Components and Specifications

Materials: polyester and galvanized steel.
Hardware for part #s 01752 - 01755 is manufactured from powder-coated steel.
Part # Size
01700 S - L
01701 XL - XXL
01702 S - L
01703 S - L
01704 XL - XXL
01705 S - L
01706 XL - XXL
01750 S - L
01751 S - L
01752 S - L
01753 XL - XXL
01754 S - L
01755
XL - XXL
99-02-0041 S

Installation and Use

All PFAS equipment must be selected and deemed compatible with Velocity Harness by a Competent
Person. ALWAYS follow all instructions of all equipment used in combination with Velocity Harness.
NEVER attach connector to any place on harness other than D-ring. Connector gate must be self-closing
and self-locking, and must withstand minimum load of 3,600 lbs. Any excess strap webbing MUST be
stored in harness Webbing Keepers.
To connect Pass-Through Buckle, angle male buckle so it is positioned to
pass up and through female buckle. Fully insert male buckle so that it lies
flat on top of female buckle.
To connect Tongue Buckle, pull webbing strap through framed tongue component,
and insert framed tongue through grommet to secure.
Roller and Friction Adjustments allow the user to make adjustments to Velocity Harness straps.
Feed webbing through buckle, and slide the buckle down on the strap to tighten, or slide the
buckle up on the strap to loosen.
To adjust dorsal D-ring, slide placard up or down webbing. Dorsal D-ring must rest between the
middle of the shoulder blades.
Dorsal D-ring, chest strap, shoulder straps, and leg straps
Velocity w/ PT Chest & PT Legs
Velocity w/ PT Chest & PT Legs
Velocity w/ 3 D-rings, PT Chest, & PT Legs
Velocity w/ PT Chest & TB Legs
Velocity w/ PT Chest & TB Legs
Velocity w/ 3 D-rings, PT Chest & TB Legs
Velocity w/ 3 D-rings, PT Chest & TB Legs
Surfacetech Web Velocity Harness w/TB Legs
Surfacetech Web Velocity Harness w/TB Legs & Side D-rings
Hawk Harness w/ PT Chest & TB Legs
Hawk Harness w/ PT Chest & TB Legs
Hawk Harness w/ PT Chest & PT Legs
Hawk Harness w/ PT Chest & PT Legs
Velocity w/ PT Chest & TB Legs
MUST be fitted for each individual user.
Description
