USB to RS-232C Converter Compact
USB-501
User's Manual
Ver. 1.0
HuMANDATA LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB-501 and is the answer not in the manual?

Questions and answers

Related Manuals for Humandata USB-501

Summary of Contents for Humandata USB-501

  • Page 1 USB to RS-232C Converter Compact USB-501 User’s Manual Ver. 1.0 HuMANDATA LTD.

  • Page 2: Table Of Contents

    Introduction ....................2  1. Overview ......................3 2. Power Supply ..................... 3 3. Specifications ..................... 4 3.1. Optional Accessories ....................5 4. RS232C Pin Assignment ..................6 5. Additional Documentation and User Support ............. 6 6. Warranty and Compensation................6 USB-501 (Ver.1.0)

  • Page 3: Precautions

    Attention Item 7 notwithstanding, HuMANDATA cannot be held liable for the consequences arising from use of this product. HuMANDATA cannot be held liable for consequences arising from using this product in a way different from the uses described herein, or from uses not shown herein.

  • Page 4: Revision History

    Initial release  Introduction Thank you very much for purchasing our product of USB-501. USB-501 is a USB to RS-232C converter that isolated between RS-232C and a USB port. So, it’s safe for use in factory automation environment. USB-501 (Ver.1.0)

  • Page 5: Overview

    USB Connector Front Side (USB) Power LED Transmit /Receive data Rear Side (RS-232) RS-232C #4-40 UNC Male Connector TOP side (Block diagram) 2. Power Supply USB-501 is powered through a USB port (Bus-powered). No external power supply is required. USB-501 (Ver.1.0)

  • Page 6: Specifications

    M2.6 screws Operating Ambient -20 to 60 [°C] (-4 to 140 [°F]) Temperature Operating Ambient Humidity 30 to 85%RH No condensation permitted Storage Ambient -20 to 55 [°C] (-4 to 131 [°F]) Temperature Storage Ambient Humidity 30 to 85%RH USB-501 (Ver.1.0)

  • Page 7: Optional Accessories

    * Power saving function (suspend, standby, sleep and others) is not supported 3.1. Optional Accessories Model Name Image Description USB series Attachment with clamping screw PEN-003 JAN：4937920800709 USB series Attachment for 35mm DIN rail PEN-003-DIN JAN：4937920800716 USB series Attachment with neodymium magnet PEN-003-MG JAN：4937920801201 USB-501 (Ver.1.0)

  • Page 8: Rs232C Pin Assignment

    5. Additional Documentation and User Support The following documents and other supports are available at https://www.hdl.co.jp/en/faspc/USB/usb-501 Device Driver  Outline Drawing  … and more. 6. Warranty and Compensation Please refer to the following URL for the warranty. https://www.fa.hdl.co.jp/en/fa-warranty.html USB-501 (Ver.1.0)
  • Page 9 USB to RS-232C Converter Compact USB-501 User’s Manual Ver. 1.0 ..........Jul. 9, 2020 HuMANDATA LTD. Address: 1-2-10-2F, Nakahozumi, Ibaraki Osaka, Japan ZIP 567-0034 Tel: 81-72-620-2002 (Japanese) Fax: 81-72-620-2003 (Japanese/English) URL: https://www.fa.hdl.co.jp/en/ (Global) https://www.fa.hdl.co.jp/jp/ (Japan)
