CBS-1100V+
™
Programming Guide
Models:
CBS-1131V+; CBS-1132V+
CBS-1151V+; CBS-1152V+
(800) 338-2699
(847) 719-3000
techsupport@fetco.com
www.fetco.com
© 2008-2018
Food Equipment Technologies Company
Part # P172
January 2018
FETCO®, EXTRACTOR® and V+ are trademarks or trade names of Food Equipment Technologies Company.
Advertisement
Related Manuals for Fetco EXTRACTOR CBS-1131V+
Summary of Contents for Fetco EXTRACTOR CBS-1131V+
- Page 1 CBS-1100V+ ™ Programming Guide Models: CBS-1131V+; CBS-1132V+ CBS-1151V+; CBS-1152V+ (800) 338-2699 (847) 719-3000 techsupport@fetco.com www.fetco.com © 2008-2018 Food Equipment Technologies Company Part # P172 January 2018 FETCO®, EXTRACTOR® and V+ are trademarks or trade names of Food Equipment Technologies Company.
- Page 2 The topics are in groups A-E in this guide. “F” screen is Save and Exit Check the user guide for more comprehensive details of the brewer settings. User guides are located online at fetco.com in Service-Resources….or use our QR code...
- Page 3 Popular Operator Control Settings Default Settings-(Factory Settings) CBS-1131V+ CBS-1151V+ Parameter Name CBS-1132V+ CBS-1152V+ Brew Volume 3 LTR 1.5 GAL Brew Time (Min:Sec) 4:00 4:00 Prewet Percent Prewet Delay (Min:Sec) 1:00 1:00 This appears only when Prewet >0% Drip Delay (Min:Sec) 1:30 1:30 Hot Water Tank Temp.
- Page 4 HOW TO ENTER PROGRAMMING MODE TO ACCESS CONTROLS AND DIAGNOSTICS 1)Turn the brewer off by pressing the power switch. DISPLAY 2)Turn power switch “ON” CBS-1132V+ -The display will progress through startup screens. STOP STOP Menu Topic CBS-1132V+ Example: v 1 . 0. 1744 Brewer and version code Menu Position -The STOP button will illuminate.
- Page 5 To change recipes Illustration shows each recipe batch position CBS-1132V+ All recipe programming is made from the “A” screens TO ACCESS BATCH RECIPES: STOP STOP -Enter “A”-BATCH PRG A10 A40 -Press button “A10” to scroll through the parameters Press “STOP” to scroll across the other recipe buttons Single brewer has 3 recipes.
- Page 6 -After all brew recipes are set press STOP button to go to–GENERAL “B” B1 is Tank Temperature This controls the brew water temperature and the hot water service faucet Toggle buttons A20 and A30 to make changes Tank Temp Then press A10 to advance First programming position “B1”...
- Page 7 Batch Parameters –A-MENU and PROGRAMMING Brewers are shipped with all recipe batch buttons enabled and set to the defaults shown in A1-A6. These are full batches. Adjust settings of the individual recipes under batch PRG “A” Position Name and default setting Range Comment A.20,30...
- Page 8 B-E Advanced Settings and Diagnostics Batch Parameters – B-GENERAL settings Position Name and default setting Range Comment Tank Temperature 70° to 96°C NOTE: Equipment factory 93° C -or- 200°F 157° to 205°F default is set for metric Brew at Temp. Setpoint Batch to start when at set YES/NO “YES”...
- Page 9 Batch Parameters – C-INPUTS controls & conditions Position Name and default setting Range Comment LLC Probe Continuity Reading of tank water Reading of tank water resistivity Direct Read resistivity in TDS in TDS Brew Basket Sensor YES/NO YES or NO Tank Temp.
- Page 10 Use this formula to compensate for minor discrepancies in actual volume versus programmed volume Measured Volume Current Use this formula to determine the new setting: Enter new setting in B6 or B7 -See user guide. Programmed Volume Setting Setting Use the formula above to compensate and fine-tune brew volume. TIP:check flow from supply for fouled water filter Brew valve flow rates are in liter/min Enter the New Setting value into B6/B7 and save as in the “F”...
- Page 11 Resetting error codes should be after completing the service and factory diagnostics and correcting any brewer faults. Clear error codes by cycling the brewer “OFF” then “ON”. NOTE: Always contact FETCO Reset Errors YES/NO Technical Service for errors...
- Page 12 Batch Parameters F–HOW TO SAVE SETTINGS –EXIT & RETURN TO PROGAMMING IMPORTANT! After programming, you MUST SAVE your settings before exiting programming mode or changes will be lost. Settings are saved from the “F” screen as shown below. You may exit programming at any time. After programmed settings are saved, the brewer exits PROGRAMMING mode and returns to regular brew operations.
