- Page 1 November 15, 2018 Lit. No. 72107, Rev. 02 Super Maxx™ Hopper Spreader SP-9300XH Owner's Manual and Installation Instructions Original Instructions CAUTION Read this document before operating or servicing the spreader. This manual supersedes all editions with an earlier date.
-
Page 3: Table Of Contents
TABLE OF CONTENTS PREFACE ..............5 ELECTRICAL DIAGRAM ......... 15 Warranty Registration ........... 5 Control and Harness Diagram ......15 Owner's Information Form ........5 OPERATING THE SPREADER ........ 16 SAFETY ..............6 Operating the Spreader – Cab Control ....16 Safety Defi... -
Page 5: Preface
Warranty Registration This manual has been prepared to acquaint you with the safety information, operation, and maintenance of your new hopper spreader. Please read this manual Follow the directions on the SnowEx ® Warranty carefully and follow all recommendations. This will Registration and Customer Survey form included in help ensure profi... -
Page 6: Safety
SAFETY SAFETY DEFINITIONS WARNING/CAUTION LABELS Become familiar with and inform users about the WARNING warning and caution labels on the spreader. Indicates a potentially hazardous situation that, if not avoided, could result in death or NOTE: If labels are missing or cannot be read, see serious personal injury. - Page 7 SAFETY WARNING/CAUTION LABELS Become familiar with and inform users about the warning and caution labels on the spreader. NOTE: If labels are missing or cannot be read, see your sales outlet. PASSENGER'S SIDE Lit. No. 72107, Rev. 02 November 15, 2018...
-
Page 8: Serial Number Label
SAFETY SERIAL NUMBER LABEL Madison Heights, MI 48071 U.S.A. 1-800-725-8377 trynexfactory.com Model No. SP0000 Serial No. 000000000000SP0000 Manuf. 2014 Madison Heights, MI 48071 U.S.A. 1-800-725-8377 trynexfactory.com Code Defi nition 2-Digit Year Model No. SP0000E 2-Digit Month 2-Digit Day Serial No. YYMMDDLLXXXXZZZZZZ 2-Digit Location Code XXXX 4-Digit Sequential Number... -
Page 9: Safety Precautions
SAFETY SAFETY PRECAUTIONS CAUTION During the hopper installation we recommend Improper installation and operation could cause the addition of an OSHA compliant Backup personal injury and/or equipment and property Alarm. This alarm is required for OSHA damage. Read and understand labels and this governed employers. -
Page 10: Personal Safety
SAFETY PERSONAL SAFETY BATTERY SAFETY CAUTION • Remove ignition key and put the vehicle in PARK or in gear to prevent others from starting the Batteries normally produce explosive gases vehicle during installation or service. which can cause personal injury. Therefore, do not allow fl... -
Page 11: Loading
LOADING DETERMINING VEHICLE PAYLOAD This Owner's Manual covers vehicles that have been recommended for carrying the hopper spreader. Please see your local dealer for proper vehicle applications. WARNING CERTIFICATION Overloading could result in an accident or damage. Do not exceed GVWR or GAWR ratings as found on the driver-side door WARNING cornerpost of the vehicle. -
Page 12: Mounting The Spreader
MOUNTING THE SPREADER MOUNTING INSTRUCTIONS 6. There are four holes in the bottom fl ange of each sideframe. These holes are on the bottom and will be used to mount the spreader to the truck body. WARNING There are also two holes in the rear stop bracket. Spreader shall be bolted to vehicle frame. - Page 13 MOUNTING THE SPREADER WARNING Rear stop bar, ratchet straps, and mount kit must always be in place. All mounting systems work together; none of them should be used exclusive of the other methods. Do not remove unless servicing spreader or removing the spreader from vehicle.
-
Page 14: Installing Electrical Harnesses
INSTALLING ELECTRICAL HARNESSES WIRING INSTRUCTIONS CAUTION Do not alter, modify, or install additional 1. Mount the rear plug bracket on the back of the components in shaded areas shown below. vehicle using supplied fasteners. Locate the Failure to comply may interfere with airbag bracket toward the center of the bumper, as that deployment or cause injury to operator in an will reduce the amount of debris getting onto the... -
Page 15: Electrical Diagram
ELECTRICAL DIAGRAM CONTROL AND HARNESS DIAGRAM Control Anderson 4-Pole Connector Connect to back of control. CHMSL Connect to Vibrator Anderson 2-Pole Connector Connect to back of control. Spreader Vehicle Harness Harness Dust Cap Work Light Lit. No. 72107, Rev. 02 November 15, 2018... -
Page 16: Operating The Spreader
OPERATING THE SPREADER OPERATING THE SPREADER – Press the Start/Stop button. The auger and spinner will begin to turn, spreading material. CAB CONTROL Use the dials on the control pendant to adjust the WARNING material distribution shaft speed. This will change the spread rate at constant vehicle speed. -
Page 17: Adjusting The Spinner
OPERATING THE SPREADER ADJUSTING THE SPINNER Before operating the spreader, spread some material The spreader is equipped with an adjustable spinner in a clear area where the spread pattern can be easily to assist in more precise material application. The observed to see how it changes with fi... -
Page 18: Inverted V
Always disconnect the power source before attempting to remove the auger discharge trough. The Super Maxx SP-9300XH hopper spreader uses an auger discharge trough to reduce material leakage. It must not be removed unless servicing the unit. Lit. No. 72107, Rev. 02... -
Page 19: Maintenance
MAINTENANCE LUBRICATION WARNING Never remove the spreader with material in To keep your spreader running smoothly, observe the the hopper. following recommendations: • Lubricate bearings after every 20 hours of use. CAUTION Disconnect electric power at spreader • Apply a small amount of light oil to latches as electrical wiring harness connection and tag needed. -
Page 20: At The End Of Each Season Or After Extended Storage
MAINTENANCE AT THE END OF EACH SEASON FUSE REPLACEMENT OR AFTER EXTENDED STORAGE If a problem should occur and fuse replacement is necessary, the replacement fuse must be of the same • Apply dielectric grease on all electrical type and amperage rating as the original. Installing a connections to prevent corrosion at the beginning fuse with a higher rating can damage the system and and end of the season and each time the power... -
Page 21: Troubleshooting Guide
TROUBLESHOOTING GUIDE MODEL SP-9300XH Preliminary Checks • Verify that all electrical connections are tight and clean. • Verify that nothing is jammed in the hopper. • Verify that all hydraulic connections are properly connected. Problem Possible Cause Suggested Solution Loose hose connection Check all connections Motor doesn't run Low fl... -
Page 22: Troubleshooting Material Flow
Slow material fl ow Turn on vibrator Increase auger speed Material issue SnowEx Diagnostic Test Kit (STK-090) is available to accurately diagnose any issues with SnowEx spreaders. ® Call your dealer for details. Lit. No. 72107, Rev. 02 November 15, 2018... - Page 24 Do not exceed vehicle ratings with a spreader. TrynEx International offers a limited warranty for all spreaders and accessories. See separately printed page for this important information. The following are registered ( ® ) or unregistered (™) trademarks of Douglas Dynamics, LLC: SnowEx , Super Maxx™. ® Printed in U.S.A.
