Energy Related Product Directive

This product meets the Ecodesign requirements for an electric storage local space heater. Commission
Regulation (EU) 2015/1188.
Model Identifier(s):
Heat Output
Nominal heat output
Minimum heat output (indicative)
Maximum heat output
Auxiliary electricity consumption
At nominal heat output
At minimum heat output
In standby mode
Type of Heat input, for electronic storage local space heaters only
Electronic heat charge control with room
temperature feedback
Fan assisted heat output
Type of heat output / room temperature control
Electronic room temperature control plus week
timer

Contact details

Glen Dimplex Heating and Ventilation
Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF
Tel: 0344 879 3588
This product meets the Ecodesign requirements for an electric storage local space heater. Commission
Regulation (EU) 2015/1188.

Technical Details

Model Identifier(s):
Input rating +5% / -10%
Boost Output 230/240V~
Rated Charge Period:
Max Storage Capacity
Fan Wattage
UI Wattage
Sound Level dB
(measured in test chamber)
Energy Cell Packs Required (047243)
Height (mm)
Width (mm)
Depth (mm)
QM050RF
Pnom 0.50kW
Pmin 0.00
Pmax,c 0.90kW
elmax 0.00
elmin 0.00
elSB
0.000
QM050RF QM070RF
936/1020W 1435/1560W 2042/2220W 2540/2760W 3024/3300W
312/340W 478/520W
7.7 - 7 Hours 7.7 - 7 Hours
7.2kWh 10.9kWh
11W 11W
0.5W 0.5W
27 29
4 6
730 730
580 703
185 185
QM070RF QM100RF
0.75kW 1.00kW
0.00 0.00
1.20kW 1.50kW
0.00 0.00
0.00 0.00
0.000 0.000
Yes
Yes
Yes
QM100RF QM125RF
681/740W 847/920W
7.7 - 7 Hours 7.7 - 7 Hours
15.4kWh 19.3kWh
11W
0.5W 0.5W
32
8
730
865
185
QM125RF QM150RF
1.25kW 1.50kW
0.00 0.00
1.70kW 2.00kW
0.00 0.00
0.00 0.00
0.000 0.000
QM150RF
1008/1100W
7.7 - 7 Hours
23.1kWh
11W 11W
0.5W
30 31
10 12
730 730
1069 1069
185 185
- 8 -
