Chapter 2
Installing Device
Figure 9: DC and 48 VDC PoE Power Supply
Figure 10: AC and 48 VDC PoE Power Supply
Section 2.7

Connecting to the Device

The following describes the various methods for accessing the ROS console and Web interfaces on the device. For
more detailed instructions, refer to the RUGGEDCOM ROS User Guide for the RUGGEDCOM RSG2300P.
RS232 Console Port
Connect a workstation directly to the RS232 console port to access the boot-time control and ROS interfaces. The
console port provides access to ROS's console and Web interfaces.
16
RUGGEDCOM RSG2300P
Installation Guide
Connecting to the Device
