QUICKSTART
KM 120/150 R Bp/Bp Pack
Start up
1
A
A
2
A
D
Warning
These are only brief instructions! Please read and comply with these instructions prior to using or servicing your
appliance.
The non-compliance of the operating and safety instructions may lead to damages of the appliance and to dangers
for the operator and other persons.
B
B
B
C
C
C
Bp model
A Open the device hood.
B Switch off the charger and remove the plug
from the socket.
Pull the battery cable from the charger cable
and connect it to the appliance.
C Close cover.
Bp Pack model
A Open the device hood.
B Unplug the charger from the mains.
Place the mains cable into the storage com-
partment.
C Close cover.
A Pull seat adjustment lever outwards.
B Move seat, release lever and
lock in place.
Check that the seat is properly locked in
position by attempting to move it backwards
and forwards.
C Adjust the seat back.
D Position the steering wheel.
5.964-011.0 07/11
