 Piattello 12003900...
  • Page 106 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 34 33 16 4 26 37 TAVOLA 1 - CARTER MOTORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode 34 Spina 02011750 35 Anello di tenuta 90405367 36 Anello OR...
  • Page 107: Tavola 2 - Testa Cilindro E Valvole

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 2 - TESTA CILINDRO E VALVOLE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Testa cilindro dx nera 02022150 Testa cilindro sx nera 02022250 Guidavalvola 30036800...
  • Page 108 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 2 - TESTA CILINDRO E VALVOLE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode 34 Anello OR viton 90706109 35 Rosetta 8,4X13X0,8 14615901 36 Dado...
  • Page 109: Tavola 3 - Albero Motore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 3 - ALBERO MOTORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Cilindro con pistone cpl.nero 02060150 Pistone cpl. 02060251 Cilindro nero 02020250 Albero motore con tappo 02064150...
  • Page 110: Tavola 4 - Distribuzione I

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 18 17 20 19 TAVOLA 4 - DISTRIBUZIONE I Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Albero di servizio 02052050 Chiavetta 91600565 Flangia 01054000...
  • Page 111 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 5 - DISTRIBUZIONE II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Puleggia distribuzione 30057400 Rosetta 17X27X2 95004217 Dado M6X1,5 92602316 Cinghia distribuzione 30055300 Albero a camme dx...
  • Page 112: Tavola 6 - Pompa Benz

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 6 - POMPA BENZ. Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Pompa benz.cpl. 02107250 Innesto 02106650 Fascetta AP8102765 Tubo SAEJ30R98X14 00823952080 Fascetta 19157800...
  • Page 113: Tavola 7 - Corpo Farfallato

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 7 - CORPO FARFALLATO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Corpo farfallato 02112550 Iniettore IW724 30530500 Rosetta 95020104 Vite 98200410 Sensore corpo a farfalla 30530501...
  • Page 114: Tavola 8 - Cassa Filtro

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 8 - CASSA FILTRO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Cassa filtro 02114050 Filtro aria AP8104211 Coperchio filtro aria 02113750 Dado 92640406...
  • Page 115: Tavola 9 - Gruppo Scarico

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 19 20 TAVOLA 9 - GRUPPO SCARICO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Tubo scarico dx 02120950 Tubo scarico sx 02120951 Flangia 02121050...
  • Page 116: Tavola 10 - Radiatore Olio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 10 - RADIATORE OLIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Radiatore olio cpl. 02162050 Tubo ritorno olio 02162350 Tubo mandata 02161650 Riduzione 02161350...
  • Page 117: Tavola 11 - Pompa Olio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 5 6 4 TAVOLA 11 - POMPA OLIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Pompa olio 30146400 Chiavetta 13148300 Vite M8X30 98622430 Ingran.pompa olio...
  • Page 118: Tavola 12 - Filtro Olio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 14 15 18 19 10 9 10 6 TAVOLA 12 - FILTRO OLIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Filtro olio 30153000 Raccordo 30003800...
  • Page 119: Tavola 13 - Frizione

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 8 9 11 10 TAVOLA 13 - FRIZIONE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Molla frizione 13084100 Piattello 37082905 Disco frizione cpl. 02084450 Disco frizione int.
  • Page 120: Tavola 14 - Scatola Cambio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 14 - SCATOLA CAMBIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Scatola cambio nero 02200250 Coperchio scatola nero 02200850 Coperchio cpl. 02201350 Tappo 93180220...
  • Page 121 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 14 - SCATOLA CAMBIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode 31 Vite M6x35 98680335 31 Vite M6x70 98680370 32 Rosetta 6,4x12x1,2 95008306 33 Piastra rinforzo...
  • Page 122: Tavola 15 - Selettore Cambio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 29 23 TAVOLA 15 - SELETTORE CAMBIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Coperchio laterale nero 02201650 Albero forchetta 04232400 Forchetta 04230500 Forchetta...
  • Page 123: Tavola 16 - Albero Primario Cambio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 10 11 TAVOLA 16 - ALBERO PRIMARIO CAMBIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Albero primario cpl. 04210500 Semianello 12211700 Ingranaggio 2a vel.Z=18 04211300...
  • Page 124: Tavola 17 - Albero Secondario

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 9 10 17 18 TAVOLA 17 - ALBERO SECONDARIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Albero secondario sup. 04213600 Manicotto 3a-5a-4a-6a 01214961 Ingranaggio...
  • Page 125: Tavola 18 - Leva Cambio

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 18 - LEVA CAMBIO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Leva cambio 02250850 Cuscinetto a sfere 608 2RS 92201008 Rosetta 8,4X15X1,4 95008208...
  • Page 126: Tavola 19 - Trasmissione Posteriore I

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 19 - TRASMISSIONE POSTERIORE I Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Albero trasmissione 02358750 Vite 98832430 Rosetta 8,4X13X0,8 14615901 Asta di reazione 02358950 Dado...
  • Page 127: Tavola 20 - Trasmissione Posteriore Ii

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 36 35 TAVOLA 20 - TRASMISSIONE POSTERIORE II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Scatola trasmis.cpl.nero 02350250 Scatola trasmis.nero 02350350 Ghiera 04358700 Vite...
  • Page 128 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 36 35 TAVOLA 20 - TRASMISSIONE POSTERIORE II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode 28 Tappo scarico olio 31003766 29 Coppia conica 11/32 01354630 30 Gabbia a rulli...
  • Page 129: Tavola 21 - Telaio I

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 21 - TELAIO I Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Telaio finito 02400150 Bocchetta di aspirazione 02116950 Vite TBEI M6X16 98370616 Clip...
  • Page 130 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 22 - TELAIO II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Telaio post. 02410250 Vite TE flangiata M8x25* AP8152287 Tappo 93180117 Rivetto a strappo 17918556...
  • Page 131: Tavola 23 - Pedane

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 23 - PEDANE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Supporto pedana pilota dx 02443550 Vite M10x70 98690570 Vite M8x14 98692414 Distanziale 02442150...
  • Page 132: Tavola 24 - Serbatoio Benzina

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 24 - SERBATOIO BENZINA Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Serbatoio benz. 02100250 Guarnizione AP8144421 Flangia pompa benzina AP8134706 Supporto pompa benz.
  • Page 133: Tavola 25 - Cupolino

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten PER LA PULIZIA DEL CUPOLINO USARE ESCLUSIVAMENTE SAPONE NEUTRO FOR THE CLENING OF THE FRONT FAIRING USE ONLY NEUTRAL SOAP. TAVOLA 25 - CUPOLINO Pos Descrizione Specif.
  • Page 134 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 26 - PARAFANGO ANTERIORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Parafango ant.carb. AP8156012 Vite te flang. M5x12 AP8152272 Rosetta in nylon 5,5X12X1 30577800 Rosetta elastica...
  • Page 135: Tavola 27 - Carena Cpl

    Rosetta in nylon 6x12x0,5 02577850 10 Vite TBEI flangiata M6X16 98210616 11 Rosetta 6,15x11x0,8 95008206 12 Clip 28576591 13 Decalco dx Moto Guzzi 02917850 14 Decalco sx Moto Guzzi 02917950 15 Decalco MGS-01CORSA 02923450 16 Decalco Competition Only AP8157098 17 Decalco...
  • Page 136: Tavola 28 - Puntale Carena

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 28 - PUNTALE CARENA Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Puntale carena carb. 02570550 Distanziale 02573750 Gommino 91551010 Vite TBEI flangiata M6x35 98210635 Piastrina...
  • Page 137: Tavola 29 - Sterzo

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 29 - STERZO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Piastra sup.forcella 02493150 Base con cannotto 02494050 Controghiera AP8123643 Piastrina di sicurezza sterzo AP8121207 Ghiera AP8123642...
  • Page 138: Tavola 30 - Forcella Anteriore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten O I L TAVOLA 30 - FORCELLA ANTERIORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Stelo dx cpl. AP8163062 Stelo sx cpl. AP8163063 Kit revisione forcella AP8123975...
  • Page 139: Tavola 31 - Forcellone

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 31 - FORCELLONE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Forcellone post. 02540250 Perno forcellone 02547060 Anello di tenuta 25x47x7 90402547 Anello Seeger 47X50,5...
  • Page 140: Tavola 32 - Bielletta E Ammortizzatore Post

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten WARNING! CONTAINS HIGH PRESSURE NITROGEN GAS. SEE WORKSHOP MANUAL FOR DISPOSAL AND ADJUSTING UNIT. DO NOT OPEN. DO NOT INCINERATE. INCINERATION, PUNCTURE OR DISASSEMBLY MAY CAUSE THIS UNIT TO EXPLODE. 16 13 13 16 TAVOLA 32 - BIELLETTA E AMMORTIZZATORE POST.
  • Page 141: Tavola 33 - Ruota Anteriore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 33 - RUOTA ANTERIORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Pneumatico ant. 120/70 ZR 17 0000000 Ruota ant.nuda 3.50x17 02610350 Disco freno ant.
  • Page 142: Tavola 34 - Ruota Posteriore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 34 - RUOTA POSTERIORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Pneumatico post. 180/55 ZR 17 0000000 Ruota posteriore 5,50x17 02630550 Disco freno post.
  • Page 143: Tavola 35 - Pompa Freno Ant

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 35 - POMPA FRENO ANT. Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Tubo freno ant. AP8113984 Tappo serbatoio olio freni AP8113598 Serbatoio olio freni AP8113499...
  • Page 144: Tavola 36 - Pinza Freno Anteriore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 36 - PINZA FRENO ANTERIORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Pinza freno ant.dx oro AP8133590 Pinza freno ant.sx oro AP8133591 Pastiglie 4 pz.
  • Page 145: Tavola 37 - Pompa Freno Post

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 37 - POMPA FRENO POST. Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Serbatoio olio freni cpl. 02663550 Fascetta 61108500 Tubo olio 00823950050 Pompa freno post.
  • Page 146: Tavola 38 - Pinza Freno Post

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 38 - PINZA FRENO POST. Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Piastra attacco pinza freno 02635850 Perno fermo piastra freno AP8146388 Distanziale 25,2x31x1,5...
  • Page 147: Tavola 39 - Comando Frizione Cpl

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 39 - COMANDO FRIZIONE CPL. Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Serbatoio olio 01663530 Vite flangiata M5x16 AP8152273 Piastrina serbatoio olio AP8134394 Cilindro comando frizione 01086330...
  • Page 148: Tavola 40 - Manubrio - Comandi

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 40 - MANUBRIO - COMANDI Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Peso antivibrante v.nero AP8104509 Terminale peso antivibrante AP8121520 Semimanubrio sx AP8118650 Semimanubrio dx...
  • Page 149: Tavola 41 - Cruscotto

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 41 - CRUSCOTTO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Cruscotto cpl. 02760050 Coperchio 02766250 Supporto antivibrante 93221315 Vite TE M4X10 98084110 Rosetta 5,3X10X1...
  • Page 150: Tavola 42 - Alternatore - Regolatore

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 42 - ALTERNATORE - REGOLATORE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Alternatore 02712450 Regolatore SHINDENGEN 03703870 Calotta ant. 29711460 Vite TCEI M5x55 98680255...
  • Page 151: Tavola 43 - Motorino Avviamento

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 43 - MOTORINO AVVIAMENTO Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Motorino avviamento Valeo 30730711 Vite M8X75 98082475 Pignone cpl. 30530510 Kit spazzole 30530511...
  • Page 152: Tavola 44 - Impianto Elettrico I

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Fuel Pump Pressure Dashboard Sensor Sensor Temperature Ground Sensor R.H. Control 7 11 Regulator TAVOLA 44 - IMPIANTO ELETTRICO I Pos Descrizione Specif. Anno I_M_ Paese Ver.
  • Page 153: Tavola 45 - Impianto Elettrico Ii

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Temperature Sensor Diagnostic socket Speedometer sensor TAVOLA 45 - IMPIANTO ELETTRICO II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Cablaggio principale 02747150 Batteria 12V-11Ah...
  • Page 154: Tavola 46 - Attrezzatura Specifica I

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 46 - ATTREZZATURA SPECIFICA I Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Appoggio cambio in morsa 01912530 Montaggio parastrappi 01966330 Ghiera mm 34 albero 1a cambio 01913430 Ghiera mm 28 albero 1a cambio...
  • Page 155 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 47 - ATTREZZATURA SPECIFICA II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Coperchio coppa e filtro 01929100 Supporto per scatola cambio 14929600 Disco fase distribuz.accens.
  • Page 156 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 48 - ATTREZZATURA SPECIFICA III Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Chiave forcella Ohlins AP8140424 Mont.paraolio d.43 AP8140189 Peso per attrezzo AP8140189 AP8140146 Protez.operazioni smont.
  • Page 157: Tavola 47 - Attrezzatura Specifica Ii

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TAVOLA 49 - ATTREZZATURA SPECIFICA IV Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Attrezzo rotaz.albero camme 30927200 Attrezzo puleggia albero camme 30927300 Attrezzo puleggia A.S.
  • Page 158 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sect. 0 - INTRODUCTION MGS corsa user's manual - page 0-1...
  • Page 159 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE OF CONTENTS 0.1. INTRODUCTION ..............................3 0.1.1. FOREWORD ............................3 0.1.2. ABBREVIATIONS/SYMBOLS/CONVENTIONS..................4 MGS corsa user's manual - page 0-2...
  • Page 160 For control and repair operations not covered in this publication, for the purchase of genuine Moto Guzzi spare parts, accessories and other products, as well as for specific advice, refer exclusively to Moto Guzzi Authorised Dealers and Service Centres, which guarantee prompt and accurate service.
  • Page 161 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 0.1.2 ABBREVIATIONS/SYMBOLS/CONVENTIONS = number < = less than > = greater than = less than or equal to = more than or equal to = approximately ∞...
  • Page 162 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten = Pneumatic Power Clutch RIGHT SIDE = right side = Society of Automotive Engineers = Secondary Air System TEST = diagnostic check T.B.E.I. = crown-head Allen screw T.C.E.I.
  • Page 163 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 164 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sect. 1 - GENERAL INFORMATION MGS corsa user's manual - page 1-1...
  • Page 165 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE OF CONTENTS 1.1. STRUCTURE............................... 3 1.1.1. CONVENTIONS USED IN THE MANUAL ....................3 1.1.2. SAFETY WARNINGS..........................4 1.1.3. BASIC SAFETY RULES........................... 5 1.1.4. DANGEROUS ELEMENTS ........................8 1.1.5.
  • Page 166: Structure

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1. STRUCTURE 1.1.1 CONVENTIONS USED IN THE MANUAL • This manual is divided in sections and subsections, each covering a set of the most significant components. Refer to the index of sections when consulting the manual.
  • Page 167: Safety Warnings

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1.2 SAFETY WARNINGS The symbols and warnings used throughout this manual have the following meanings: Safety warning. This symbol appears, whether in the manual or on the vehicle itself, to indicate a personal injury hazard.
  • Page 168: Basic Safety Rules

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1.3 BASIC SAFETY RULES CARBON MONOXIDE Should it be necessary to perform some operations with the vehicle running, make sure to work outdoors or in a well-aerated room.
  • Page 169 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten HYDROGEN AND BATTERY FLUID DANGER The battery electrolyte is a toxic, caustic substance containing sulphuric acid and thus able to cause severe burns in case of contact with the skin. Always wear tight gloves and protective clothes when handling this fluid.
  • Page 170 CAUTION All bearings must rotate freely with no hard spots or noise. Replace any bearings that do not meet these requirements. Use ORIGINAL Moto Guzzi spare parts only. Use the specified lubricants and consumables. Where possible, lubricate a part before assembly.
  • Page 171: Dangerous Elements

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1.4 DANGEROUS ELEMENTS FUEL DANGER The fuel used in internal combustion engines is highly flammable and can become explosive under particular conditions. Refuelling and engine service should take place in a well-ventilated area with the engine stopped. Do not smoke when refuelling or in the proximity of sources of fuel vapours, avoid flames, sparks and any element that could ignite fuel or provoke explosions.
  • Page 172 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten FRONT FORK FLUID DANGER Front suspension response can be modified to a certain extent by changing damping settings and/or selecting a particular grade of oil. Standard oil: SAE 5 W. Choose suitable viscosity grades according to the desired set-up (SAE 5W softer, 20W less soft).
  • Page 173 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten DISC BRAKES DANGER The brakes are the parts that most ensure your safety and for this reason they must always be perfectly working; check them before every trip. A dirty disc soils the pads.
  • Page 174: Running-In

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.1.5 RUNNING-IN Correct engine running-is essential to ensuring proper performance and durability. Follow these recommendations: • Let the engine warm up to above 50° C (122° F); this is indicated by the blue light (1) on the instrument panel going out.
  • Page 175 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 176 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sect. 2 - TECHNICAL INFORMATION MGS corsa user's manual - page 2-1...
  • Page 177 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE OF CONTENTS 2.1. SPECIFICATIONS ............................... 3 2.1.1. TECHNICAL DATA........................... 3 2.1.2. SCHEDULED MAINTENANCE CHART ....................6 2.1.3. LUBRICANT TABLE ..........................9 2.1.4. TIGHTENING TORQUE SETTINGS ...................... 10 2.2.
  • Page 178: Specifications

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.1. SPECIFICATIONS 2.1.1 TECHNICAL DATA ENGINE – TRANSMISSION ENGINE Type two-cylinder, four-stroke Number of cylinders Cylinder arrangement V, 90° Pistons 2 compression rings, 1 scraper ring Connecting rods Carillo 144 mm (5.67 in) Bore...
  • Page 179 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TRANSMISSION SYSTEM - Clutch Sintering double-disc hydraulic-drive dry clutch - Primary drive Spur gears, ratio: 20/31 = 1:1.55 - Gearbox 6-speed - Overall gear ratios: 1st gear 15/36 = 1:10.822 2nd gear...
  • Page 180 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TYRES Wheel Make Model Size Compositi Pressure, bar (PSI) Front MICHELIN PILOT 120/60-17 "S1246A 2.1 (30.5) Rear MICHELIN PILOT 180/67-17 "S1835A 1.9 (27.6) Front DUNLOP KR106 120/75-17 "587...
  • Page 181: Scheduled Maintenance Chart

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.1.2 SCHEDULED MAINTENANCE CHART CAUTION: WHEN THE VEHICLE IS USED FOR THE FIRST TIME, WHEN ENGINE IS STILL OFF, CHECK FLUID LEVEL: brake fluid, see 3.1.1 (BRAKE FLUID); clutch fluid, see 3.1.2 (CLUTCH FLUID);...
  • Page 182 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Distance covered, Km (mi) Note Engine Valve seats R "R" lap upon each inspection Valve guides R "R" dimensional check Head structural R "R" part must be free from cracks analysis Camshafts R "R"...
  • Page 183 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Distance covered, Km (mi) Note Clutch Fluid Clutch actuating rod "R" wear inspection R "R" Thickness check Clutch plates Gearbox Gearbox fluid Primary transmission "R" tooth wear inspection and Wildhaber inspection Gears "R"...
  • Page 184: Lubricant Table

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.1.3 LUBRICANT TABLE LUBRICANT PRODUCT Engine oil RECOMMENDED: RACING 4T 5 W 40 As an alternative to recommended oils, top brand oils meeting or exceeding CCMC G-4 A.P.I.
  • Page 185: Tightening Torque Settings

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.1.4 TIGHTENING TORQUE SETTINGS WARNING The fastening elements listed should be tightened to the specified torque using a torque wrench and applying ® LOCTITE where indicated. All torque values are nominal values. Allowed tolerance range is ± 2 Nm (1.47 ftlb).
  • Page 186 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Torque Description Q.ty Size Note Nm (ftlb) Engine-to-frame fastening Front mounting bolt M12x1.75 80 (59.0) Mounting bolt above gearbox M10x1.5 50 (36.9) Linkage to frame screw M14x2 120 (88.5) Gearbox stud bolts / frame...
  • Page 187 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Torque Description Q.ty Size Note Nm (ftlb) Linkage pivot bolt on universal joint case M10x1.25 40 (29.5) BRAKING SYSTEMS Front system Right and left brake calliper retaining screw M10x1.25 50 (36.9) Brake disc retaining screw...
  • Page 188 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten WARNING ® Avoid using oil on threads for which Loctite application is specified. • Screw pipe onto nipple. • Screw fitting until finger-tight. • Tighten fitting to the specified torque. CAUTION Use ratchet pliers to set pipe in the desired direction if needed.
  • Page 189: Instruments

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.2. INSTRUMENTS 2.2.1 CONTROLS ON RIGHT HANDLEBAR ENGINE KILL SWITCH ( ) (1) WARNING Do not operate the engine stop switch " " while riding. This switch serves as a safety or emergency switch.
  • Page 190 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Pull the clutch lever (3) fully in and place the gear shift lever in neutral (4). • When you press the button " " (2), the starter motor will crank the engine. MGS corsa user's manual - page 2-15...
  • Page 191: Instrument Panel

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 2.2.2 INSTRUMENT PANEL The multifunction computer is a high-performance interface developed for racing; it consists of a multifunction display, six warning lights and two buttons. Key: Description Function...
  • Page 192 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten MODES When engine is started, a message appears and then the display provides configuration data (warm up mode); there are two more alternative configurations (practice and race mode) to choose from by pressing the button (1). Warm up mode: 11 Rev counter 12 Engine oil pressure...
  • Page 193 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Race mode: 11 Speed 12 Engine oil pressure 13 Engine oil temperature 14 Lap 15 Battery voltage CAUTION The instrument panel is pre-set to display one lap time in field (14) through the suitable device ( ODO/TRIP READOUT When engine is started, a message is displayed and then the display defaults to configuration data;...
  • Page 194 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten In ODO/TRIP readout, hold button (1) for less than five seconds to toggle between (TRIP) and (ODO) readings in kilometres and miles. To reset the trip meter (TRIP), go to ODO/TRIP readout and hold button (1) for over five seconds. CAUTION The trip meter gives the distance covered since last reset.
  • Page 195 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 196 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sect. 3 - USE AND MAINTENANCE MGS corsa user's manual - page 3-1...
  • Page 197 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE OF CONTENTS 3.1. LEVELS ................................3 3.1.1. BRAKE FLUID ............................3 3.1.2. CLUTCH FLUID............................8 3.1.3. GEARBOX FLUID ..........................10 3.1.4. GEARBOX OIL ............................11 3.1.5.
  • Page 198: Levels

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1. LEVELS 3.1.1 BRAKE FLUID RECOMMENDATIONS CAUTION This vehicle is fitted with front and rear disc brakes. Each braking system is operated by an independent hydraulic circuit.
  • Page 199 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten The front brake fluid reservoir is located near the front brake lever mount. The rear brake fluid reservoir is located near the rear brake lever mount. MGS corsa user's manual - page 3-4...
  • Page 200 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten FRONT BRAKE CHECK • Place the vehicle upright and keep the handlebar straight. • Make sure that the fluid in the reservoir is above the "MIN" level mark. MAX= maximum level MIN = minimum level.
  • Page 201 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Lift and remove the cover (3) complete with screws (1) and gasket (4). WARNING In order not to spill the brake fluid while topping up, do not rock the vehicle. Do not put additives or other substances into the fluid.
  • Page 202 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten REAR BRAKE CHECK • Keep the vehicle upright so that the fluid in the reservoir (6) is level with the plug (5). • Make sure that the fluid in the reservoir is above the "MIN" level mark. MAX= maximum level MIN = minimum level.
  • Page 203: Clutch Fluid

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.2 CLUTCH FLUID RECOMMENDATIONS CAUTION This vehicle is equipped with a hydraulic clutch. WARNING Sudden changes in brake lever play or a spongy feel of the lever may indicate problems with the hydraulic system.
  • Page 204 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TOPPING UP WARNING Danger: clutch fluid could leak out. Do not operate the clutch lever when the brake fluid reservoir plug (2) has been loosened or removed. DANGER Avoid long exposure of clutch fluid to air.
  • Page 205: Gearbox Fluid

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.3 GEARBOX FLUID CHECKING AND TOPPING UP WARNING Check engine oil level when the engine is hot. CAUTION Letting the engine idle with the vehicle at standstill is not the correct procedure to warm engine and engine oil up to operating temperature for an oil check.
  • Page 206: Gearbox Oil

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.4 GEARBOX OIL CHECKING AND TOPPING UP • Keep the vehicle upright with both wheels on the ground. • Unscrew and remove the level plug (1). •...
  • Page 207: Engine Oil

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.5 ENGINE OIL CHECKING AND TOPPING UP WARNING Check engine oil level when the engine is hot. CAUTION Letting the engine idle with the vehicle at standstill is not the correct procedure to warm engine and engine oil up to operating temperature for an oil check.
  • Page 208: Fuel

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.1.6 FUEL DANGER The fuel used in internal combustion engines is highly flammable and can become explosive under particular conditions. Refuelling and engine service should take place in a well-ventilated area with the engine stopped. Do not smoke when refuelling or in the proximity of sources of fuel vapours, avoid flames, sparks and any element that could ignite fuel or provoke explosions.
  • Page 209: Settings

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2. SETTINGS 3.2.1 THROTTLE CABLE TENSION The throttle grip must have 2 ÷ 3 mm (0.079 – 0.118 in) free play, measured at the edge of the grip. If this is not the case, proceed as follows: •...
  • Page 210: Adjusting The Front Brake Lever And The Clutch Lever

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.2 ADJUSTING THE FRONT BRAKE LEVER AND THE CLUTCH LEVER CAUTION The following procedures apply to both levers. The position of the lever (1) relative to the grip (2) is adjusted by rotating the adjuster (3). Adjust as follows: •...
  • Page 211: Adjusting The Gear Shift Lever

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.3 ADJUSTING THE GEAR SHIFT LEVER The gear shift lever is set in the correct ergonomic position at the factory. However, lever position can be adjusted to suit rider's preferences: •...
  • Page 212 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten FOOTREST HEIGHT ADJUSTMENT (6) The footrest (6) has three height adjustments. Adjust as follows: • Unscrew and remove the two screws (7). • Loosen and remove the screw (8) while holding the nut (9) at the rear end steady with a wrench. •...
  • Page 213 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Unscrew and remove the screw (10). • Set the footrest complete with pedal (6) so as to match one of the three bracket holes that determine the different height adjustments for the footrest (6).
  • Page 214 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Tighten the two screws (7). CAUTION Check that the footrest (6) is secured firmly in the correct position before riding. CONVERSION TO REVERSE SHIFT PATTERN DANGER This vehicle is designed for racing and provides for easy conversion to the reverse shift pattern to meet rider's preferences.
  • Page 215 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Rotate the intermediate shift arm (12) and fit it to the selector shaft to obtain a reverse shift pattern. • Tighten the screw (11). MGS corsa user's manual - page 3-20...
  • Page 216: Adjusting The Rear Brake Lever

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.4 ADJUSTING THE REAR BRAKE LEVER The rear brake lever is set in the correct ergonomic position at the factory. However, lever position can be adjusted to suit rider's preferences: •...
  • Page 217: Front Fork Adjustment

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.5 FRONT FORK ADJUSTMENT The front suspension is managed by a hydraulic fork, which is held to the steering stem by two yokes. Each fork leg is fitted with adjusters to modify suspension response. A top-mounted adjuster screw (1) controls rebound damping, a lower adjuster screw (2) controls compression damping, whereas a top-mounted adjuster nut (3) controls springs preload.
  • Page 218 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten The first step to setting a suspension is to set static sag (∆) according to rider's weight and tyres used. Static sag (∆) is the difference between the unloaded dimension (4) and the loaded dimension with the rider on board in riding position (5).
  • Page 219: Steering Damper Adjustment

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.6 STEERING DAMPER ADJUSTMENT The steering damper is adjustable and has a knob (1) to set hydraulic damping. Adjust as follows: • Turn the handlebar full lock to the left. WARNING Always set the damper to the softest setting before adjusting (turn knob fully anticlockwise).
  • Page 220: Rear Shock Absorber Adjustment

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.7 REAR SHOCK ABSORBER ADJUSTMENT The rear suspension is managed by a spring/damper unit that is connected to the frame through uniballs and to the rear swinging arm through a linkage system.
  • Page 221 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten The first step to setting a suspension is to set rear static sag (∆) according to rider's weight and tyres used. Static sag (∆) is the difference between the unloaded dimension (5) and the loaded dimension with the rider on board in riding position (6).
  • Page 222 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 1.9 bar from fully tightened from fully tightened 180/67- MICHELIN PILOT S1835A (27.6 position, slacken by 28 position, slacken by 5 17” (1.14 (1.30 PSI) –...
  • Page 223: Tappet Clearance Adjustment

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.8 TAPPET CLEARANCE ADJUSTMENT When the timing system is noisy, check clearances between valves and rocker arms. CAUTION Adjust clearance when the engine is cold, with the piston at top dead centre (TDC) during the compression stroke (valves closed).
  • Page 224: Adjusting Timing Belt Tension

    ADJUSTING TIMING BELT TENSION DANGER Timing belt tension adjustment is a complex procedure and is best left to experienced mechanics. If necessary, contact a Moto Guzzi Authorised Dealer. If you opt for doing yourself, follow these instructions. WARNING Allow some time for the engine and exhaust system to cool down.
  • Page 225 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Remove the two belt covers. CAUTION The following procedures apply to both timing belts. The timing belts must be tensioned with the piston at TDC during the combustion stroke (valves closed). CAUTION Be sure to have the special tool (1) no.30948600 (timing belt tension tool ) ready at hand.
  • Page 226: Settings For Use In Case Of Rain

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.2.10 SETTINGS FOR USE IN CASE OF RAIN In case of rain it is necessary to carry out the following operations to ensure the vehicle proper operation: •...
  • Page 227: Bleeding Instructions

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.3. BLEEDING INSTRUCTIONS 3.3.1 BLEEDING THE FRONT BRAKE Any air trapped in the hydraulic circuit will act as a cushion and take up most of the pressure applied by the master cylinder;...
  • Page 228 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Remove the bleed valve rubber cap (1). • Insert one end of a transparent plastic tubing inside the front brake calliper bleed valve (1) and the other end in a container.
  • Page 229: Bleeding The Rear Brake

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.3.2 BLEEDING THE REAR BRAKE Any air trapped in the hydraulic circuit will act as a cushion and take up most of the pressure applied by the master cylinder;...
  • Page 230 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Before proceeding, verify the following conditions: The master cylinder is above the hose (meaning the total length of the hose) and the brake calliper; The brake fluid reservoir is above the master cylinder; The calliper is oriented with the bleed valve at the uppermost position;...
  • Page 231: Bleeding The Clutch

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 3.3.3 BLEEDING THE CLUTCH Any air trapped in the circuit is indicated by a "spongy" feel of the clutch lever. DANGER Clutch fluid is an irritant. Avoid contact with eyes or skin. In the event of accidental contact, wash affected body parts thoroughly.
  • Page 232 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten BLEEDING THE CLUTCH MASTER CYLINDER • Insert one end of a transparent plastic tubing inside the clutch master cylinder bleed valve (1) and the other end in a container.
  • Page 233 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 234 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sect. 4 - FRAME MGS corsa user's manual - page 4-1...
  • Page 235 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE OF CONTENTS 4.1. CHASSIS ................................3 4.1.1. FRONT WHEEL ............................3 4.1.2. REAR WHEEL............................6 4.1.3. FAIRING ..............................11 4.1.4. SUMP GUARD ............................14 4.1.5.
  • Page 236: Chassis

    Front wheel removal and installation are complex procedures and are best left to experienced mechanics. If necessary, contact a Moto Guzzi Authorised Dealer. If you opt for doing it yourself, use great care when removing and installing the wheel to avoid damaging the brake hoses, discs and pads.
  • Page 237 Remove the brake callipers from the disc, but do not disconnect them from the brake hoses. WARNING Do not operate the brake lever after removing the calliper, or the pistons might fall out leading to loss of brake fluid. Should this happen, contact a Moto Guzzi Authorised Dealer to have the problem rectified. •...
  • Page 238 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Knock out the wheel shaft (4) by pushing gently on the threaded end and tapping with a rubber mallet if necessary. • Hold the front wheel and withdraw the wheel shaft manually . •...
  • Page 239: Rear Wheel

    Rear wheel removal and installation are complex procedures and are best left to experienced mechanics. If necessary, contact a Moto Guzzi Authorised Dealer. If you opt for doing yourself, follow these instructions. Use great care when removing and installing the wheel to avoid damaging the brake hoses, discs and pads.
  • Page 240 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Working from the left side, loosen and remove the rear wheel shaft nut and collect the washer. • Working from the right side, remove the rear wheel shaft. WARNING After removing the shaft, support the rear wheel and the rear brake calliper or they might drop and damage.
  • Page 241 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Ease off the brake calliper by shifting the rear wheel in small motions and remove the calliper in a downward motion. WARNING On refitting, be sure to match the recess (1) in the calliper carrier (2) to the locating peg (3) on the inside of the swinging arm.
  • Page 242 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Support the transmission case and remove the wheel. WARNING When refitting the wheel, align the mark on the transmission shaft (4) with the rear coupling mark (5) accurately.
  • Page 243 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Detach the transmission case from the wheel. MGS corsa user's manual - page 4-10...
  • Page 244: Fairing

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 4.1.3 FAIRING DANGER Risk of fire. Allow for the engine and exhaust silencer to cool down completely before proceeding. Fuel vapours are noxious to human health. Ensure the area is well ventilated before proceeding.
  • Page 245 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Remove the quick-release fastener on the tail guard. • Working on either side, loosen and remove the screw. MGS corsa user's manual - page 4-12...
  • Page 246 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Working on either side, loosen and remove the screw under the tail guard. • Grasp the fairing firmly at the fuel filler hole and the tail guard. •...
  • Page 247: Sump Guard

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 4.1.4 SUMP GUARD • Loosen and remove the rear mounting screw (1). • Working from both sides, loosen and remove the side mounting screw (2). MGS corsa user's manual - page 4-14...
  • Page 248 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Remove the sump guard. WARNING The sump guard is made from composite carbon fibre; this material is light and strong, but not very flexible. Do not drop or bend the guard and do not apply exceeding force on the mountings on refitting. MGS corsa user's manual - page 4-15...
  • Page 249: Battery Mount

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 4.1.5 BATTERY MOUNT • Remove the fairing, see 4.1.3 (FAIRING) There are several components mounted on the battery mount: Electronic control unit Fuse carrier Ignition coils Injection relay Battery •...
  • Page 250 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Working from the right side, loosen and remove the screw (7) connecting mount to frame and its nut. • Working from the left side, loosen and remove the screw (8) connecting mount to seat support and its nut. MGS corsa user's manual - page 4-17...
  • Page 251 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Remove the battery mount but do not disconnect the wiring of the components mounted on it. • The bank angle sensor (9) is located under the battery mount; make sure the sensor is in the correct position. DANGER If in the wrong position, the bank angle sensor (9) may lead to sudden engine stalling and loss of control.
  • Page 252: Air Filter

    www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 4.1.6 AIR FILTER • Remove the fairing, see 4.1.3 (FAIRING) • Loosen and remove the two airbox cover screws (1). • Remove the airbox cover. WARNING The airbox cover is made from composite carbon fibre;...
  • Page 253 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Loosen and remove the air filter cover nut (2) and collect the washer. • Remove the air filter cover. WARNING The air filter cover is made from composite carbon fibre; this material is light and strong, but not very flexible.
  • Page 254 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten • Bend the filter slightly to lift it out of its housing. • Block off the intake duct with a clean cloth to prevent dirt from falling into the intake ducts. WARNING On assembly, make sure to remove the cloth or any other objects from inside the airbox before refitting the filter and airbox covers.
  • Page 255 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten...
  • Page 256 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Sect. 5 - ELECTRIC SYSTEM MGS corsa user's manual - page 5-1...
  • Page 257 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE OF CONTENTS 5.1. DIAGRAM ................................3 5.1.1. WIRING DIAGRAM ..........................3 MGS corsa user's manual - page 5-2...
  • Page 258 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 5.1. DIAGRAM 5.1.1 WIRING DIAGRAM CABLE H. T. CABLE H. T. OIL PRES. OIL PRES. GROUND OIL TEMP. OIL TEMP. GROUND MGS corsa user's manual - page 5-3...
  • Page 259 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Key: Wire colour coding: Orange 17 Falcon instrument panel, Light blue 18 Engine oil pressure sensor, Blue 19 Engine oil temperature sensor, White 20 Speed sensor, Yellow 21 12V 330W alternator, Grey...
  • Page 260 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten SEC. 6 - SPARE PARTS CATALOGUE owner’s manual MGS corsa - pag 6-1...
  • Page 261 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten INDICE TABLE 1 - CRANKCASE ............................... 3 TABLE 2 - CYLINDER HEAD AND VALVES ......................... 5 TABLE 3 - DRIVE SHAFT .............................. 7 TABLE 4 - TIMING SYSTEM II ............................8 TABLE 5 - TIMING SYSTEM I ............................
  • Page 262 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 34 33 16 4 26 37 TABLE 1 - CRANKCASE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Crankcase black 02000750 Disc 12003900 Stud bolt M8X51...
  • Page 263 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 34 33 16 4 26 37 TABLE 1 - CRANKCASE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode 34 Pin 02011750 35 Gasket ring 90405367 36 O-ring 90706981...
  • Page 264 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 2 - CYLINDER HEAD AND VALVES Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode RH cylinder head, black 02022150 LH cylinder head, black 02022250 Valve guide 30036800...
  • Page 265 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 2 - CYLINDER HEAD AND VALVES Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode 34 O-ring viton 90706109 35 Washer 8,4X13X0,8 14615901 36 Nut 92602008...
  • Page 266 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 3 - DRIVE SHAFT Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Cylinder with piston, black 02060150 Piston assy 02060251 Cylinder black 02020250 Crankshaft with plug 02064150...
  • Page 267 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 18 17 20 19 TABLE 4 - TIMING SYSTEM II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Shaft 02052050 Transmission key 91600565 Flange 01054000...
  • Page 268 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 5 - TIMING SYSTEM I Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Distribution pulley 30057400 Washer 17X27X2 95004217 M6X1,5 92602316 Timing belt 30055300 RH camshaft...
  • Page 269 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 6 - FUEL PUMP Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Fuel pump cpl. 02107250 Coupling 02106650 Hose clamp AP8102765 Pipe SAEJ30R98X14 00823952080...
  • Page 270 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 7 - THROTTLE BODY Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Throttle body 02112550 Injector IW724 30530500 Washer 95020104 Screw 98200410 Throttle body sensor 30530501...
  • Page 271 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 8 - AIR BOX Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Air box 02114050 Air filter AP8104211 Air filter cover 02113750 92640406 02113850...
  • Page 272 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 19 20 TABLE 9 - EXHAUST UNIT Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode RH exhaust pipe 02120950 LH exhaust pipe 02120951 Flange 02121050...
  • Page 273 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 10 - OIL COOLER Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Oil cooler cpl. 02162050 Oil return pipe 02162350 Oil delivery pipe 02161650 Reduction 02161350...
  • Page 274 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 5 6 4 TABLE 11 - OIL PUMP Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Oil pump 30146400 Transmission key 13148300 Screw M8X30 98622430...
  • Page 275 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 14 15 18 19 10 9 10 6 TABLE 12 - OIL FILTER Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Oil filter 30153000 Union 30003800...
  • Page 276 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 8 9 11 10 TABLE 13 - CLUTCH Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Clutch spring 13084100 Disc 37082905 Clutch plate complete 02084450 Intermediate plate 12082300...
  • Page 277 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 14 - TRANSMISSION CAGE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Gearbox black 02200250 Case cover black 02200850 Cover cpl. 02201350 Plug 93180220...
  • Page 278 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 14 - TRANSMISSION CAGE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode 31 Screw M6x35 98680335 31 Screw M6x70 98680370 32 Washer 6,4x12x1,2 95008306 33 Reinforcement Plate...
  • Page 279 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 29 23 TABLE 15 - GEAR BOX SELECTOR Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Gearshift black 02201650 Fork shaft 04232400 Fork 04230500 Fork...
  • Page 280 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 10 11 TABLE 16 - PRIMARY GEAR SHAFT Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Primary gear shaft assy. 04210500 Half ring 12211700 Gear 2a vel.Z=18...
  • Page 281 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 9 10 17 18 TABLE 17 - DRIVEN SHAFT Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Upper lay shaft 04213600 Hose 3a-5a-4a-6a 01214961 Gear...
  • Page 282 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 18 - GEAR LEVER Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Gear lever 02250850 Ball bearing 608 2RS 92201008 Washer 8,4X15X1,4 95008208 Shift lever...
  • Page 283 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 19 - TRANSMISSION COMPLETE I Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Primary drive shaft 02358750 Screw 98832430 Washer 8,4X13X0,8 14615901 Reaction rod 02358950...
  • Page 284 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 36 35 TABLE 20 - TRANSMISSION COMPLETE II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Transmission complete black 02350250 Transmission housingblack 02350350 Ring nut 04358700...
  • Page 285 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten 36 35 TABLE 20 - TRANSMISSION COMPLETE II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode 28 Oil unload plug 31003766 29 Bevel gear 11/32 01354630 30 Roller cage...
  • Page 286 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 21 - FRAME I Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Frame 02400150 Intake opening 02116950 Hex socket screw M6X16 98370616 Clip 28576591...
  • Page 287 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 22 - FRAME II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Rear frame 02410250 Screw w/ flange M8x25* AP8152287 Plug 93180117 Tearing rivet 17918556...
  • Page 288 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 23 - FOOT RESTS Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode RH front footrest bracket 02443550 Screw M10x70 98690570 Screw M8x14 98692414 Spacer...
  • Page 289 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 24 - FUEL TANK Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Fuel tank 02100250 Gasket AP8144421 Fuel pump flange AP8134706 Fuel pump support AP8134712 Self-locking nut...
  • Page 290 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten PER LA PULIZIA DEL CUPOLINO USARE ESCLUSIVAMENTE SAPONE NEUTRO FOR THE CLENING OF THE FRONT FAIRING USE ONLY NEUTRAL SOAP. TABLE 25 - WINDSHIELD Pos Descrizione Specif.
  • Page 291 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 26 - FRONT MUDGUARD Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Front mudguard, carb. AP8156012 Screw w/ flange M5x12 AP8152272 Nylon washer 5,5X12X1 30577800...
  • Page 292 Nylon washer 6x12x0,5 02577850 10 Screw w/ flange M6X16 98210616 11 Washer 6,15x11x0,8 95008206 12 Clip 28576591 13 Sticker RH Moto Guzzi 02917850 14 Sticker LH Moto Guzzi 02917950 15 Decal MGS-01CORSA 02923450 16 Decal Competition Only AP8157098 17 Decal...
  • Page 293 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 28 - PILLAR Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Pillar, carb. 02570550 Spacer 02573750 Rubber spacer 91551010 Screw w/ flange M6x35 98210635 Plate...
  • Page 294 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 29 - STEERING Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Fork upper plate 02493150 Stem base 02494050 Return ring nut AP8123643 Steering security plate AP8121207...
  • Page 295 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten O I L TABLE 30 - FRONT FORK Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode RH hub cpl. AP8163062 LH hub cpl. AP8163063 Front fork revision kit AP8123975...
  • Page 296 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 31 - SWING ARM Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Swingarm 02540250 Rear swing arm pin 02547060 Gasket ring 25x47x7 90402547 Circlip...
  • Page 297 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten WARNING! CONTAINS HIGH PRESSURE NITROGEN GAS. SEE WORKSHOP MANUAL FOR DISPOSAL AND ADJUSTING UNIT. DO NOT OPEN. DO NOT INCINERATE. INCINERATION, PUNCTURE OR DISASSEMBLY MAY CAUSE THIS UNIT TO EXPLODE. 16 13 13 16 TABLE 32 - CONNECTING ROD - REAR SHOCK ABS.
  • Page 298 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 33 - FRONT WHEEL Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Front/rear tyre 120/70 ZR 17 0000000 Front wheel 3.50x17 02610350 Front brake disc AP8113926...
  • Page 299 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 34 - REAR WHEEL Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Rear tyre 180/55 ZR 17 0000000 Rear wheel 5,50x17 02630550 Rear brake disc AP8113612...
  • Page 300 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 35 - FRONT BRAKE PUMP Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Front brake pipe AP8113984 Pil brake tank plug AP8113598 Brake oil tank AP8113499...
  • Page 301 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 36 - FRONT BRAKE CALIPER Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode RH Front brake caliper, gold AP8133590 LH Front brake caliper, gold AP8133591 Pads 4 pc.
  • Page 302 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 37 - REAR BRAKE PUMP Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Brake oil tank complete 02663550 Hose clamp 61108500 Oil pipe 00823950050 Rear brake pump...
  • Page 303 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 38 - REAR BRAKE CALIPER Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Brake hanger plate 02635850 Brake supp. plate pin AP8146388 Spacer 25,2x31x1,5...
  • Page 304 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 39 - CLUTCH CONTROL COMPLETE Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Oil tank 01663530 Screw w/ flange M5x16 AP8152273 Oil tank plate AP8134394 Clutch command cylinder...
  • Page 305 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 40 - HANDLEBAR - CONTROLS Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Anti.v weight, black AP8104509 Anti vib.weight trailing AP8121520 Left half handlebar AP8118650 Right half handlebar...
  • Page 306 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 41 - DASHBOARD Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Dashboard complete 02760050 Cover 02766250 Block 93221315 Screw TE M4X10 98084110 Washer 5,3X10X1...
  • Page 307 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 42 - GENERATOR - REGULATOR Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Generator 02712450 Regulator 03703870 Front calotte 29711460 Hex socket screw M5x55 98680255 Washer...
  • Page 308 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 43 - STARTER MOTOR Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Starter motor Valeo 30730711 Screw M8X75 98082475 Pinion assy 30530510 Brush revision set 30530511...
  • Page 309 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Fuel Pump Pressure Dashboard Sensor Sensor Temperature Ground Sensor R.H. Control 7 11 Regulator TABLE 44 - ELECTRICAL SYSTEM I Pos Descrizione Specif. Anno I_M_ Paese Ver.
  • Page 310 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten Temperature Sensor Diagnostic socket Speedometer sensor TABLE 45 - ELECTRICAL SYSTEM II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Main wiring harness 02747150 Battery 12V-11Ah...
  • Page 311 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 46 - SPECIFIC TOOLS I Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Tool gearbox resting onto vice 01912530 Flexible couplings assembly 01966330 Locking mm34 on gear 1a shaft 01913430...
  • Page 312 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 47 - SPECIFIC TOOLS II Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Wrench remov.cover sump/filter 01929100 Gearbox housing support 14929600 Index plate tim.sett./ign.cont 19929600 Arrow tim.set.ignition control...
  • Page 313 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 48 - SPECIFIC TOOLS III Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Key for Ohlins forks AP8140424 Oil seal assembly tool d.43 AP8140189 Weight for AP8140189 AP8140146...
  • Page 314 www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten TABLE 49 - SPECIFIC TOOLS IV Pos Descrizione Specif. Anno I_M_ Paese Ver. Ver.1 Cod. Q.t’ PCode Camshaft turning tool 30927200 Camshaft pulley tool 30927300 Secondary shaft pulley tool 30927600 Timing belt tensioner tool...
