The following table gives an overview of the MultiCharger 1500's default voltage levels:
Charging 12V
charging 12V
14.8V
The charging process can be stopped by pressing button 2 (Start/Stop). If the battery remains
connected, the charging process can then be restarted by pressing button 2 (Start/Stop) again. If
the battery is unclamped, the charging process is over and will be restarted automatically if the
battery is connected again.
If the battery is unclamped during the charging process without pressing button 2 (Start/Stop), the
process will likewise be stopped. It will be restarted again automatically if the battery is
reconnected.
Warning:
Unclamping the battery without first properly ending the charging process can briefly create sparks.
The charging process can also be stopped at any time by pressing button 1 (On/Off). When the
MultiCharger 1500 is switched back on the charging process would then begin again from the start.
2.2.1

Output current in battery charging mode

In battery charging mode the MultiCharger 1500 can be briefly (max. 1 minute) subjected to an
output current increased by 25%.
The following table gives an overview of maximum levels of output current for the MultiCharger
1500:
Inom at Imax at
12V CHRG 12V CHRG
80.0A
If the MultiCharger 1500 rated current is exceeded during use, the unit internally measures how
long this situation lasts. After a maximum of one minute the current limit is reset to the rated value.
To avoid the MultiCharger 1500 overheating the unit allows a period for the charger recover five
times as long as the length of time for which the rated current was exceeded. For example, if the
rated current is exceeded for 30 seconds, the MultiCharger 1500 current limit is held at the level of
the rated current for 2 minutes 30 seconds. After that time, the rated current can again be
exceeded.
Trickle Charging 24V
13.4V 28.8V
Inom at
24V CHRG
100.0A 40.0A
Trickle
charging 24V
26.8V
Imax at
24V CHRG
50.0A
