SERVICE MANUAL
Ver 1.2 2003. 11
Revision History
Revision History
J MECHANISM
Link
Link
SPECIFICATIONS
SPECIFICATIONS
SERVICE NOTE
SERVICE NOTE
DISASSEMBLY
DISASSEMBLY
• For INSTRUCTION MANUAL, refer to separate file (992995271.pdf).
• For MECHANISM ADJUSTMENTS, refer to the "DV MECHANICAL ADJUSTMENT MANUAL
J MECHANISM " (9-929-807-11).
On the VC-280 board
This service manual provides the information that is premised the circuit board replacement service and not intended repair
inside the VC-280 board.
Therefore, schematic diagram, printed wiring board, waveforms, mounted parts location and electrical parts list of the VC-280
board are not shown.
The following pages are not shown.
Schematic diagram ............................. Pages 4-37 to 4-66
Printed wiring board ............................ Pages 4-85 to 4-88
Waveforms ........................................... Page 4-92
DCR-TRV16/TRV16E/TRV18/
TRV18E/TRV116E/TRV118E
Photo : DCR-TRV18
BLOCK DIAGRAMS
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
Mounted parts location ............................. Pages 4-95 to 4-96
Electrical parts list ................................... Pages 6-19 to 6-24
DIGITAL VIDEO CAMERA RECORDER
RMT-814
LEVEL
US Model
Canadian Model
AEP Model
UK Model
East European Model
North European Model
DCR-TRV16E/TRV18E/TRV116E/TRV118E
E Model
Hong Kong Model
DCR-TRV16/TRV16E/TRV18/TRV18E
Australian Model
Chinese Model
DCR-TRV16E/TRV18E
Tourist Model
DCR-TRV18/TRV18E
Korea Model
DCR-TRV16/TRV18
PRINTED WIRING BOARDS
PRINTED WIRING BOARDS
ADJUSTMENTS
ADJUSTMENTS
REPAIR PARTS LIST
REPAIR PARTS LIST
2
DCR-TRV18
