ElMod Fusion ECO Detailed Installation Instructions And User Manual page 3

are set up correctly.
• when only one motor is attached proceed accordingly. Release the button when the motor rotates forward.
Commercially available external drivers may be connected directly to the
must be set by the ElMod App
simultaneously. The external drivers are connected with the connectors 9. The black ground wire of the
drivers points to the right edge of the PCB (towards the battery connector).
The smoke generator is connected to the connector for the smoke generator (connector 10).
• if the smoker generator provides two wire operation only (combined fan and heater), attach it to the fan
labeled connector
• if the smoker generator provides four wire operation (separated fan and heater wires), attach the fan
wires and the heater wires to the respective connector
• the polarity of the connectors are printed on the board
The ElMod Fusion provides a HengLong
turret rotation motor, gun elevation motor, main gun trigger motor, front lighting and muzzle flash of the
main MG.
• an optional adapter allows the use of a Tamiya
muzzle flash of the main MG are supported
• an optional cable offers the connection of a turret with a different wiring to the
The voltage on all turret components is always equal to the voltage of the battery. If you plan to use motors with lower voltage, reduce
the setting for maximum speed in the ElMod App of the corresponding motor. For example the maximum speed of a 7.2 V motor in a
Also keep in mind that the maximum current per motor must not exceed 2 A. Higher current may destroy the electronics.
In principle, all HengLong ®
attached to connector 1. In this case the shot function is active as long as the trigger is actuated.
Depending on the assignment of the plugs and the settings in the
extended. The corresponding parameter "Recoil Type" in the
tab.
• Setting Standard corresponds to the basic setting (turret cable only). If the ground cable of the shot
system is also connected to the negative pole of the battery, the firing mechanism automatically
returns to its initial position after the trigger is released.
• Setting Airsoft is suitable for the firing mechanism for plastic balls. The shot sound sounds at the same
time as the ball is fired. For this purpose, one more cable must be connected in addition to the 8-wire
turret cable and the ground wire. The white-orange cable from the switch for the position of the
shooting mechanism has to be attached to connector 12. The orange wire points to the edge of the
board (mark "O" at the bottom of the board).
• Setting Airsoft with recoil
simultaneous recoil mechanics via a turret built-in control electronics with a servo. The wiring is the same as for the airsoft shot
function. Additionally electronics for the recoil mechanics has to be attached to connector 11. Plus and minus are marked on the
board and correspond to the red or black wire of the cable.
• Setting Tamiya Recoil is intended for the Tamiya
connector 4. The white cable faces the marking (golden dot) on the upper side of the board.
If your cabling differs from the one described here or if you are unsure, please contact your dealer's support! Errors in the wiring can
A further possibility to simulate the barrel recoil is the use of a dedicated servo with the appropriate mechanics. Details are described
in this section Servos. The servo recoil is independent of the setting "Recoil Type" in the
The HengLong ® /Taigen ® Xenon flash or the HengLong
connector 2. The Tamiya ®
ElMod LED Flash Booster
Connection of the drive motors (external drivers)
(tab "drive", parameter "motor drivers"). It is not possible to operate integrated and external drivers
Smoke generator
Turret functions
compatible 8-pin turret terminal (connector 1). It is used by the
®
® turret. The functions turret rotation, main gun elevation and also main lighting and
12 V tank should not excess 60% (60% of 12V = 7,2V).
Shot function
/Taigen ® shot systems are operable as soon as the 8-wire turret cable is
is suitable for tanks with a firing mechanism for plastic balls AND
®
damage or destroy the electronics of the tank or the ElMod circuit board!
Xenon flash is not supported. If an LED is used, the flash may be weak depending on the type of LED. The
provides a bright LED flash in this case.
ElMod
ElMod App, this basic function can be
ElMod App can be found in the "Weapons"
recoil mechanics. For this the connector of the mechanics has to be attached to
Muzzle flash
® muzzle flash LED are equipped with a 5-pin plug and has to be connected to
- 3 -
Fusion. The operating type (internal/external drivers)
ElMod Fusion board.
ElMod App.
© ElMod - 19-09-02
