- Page 1 Electrical operating instructions OFF and Re-made module for airlock, with emergency-open function 0 0 0 0 0 0 0 0 0 0 0 5 1 1 7 1 3 9 4 XXXXX 51171394 - c 01.2016...
- Page 2 Page 2...
- Page 3 OPERATING INSTRUCTIONS Page DESCRIPTION ......................4 SUPPLY EMERGENCY OPEN MODULE ..............4 ENCLOSURE INSTALATION ..................5 WIRING .........................6 Page 3...
- Page 4 DESCRIPTION This emergency open module must be connected into connection circuit between airlock module and control panel and supplies the following functions: - Airlock function can be switched OFF in an emergency (panic) situation. Thereafter both doors open automatically if the push button S42 or S43 will be activated. (Principle 1; Fig.: 1 + 2) - OFF - respectively Re-made of the airlock function when using a latching key-switch S44 (Principle 2;...
- Page 5 ENCLOSURE INSTALATION The enclosure should be fitted directly beside the control panel. To connect the module, the lateral rubber plug must be carefully opened. The module cable should be guided thru the hole into the control enclosure, and following the pre-fitted cable gland may be softly tightened by using the enclosed nut.
- Page 6 WIRING Principle 1: In an emergency situation the airlock function will be switched OFF when activating the button S42 or S43 and following both doors travelling to final open position. If contacted S 42: Emergency open function activated If contacted S 41: Emergency open function OFF, Airlock function ON Fig.: 1 If contacted S 43: Emergency open function activated Fig.: 2...
- Page 7 OFF position and both doors can be used independent and in normal mode Fig.: 3 Note: To activate the airlock function after a re-made, the minimum of one door must travel to the final closed position. www.gfa-elektromaten.de Page 7...
