Summary of Contents for Stanley STAPB70
- Page 3 OWNER’S MANUAL WARNING This appliance can be used by children aged from 8 years and above and any persons, provided they have experience and knowledge regarding the use of the product, or supervision or instruction regarding the use of the appliance in a safe way, and understand the hazards involved. Children shall not play with the appliance.
- Page 4 Contents 1. Applications 2. Model Description 3. Hydraulic Performance Curve - STAPB70 4. Hydraulic Performance Curve - STAPB120 5. Safety Precautions 6. Product Structure 7. Dimension 8. Pipeline Installation 9. Electrical Connection 10. Start-up and Maintenance 11. Troubleshooting - 2 -...
- Page 10 8. Pipeline Installation WARNING This product should be installed and maintained by a qualified person, or someone who has read this manual and understands the use requirements. Installation and operation should be in accordance with local regulations and recognized operation standards. Install pipelines properly as stipulated in the manual, and conduct frost protection measures for the pipeline.
- Page 11 OWNER’S MANUAL 5. Drain plug 1. Foot valve 6. Electric pump 2. Inlet pipe 7. Valve 3. Tie-in 4. Filling plug B: Installation precautions for inlet pipelines 1. While installing the electric pump, do not use too soft rubber tube for the inlet pipeline. This avoids it being sucked flat.
- Page 12 9. Electrical Connection WARNING Unless the power is off, do not touch the wiring in the junction box. The electric pump should have reliable grounding to prevent current leakage with leakage protection switch being equipped. 1. Electrical connection and protection should be conducted according to stipulations. Specification of working voltage is marked on the nameplate;...
- Page 13 OWNER’S MANUAL 10. Start-up and Maintenance WARNING Do not start up the pump before the pump chamber is filled with water. Do not touch the electric pump unless its power has been cut off for at least 5 minutes. Do not dismount the pump body unless water in the pump chamber is emptied. Rotate the fan blade before startup, check whether the pump rotation is flexible and then unscrew the water-filling plug, fill the pump...
- Page 14 11. Troubleshooting WARNING Check the pump after power cut-off. - 12 -...
- Page 15 OWNER’S MANUAL - 13 -...
