Service menu:
ID code: 0000
0
Activate
Set mode
24V mode
Present mode 24V mode off
charging
Present mode 24V mode on
EPS 12V
Present mode
EPS 24V
Present mode
EPS autostart
Service menu structure
Set voltage
Set 12V Trickle 12V
trickle voltage Now at: 13.4V
Set 24V Trickle 24V
trickle voltage Now at: 26.8V
Set 12V Charging 12V
charging voltage Now at: 14.8V
Set 24V Charging 24V
charging voltage Now at: 28.8V
Set 12 V EPS 12V
EPS voltage Now at: 14.0V
Set 24V EPS 24V
EPS voltage Now at: 28.0V
Exit menu
Page 22
Set voltage limit
Set Ua max. 12V Ua max. 12V
Now at: 16.0V
Set Ua min. 12V Ua min. 12V
Now at: 7.0V
Set Ua max. 24V Ua max. 24V
Now at: 32.0V
Set Ua min. 24V Ua min. 24V
Now at: 14.0V
Exit menu
