1 Introduction

1.1 Overview

The User Interface Manual explains the different user interfaces for accessing and
configuring the SDIDU™.

1.2 Modes of User Interfaces

The terminal can be accessed through Serial, Ethernet, or Modem interfaces
using the following modes:

1.3 Features Overview

© Copyright 2006 Microwave Data Systems Inc. All Rights Reserved
Web Interface (Normal / SSL)
Command Line Interface, CLI (Serial Console/Telnet/SSH)
SNMP Agent
SDIDU™ Provisioning
Network Time Protocol (NTP) client
Spanning-Tree Protocol (STP) configuration
SNMP configuration
Serial port configuration
Security configuration
Feature authorization
Configuration saving/retrieving
Alarm notification configuration
DHCP client for automated NMS network configuration
Link Provisioning
Modulation, Bandwidth, E1/T1 channels, Ethernet, STM-1/OC-3
Status and Monitoring
Automated alarm reporting
SNR, RSL, Errored-Seconds
Event Log
Alarm Log
Remote logging to Syslog server
SNMP TRAPs
Firmware Upgrade
