A world of expertise
11854-2 Shetland
Rev. 221/229
Operating Instructions
IMPORTANT
These instructions should be read carefully and retained for
future use.
Note also the information presented on the appliance.
Quantum Heater
Models:
QM070
Boost
Output
230/240V~:
567/630W
Storage
Element
Rating
230/240V~:
1435/1560W 2042/2220W
Rated
Charge
Period:
7.7 - 7 Hours
Energy Cells:
18
Installed
Weight:
91kg
kWh:
10.9kWh
QM100
QM125
792/880W
1017/1130W
2540/2760W
24
30
115kg
142kg
15.5kWh
19.3kWh
QM150
1242/1380W
3024/3300W
36
165kg
23.1kWh
- 1 -
Advertisement
Table of Contents
Related Manuals for Dimplex QM070 QM100 QM125 QM150
Summary of Contents for Dimplex QM070 QM100 QM125 QM150
-
Page 1: Operating Instructions
Operating Instructions A world of expertise IMPORTANT These instructions should be read carefully and retained for future use. Note also the information presented on the appliance. Quantum Heater Models: QM070 QM100 QM125 QM150 Boost Output 230/240V~: 567/630W 792/880W 1017/1130W 1242/1380W Storage Element Rating... - Page 2 fi tted around the heater, as is normal with heating appliances in similar circumstances. A range of guards specially designed for Dimplex heaters is available. If you require further information on these guards, please see contact details on back page of these instructions.
- Page 3 CAUTION: DO NOT COVER SURFACES OF THE HEATER AND DO NOT OBSTRUCT AIR OUTLET GRILLES. • Surfaces of the heater should not be covered or obstructed as this can cause excessive temperatures that can be hazardous and may cause safety cut-outs to operate. This will stop the heater from working.
-
Page 4: The Benefi Ts Of Quantum
The benefi ts of Quantum Quantum is designed to be a responsive heating system that meets your comfort requirements while optimising energy use. The heater releases heat in two ways: A small amount of heat is dispersed by ‘natural’ convection and radiation from the heater case. The vast majority of heat is released using the built- in fan that pushes hot air out from the heat outlet grille at the bottom of the product. - Page 5 Function Compared with traditional storage heaters the amount of energy released from the outer case of the heater is signifi cantly reduced, resulting in lower surface UE TO THE LOW ENERGY LOSSES FROM temperatures. This allows more effi cient running because the Quantum is heating the room only when THE CASING OF THE HEATER THE SURFACE you want it to.
-
Page 6: Operation
Operation The user controls are located on the top right of the heater. The heater is fi tted with an adjustable electronic temperature controller and three buttons. Programmable timer Display screen ‘ Menu’ b utton ‘ Back’ button Advance ‘ ’... -
Page 7: Control Functions
Control Functions The heater controls can easily be adjusted by using a combination of the three buttons and the selector dial, which can be rotated and pressed. 1. The DISPLAY SCREEN shows the options available at each stage of the adjustment. 2. -
Page 8: Setting The Date And Time
Setting the Date and Time Your Quantum controller incorporates a real time clock with calendar function. The time clock has a battery backup that will keep the clock running in the event of a mains power outage. To adjust the time or date follow the steps below. Note - the display screen will return to standard display after a period of 20 seconds of inactivity. -
Page 9: Choosing And Setting A Timer Mode
Choosing and Setting a Timer Mode Your Quantum controller comes pre-programmed with a set of operating periods. There are three options available - two presets and one user adjustable timer; 1. Out All Day (pre-programmed) - has the following preset times Monday to Sunday, which can be altered if desired;... - Page 10 To choose a Timer Mode press Menu and rotate the Selector Dial to select ‘Timer Mode’. Main Menu Date / Time Timer Mode Options Select the mode required, again by rotating and pressing the Selector Dial. For options Out All Day, Home All Day and User Timer Mode Timer, three choices are available - Select, Preview Out All Day...
- Page 11 NCE MODIFIED A PROGRAMME MUST THEN BE SELECTED IF YOU WANT TO BEGIN USING IT Main Screen After 20 seconds the heater will default back to the Main Screen. Here the chosen temperature is displayed along with Comfort On or Comfort Off, which tells you whether you are in a timed heating period or not.
-
Page 12: Child Lock
Options The Options menu enables you to choose time formats to suit your preferences. These are; DST Rule - Select your daylight saving setting. Temp Units - Choose whether your unit displays degrees centrigrade or fahrenheit. Child Lock To lock the controls press Back and the Selector Dial Options together for 3 seconds. - Page 13 (such as soot or incense generated from the burning of candles, etc.). A suitable shelf (available from Dimplex) may be fi tted to limit the extent of any wall discolouration.
- Page 14 - 14 -...
- Page 15 - 15 -...
-
Page 16: After-Sale Service
If this product appears damaged when fi rst received or does not function correctly contact us by e-mail aftersales@ dimplex.co.uk or ring 0844 879 35 88 and we will be able to help. For ROI please phone 01 842 4833.
