TP08
HYDRAULIC
TRASH PUMP
(TP0813X, TP08013XB, TP08013XCS, TP0813XW)
USER MANUAL
Safety, Operation and Maintenance
© 2014 STANLEY Black & Decker, Inc.
New Britain, CT 06053
U.S.A.
66364 1/2020 Ver. 22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP0813X and is the answer not in the manual?

Questions and answers

Summary of Contents for Stanley TP0813X

  • Page 1 TP08 HYDRAULIC TRASH PUMP (TP0813X, TP08013XB, TP08013XCS, TP0813XW) USER MANUAL Safety, Operation and Maintenance © 2014 STANLEY Black & Decker, Inc. New Britain, CT 06053 U.S.A. 66364 1/2020 Ver. 22...
  • Page 2 Provisiones especiales: Disposizioni speciali: Representative in the Union: Patrick Vervier, Stanley Dubuis 17-19, rue Jules Berthonneau-BP 3406 41034 Blois Cedex, France. Vertreter in der Union/Représentant dans l’union/Representante en la Union/Rappresentante presso l’Unione Done at/Ort/Fait à/Dado en/Fatto a STANLEY Infrastructure, Portland, Oregon USA...
  • Page 3: Table Of Contents

    REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN AUTHORIZED AND CERTIFIED DEALER. For the nearest certified dealer, call STANLEY Infrastructure at (503) 659-5660 and ask for a Customer Service Representative. TP08 User Manual ◄ 3...
  • Page 4: Safety Symbols

    SAFETY SYMBOLS Safety symbols and signal words, as shown below, are used to emphasize all operator, maintenance and repair actions which, if not strictly followed, could result in a life-threatening situation, bodily injury or damage to equipment. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 5: Safety Precautions

    Always keep critical tool markings, such as labels and warning stickers, legible. • Always replace parts with replacement parts recommended by STANLEY. • Check fastener tightness often and before each use • Operator must start in a work area without daily.
  • Page 6: Tool Stickers & Tags

    USE ONLY PARTS AND REPAIR USE ONLY PARTS AND REPAIR PROCEDURES APPROVED BY PROCEDURES APPROVED BY STANLEY AND DESCRIBED IN THE STANLEY AND DESCRIBED IN THE OPERATION MANUAL. OPERATION MANUAL. TAG TO BE REMOVED ONLY BY TAG TO BE REMOVED ONLY BY TOOL OPERATOR.
  • Page 7: Hose Types

    This hose is not certifi ed non-conductive and must never be used near electrical conductors. HOSE SAFETY TAGS To help ensure your safety, the following DANGER tags are attached to all hose purchased from STANLEY. DO NOT REMOVE THESE TAGS.
  • Page 8: Hose Recommendations

    HOSE RECOMMENDATIONS 8 ► TP08 User Manual...
  • Page 9: Htma/Ehtma Requirements

    HTMA/EHTMA REQUIREMENTS HTMA / EHTMA REQUIREMENTS TOOL TYPE HTMA TYPE I TYPE II TYPE RR TYPE III HYDRAULIC SYSTEM REQUIREMENTS 4-6 GPM 7-9 GPM 9-10.5 GPM 11-13 GPM Flow range (15-23 LPM) (26-34 LPM) (34-40 LPM) (42-49 LPM) Nominal operating pressure 1500 psi 1500 psi 1500 psi...
  • Page 10: Operation

    Observe the following for trash pump hose. For high-pressure water pumping, use a protection and care. STANLEY SM20 or SM50 and nozzle. The TP08 is designed for high GPM water flow at low water The trash pump must maintain a mini mum impeller pressure (head).
  • Page 11 OPERATION begins to slow, turn off the hydraulic power source and lift the trash pump from the work area. Disconnect the hydraulic hoses and clean at the water hose and the pumping chamber. Pumping liquids with a solids-to liquid ratio greater than 30 per cent will cause impeller wear.
  • Page 12: Tool Protection & Care

    Do not reverse circuit flow. This can cause damage to internal seals. • Always replace hoses, couplings and other parts with replacement parts recommended by STANLEY. Supply hoses must have a minimum working pressure rating of 2500 psi/172 bar. •...
  • Page 13: Troubleshooting

    TROUBLESHOOTING If symptoms of poor performance develop, the following chart can be used as a guide to correct the problem. When diagnosing faults in operation of the tool, always make sure the hydraulic power source is supplying the correct hydraulic flow and pressure as listed in the table. Use a flowmeter know to be accurate. Check the flow with the hydraulic fluid temperature at least 80 °F/27 °C.
  • Page 14: Specifications

    SPECIFICATIONS Capacity............................800 GPM/3028 LPM Weight ..............................59 lbs/26.7 kg Height (over handle) ..........................16.5 in./42 cm Length..............................19 in./48.3 cm Width ..............................15 in./38.1 cm Pressure ............................2000 psi/140 bar Flow Range ..........................7–10 GPM/26–38 LPM Maximum Flow ..........................10 GPM/38 LPM Porting ......................
  • Page 15: Tp08 Body Illustration

    TP08 BODY ILLUSTRATION ITEM DESCRIPTION 81135 CAP SCREW 81123 HANDLE 81122 HANDLE PLATE 09578 COUPLER - MODEL TP0813XW 09579 COUPLER - MODEL TP0813XW 01652 HOSE WHIP - MODEL TP0813XW 82532 FITTING - MODEL TP0813XW 82533 FITTING - MODEL TP0813XW 81124 WING NUT 22752 NUT - MODEL TP08013XCS...
  • Page 16: Tp08 Impeller Illustration

    TP08 IMPELLER ILLUSTRATION ITEM DESCRIPTION SEE PAGE 17 00600 WOODRUFF KEY 81215 TOOL NAME TAG 82595 MOTOR ADAPTOR PLATE 73061 CAP SCREW 81133 SHIM 81260 WEAR PLATE 21989 CAP SCREW 81121 VOLUTE WELDMENT 26297 CAP SCREW 21979 IMPELLER 03827 WASHER 21988 ACORN NUT 16 ►...
  • Page 17: Tp08 Motor Illustration

    TP08 MOTOR ILLUSTRATION ITEM DESCRIPTION 03975 COUPLER 03976 COUPLER 06264 FITTING 07882 FITTING 21986 CAP SCREW 82595 MOTOR CAP ASSEMBLY 15385 O-RING 22065 DOWEL PIN 21974 GEAR 21982 GEAR 19793 BUSHING 21984 IDLER SHAFT 82592 FLANGE 82594 MOTOR SHAFT 82602 WOODRUFF KEY 19793 BUSHING...
  • Page 18: Service

    UNDERWATER TOOLS DEPTH GUIDELINE UNDERWATER MODELS ONLY OPERATION OVERVIEW PERCUSSIVE ROTATIONAL Tools: Breakers, Tools: Grinders, Hammer Drills and Saws, Chain Saws Do not use hydraulic tools underwater that are not designated as an “underwater” model, or this will Chipping Hammers result in damage to the tool.
  • Page 20 STANLEY Infrastructure 6430 SE Lake Road Portland, Oregon 97222 USA (503) 659-5660 / Fax (503) 652-1780 www.stanleyinfrastructure.com...
