4 Channel RS232C/USB Converter
(Common Isolation Type)
USB-033SI
User's Manual
Ver. 1.0
HuMANDATA LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB-033SI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Humandata USB-033SI

Summary of Contents for Humandata USB-033SI

  • Page 1 4 Channel RS232C/USB Converter (Common Isolation Type) USB-033SI User’s Manual Ver. 1.0 HuMANDATA LTD.

  • Page 3: Table Of Contents

    Table of Contents Precautions ..................... 1  Revision History ....................2  Introduction ....................2  1. Specifications ..................... 3 1.1. Optional Accessories ....................4 2. Overview ......................5 3. Power Supply ..................... 5 4. Block Diagram ....................6 5. Reference Circuit of RS-232C I/O ............... 6 6.

  • Page 5: Precautions

    Attention Item 7 notwithstanding, HuMANDATA cannot be held liable for the consequences arising from use of this product. HuMANDATA cannot be held liable for consequences arising from using this product in a way different from the uses described herein, or from uses not shown herein.

  • Page 6: Revision History

     Introduction Thank you very much for purchasing our product of USB-033SI. USB-033SI is a 4 channel USB to RS-232C converter. You can add 4 channels of RS232C from 1 USB port. Those 4 channels are isolated commonly from USB port.

  • Page 7: Specifications

    165 x 80.5 x 39 [mm] Dimensions Without projections (6.496" x 3.169" x 1.535") * There is a case to be changed to the parts of the compatibility * Power saving function (suspend, standby, sleep and others) is not supported USB-033SI (Ver.1.0)

  • Page 8: Optional Accessories

    Metal bracket type A ACC-027 for vertical mounting USB series JAN : 4937920801096 Metal bracket type A ACC-028 for horizontal mounting USB series JAN : 4937920801102 Din rail attachment type B for USB series ACC-031 JAN : 4937920801256 USB-033SI (Ver.1.0)

  • Page 9: Overview

    2. Overview Tx/Rx LED x4 (Ch A-D) Front Side Power LED USB Connector RS232C Port x 4 (Ch A-D) Rear Side 3. Power Supply USB-033 is powered through a USB port (Bus-powered). USB-033SI (Ver.1.0)

  • Page 10: Block Diagram

    4. Block Diagram Between USB and RS-232C side is isolated. 5. Reference Circuit of RS-232C I/O Protection circuit is shortened USB-033SI (Ver.1.0)

  • Page 11: Rs232C Pin Assignment

    7. Additional Documentation and User Support The following documents and other supports are available at http://www.hdl.co.jp/en/faspc/USB/usb-033si Device Driver  Dimensional drawing  … and more. 8. Warranty and Compensation Please refer to the following URL for the warranty. http://www.fa.hdl.co.jp/en/fa-warranty.html USB-033SI (Ver.1.0)
  • Page 12 4 Channel RS232C/USB Converter (Common Isolation Type) USB-033SI User’s Manual Ver. 1.0 ........January 17, 2017 HuMANDATA LTD. Address: 1-2-10-2F, Nakahozumi, Ibaraki Osaka, Japan ZIP 567-0034 Tel: 81-72-620-2002 (Japanese) Fax: 81-72-620-2003 (Japanese/English) URL: http://www.fa.hdl.co.jp (Japan) http://www.fa.hdl.co.jp/en(Global)
