Dimplex Quantam
User guide
Dimplex Quantum heaters are cool to the touch, so no need to worry about burning
yourself. It also means it has better insulation and can store the heat better and for longer.
Your heaters should be set up for what will suit you by the installer, but here you'll find
instructions on how to tweak the settings if you need to.
How do they work?
Each heater contains electric elements and special thermal bricks. The elements heat up
the bricks and the bricks give off heat slowly. Think of your heater as a battery, electricity
coming in 'charges' the elements, and the bricks 'discharge' (or 'uses') the stored heat. The
amount of electricity put into heater and the speed and temperature of heat coming out are
both controllable by you.
This guide is aimed at helping you get the most from your heaters.
Getting to know your new heaters
Your heater has four different timer modes and also a temperature setting.
The timer modes are fully adjustable so you can set them up to suit your needs and lifestyle.
The temperature displayed is the temperature that the heater is set to and not the actual
room temperature. The heater reads the temperature around itself and not the room
temperature.
Keep the space next to and in front of the heater free from obstacles or furniture so that
heater can accurately read the temperature. Placing items next to the heater will increase
the air temperature around the sensor, causing the heater to take a smaller charge and not
be as efficient.
You don't need to decide how much heat to store as the heater does that itself. Simply set
the timer mode and the temperature that suits you and leave the heater to meet your
requirements.
For the heater to work correctly, please make sure both wall switches are turned on. During
the summer when you're not using your heating, both wall switches can be turned off.
Yorkshire Housing
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dimplex Quantam
Summary of Contents for Dimplex Quantam
- Page 1 Dimplex Quantam User guide Dimplex Quantum heaters are cool to the touch, so no need to worry about burning yourself. It also means it has better insulation and can store the heat better and for longer. Your heaters should be set up for what will suit you by the installer, but here you’ll find instructions on how to tweak the settings if you need to.
- Page 2 Remember to turn both switches back on in autumn when you’re wanting to use your heaters again. Example If you’re a bit cold but your heater is set to 21°C your room, you can adjust the ‘set point’ on the timer settings. You don’t need to adjust the temperature on the heater during the day. If you do adjust the temperature, this reduces the stored heat (charge).
- Page 3 Setting up the temperature and your timer Set the temperature The temperature shown on the display is the room temperature set point. This is the temperature that the heater will maintain during the ‘Heating On’ periods. If the room temperature is above this temperature, then the fan will not operate. The heater levels are set at 21°C.
- Page 4 6. You can then select and change each option by rotating and pressing the dial to set it up to suit you. Changing the temperature ‘set point’: During the timer set up you can also adjust the temperature ‘set point’ which will alter the input (‘charge’) temperature for the heater.
- Page 5 This guide should help you get the most from your Quantum heating system but if you have any questions Dimplex have a customer web page where you can type in your question for assistance: www.dimplex.co.uk/dimplex-support Support : Dimplex Help Centre...
