Full Gauge Controls RT-607RiL power Manual page 2

5.2 - View maximum and minimum temperature
By pressing key one can view the minimum and maximum thermostat temperature. On pressing key
(short touch), the minimum temperature shall be displayed, followed by the maximum temperature.
If the key remains pressed in, the values will be reinitialized and the message
the display.
5.3 - Manual events activation
Pressing the key for 10 seconds, manually activate an event. It will be deactivated after the time
adjusted in the function elapses .
If the key is pressed again for 10 seconds, the manual drive will be disabled.
To deactivate the manual activation, all you have to do is configure function
The display will show the message when the manual drive is enabled and the
when the manual drive is disabled.
6. SIGNALLING
- Thermostat sensor disconnected or out of range
- Configuration parameters not programmed or out of range
EVENT
Led - Currently active event
7. UNIT SELECTION(°C / °F)
To define the unit that the system will use to operate, enter into the functions menu
access code "231" and confirm it by hitting key
or to choose between or
figure will appear, and the instrument will return to the function
altered, the parameters should be reconfigured, since they assume "standard" values.
8. WIRING DIAGRAM
THERM
1 3 4 5 6 7 8 9 10 11 12
2
0 115 V 230 V
(12 V) (24 V)
Load
Power
supply
RT-607Ri power RT-607RiL power
7 - 8 115V 12V
7 - 9 230V 24V
will be shown in
with the value " 000".
SET . The indication will appear, then press
and confirm with key SET . After selecting the unit the
. Whenever the unit is
Load
Dimension of the clipping
for setting of the instrument
supply
in panel
72 mm
IMPORTANT
According to the chapters of norm IEC 60364:
1: Install protector against overvoltage
2: Sensor cables and signal cables of the computer may be joined, but not in the same electric conduit
through which the electric input and the activation of the loads run
3: Install transient suppresors (RC filters) parallel to the loads as to increase the product life of the
relays.
message
Schematic for the connection of supresors
to contactors
A1
using the
PROTECTIVE VINYL:
This adhesive vinyl (included inside the packing) protects the instruments against
water drippings, as in commercial refrigerators, for example.
Do the application after finishing the electrical connections.
Remove the protective paper
and apply the vinyl on the entire
superior part of the device,
folding the flaps as indicated by
the arrows.
on the power supply
Schematic for the connection of supresors to
direct activation loads
A1 and A2 are the
contactor coil terminals.
A2
For direct activation the maximum
Load
specified current should be taken
into consideration.
