Becker CentralControl CC31 Commissioning Instructions
  1. Manuals
  2. Brands
  3. Becker Manuals
  4. Controller
  5. CentralControl CC31
  6. Commissioning instructions

Becker CentralControl CC31 Commissioning Instructions

Hide thumbs Also See for CentralControl CC31:
Table of Contents

Advertisement

Quick Links

CentralControl
CC31
Commissioning instructions
en
Central Controller
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
4035 630 087 0a     21/07/2017
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CentralControl CC31 and is the answer not in the manual?

Questions and answers

Related Manuals for Becker CentralControl CC31

Summary of Contents for Becker CentralControl CC31

  • Page 1 CentralControl CC31 Commissioning instructions Central Controller Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 4035 630 087 0a     21/07/2017    Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany www.becker-antriebe.com...

  • Page 2: Table Of Contents

    Table of contents General ........................  3 Warranty ...................... 3 Items included ......................  4 Safety instructions .................... 4 Intended use ...................... 5 Dimensions ...................... 6 Device overview .................... 6 Online documentation ...................  8 Preparation for Commissioning ................ 9 Start / standard screen.................. 11 Commissioning, step-by-step ................ 12 Selecting a language..................

  • Page 3: General

    KNX radio and the Centronic I and II range of controls. This device uses free/open source software. The source code can be downloaded from http://www.b-tronic.net/source/. On request, Becker Antriebe will make the source code available on a CD-ROM at cost price. Please contact source@b-tronic.net if you are interested.

  • Page 4: Items Included

    Items included • B-Tronic CentralControl controller • USB WLAN stick • USB Flash memory stick • USB Centronic stick • USB B-Tronic/KNX stick (optional) • Mains adapter • Radio keypad • Commissioning instructions Safety instructions General information • Please keep the instructions safe! •...

  • Page 5: Intended Use

    Attention • Do not let any objects fall onto the control unit. • If a display is present, protect it against being scratched by hard ob- jects (e.g. rings, fingernails, wristwatches) • Wait until the control unit has adjusted to ambient temperature be- fore connecting the control unit to the mains adapter.

  • Page 6: Dimensions

    Dimensions All dimensions in mm. 28,5 Device overview Connections / slots 1. Mains connection 7. USB connection for KNX stick 2. LAN connection 8. USB connection for Centronic stick 3. HDMI connection 9. USB connection for keypad stick 4. AV connection 10.
  • Page 7 Rear of the device B-Tronic CentralControl CC31 4035 200 019 0 IP20 SSID: CC31-XXXX : WPACC31-YYY IP: 192.168.31.1 MAC-ETH: b4:4a:bc:03:09:aa Serial: 256854214587 1. WLAN wireless network (SSID) 2. WLAN network key (KEY)

  • Page 8: Online Documentation

    8. Compartment for keypad receiver 4. No function 9. Battery compartment cover 5. Light button Online documentation In addition to the present commissioning instructions, we make comprehensive docu- mentation available to you online. Please visit the following Internet site: http://www.becker-antriebe.net/centralcontrol/.

  • Page 9: Preparation For Commissioning

    Preparation for Commissioning Insert the supplied stick into the B-Tronic CentralControl in accordance with the Device overview [} 6]. There are a number of display options: • Via television or screen • Via PC, notebook or tablet Via television or screen 1.
  • Page 10 5. Now open your browser via the input device. 6. Type the following address into the browser's address bar: http://192.168.31.1/ and confirm it by pressing Enter. 7. Now click on the cogwheel in the top right-hand corner with the arrow. 8.

  • Page 11: Start / Standard Screen

    Start / standard screen 1 Main screen area The time and date, and in some cases the weather forecast, are displayed on the main screen area. 2 Navigation and status area The current weather, status information, and the navigation elements for the pro- grammed receivers are shown in the navigation and status area.

  • Page 12: Commissioning, Step-By-Step

    Network via cable No network via cable Access point available Fault indication An update is available The display of blue triangles indicates that more content is available in the main screen area by scrolling up or down. 6 Main navigation The main navigation is visible, with an identical format, on all the screens.

  • Page 13: Selecting A Language

    Selecting a language 1 Please press the "Programs and set- tings" button. 2 On the "Programs and settings" screen you should now select the "Configuration" Settings Configuration menu item. House installation Select an application Cameras Radio System information 3 Now select "Selecting a language" in the configuration menu.

  • Page 14: Network Settings

    Network settings The full home automation functionality of the B-Tronic CentralControl is available even when it is not connected to a network. However, some additional functions and access options are only possible with network or Internet access. In order to be able to use these functions, make sure that the B-Tronic CentralControl is connected to your network, that there is an Internet connection, and that the time is set correctly.
  • Page 15 4 You can change the name of the B- Host name Tronic CentralControl here. Network Network CentralControl 5 Selection for access point (configura- configuration tion WLAN of the B-Tronic CentralControl. Interface Only available on the CC31) Ethernet Activate access point (wired network installation) or WiFi Ethernet (WLAN / radio network installation).

  • Page 16: Date / Time

    7 Key = password (this is only needed for WiFi / WLAN con- Key / password (PSK) nections) Please note that the central control can Network configuration only be linked into a network by means of WiFi / WLAN if the WPA2 encryption is Automatic (DHCP) switched on at the router.
  • Page 17 2 On the "Programs and settings" screen you should now select the "Configuration" Settings Configuration menu item. House installation Select an application Cameras Radio System information 3 Now select "Date / time" in the config- uration menu. Configuration Selecting a language Please select the Network settings desired menu item...

  • Page 18: Select Weather Location

    Select weather location Displaying the weather data requires an Internet connection. In order to be able to display the correct weather data on your B-Tronic CentralControl it is necessary to provide the location for which the weather data is to be displayed. If the place you want is not available in the selection list, choose the nearest larger city.
  • Page 19 4 The location that is currently set for the weather data is shown on the display. Location: Weather Location for weather Sinn, Germany 5 To change the location, click the field information where the name is displayed. Options Set using location data 6 Now enter the location that you want.

  • Page 20: Programming Receivers

    12 After the central controller has entered the weather location according to your Configuration Network settings specifications, the screen returns auto- Please select the Date / time matically to the previous menu. desired menu item Select weather location Location Programming receivers 1 Please press the "Programs and set- tings"...
  • Page 21 4 Select the [ + ] button in order to add a receiver. Receiver Drive Centronic installation Add / select Dimmer KNX receiver Switch KNX Socket switch KNX A name is first assigned to a new receiver. Receiver name: Do please make sure that you name the receiver receivers in a meaningful way, so that Configure...
  • Page 22 8 Selecting the receiver type. Receiver name: Two options are available: receiver Receiver - B-Tronic / KNX (bidirectional - with con- Configure Receiver type: firmation function) settings B-Tronic / KNX-RF - Centronic (unidirectional - without con- Centronic firmation function) Device type: Only certain device types are available for selection, depending on the selected re- Tubular drive / ext.

  • Page 23: Creating Rooms

    13 In addition to the information on the screen saying that the programming has Program The receiver has been successfully programmed been completed successfully, many re- and can now be added B-Tronic / KNX-RF ceivers also confirm correct program- to groups or rooms. ming.
  • Page 24 2 On the "Programs and settings" screen you should now select the "House install- Settings Configuration ation" menu item. House installation Select an application Cameras Radio System information 3 On the "House installation" screen you should now select the "Rooms" menu Setup Receiver item.

  • Page 25: Add Receivers To Rooms

    6 The keyboard opens. Enter the name of the new room here. New room Bedroom The name "Bedroom" has been used in Please enter a name the example. 7 You confirm your input and close the keyboard with the green tick. 8 The new room can now be seen in the room selection menu.
  • Page 26 3 On the "House installation" screen you should now select the "Rooms" menu Setup Receiver item. Please select Groups a function Scenarios Rooms Timers 4 Choose the room in which you want to add receivers. Rooms Bedroom For example: Bedroom Add / select Living room room...

  • Page 27: Creating Groups

    8 The chosen receiver (switch) has now been assigned to the room (Bedroom), Bedroom Switch and appears in the list of receivers con- Add / select tained in the room. receiver or edit room Creating groups A "group" is a number of receivers combined on one channel of the transmitter. All re- ceivers in a group respond jointly to signals from the transmitter.
  • Page 28 3 On the "House installation" screen you should now select the "Groups" menu Setup Receiver item. Please select Groups a function Scenarios Rooms Timers 4 Select the [ + ] button in order to add a Group group. Switch setup Add / select Drives group...

  • Page 29: Program Receivers For Groups

    9 You confirm your entries about the new group and close the menu with the green Name group tick. new group Adjust settings Tubular drive / ext. Switching actuator Dimming actuator 10 The new group is now visible in the list Group of all groups.
  • Page 30 3 On the "House installation" screen you should now select the "Groups" menu Setup Receiver item. Please select Groups a function Scenarios Rooms Timers 4 Select the group to which you want to Group assign receivers. new group setup For example: "New group" Add / select Switch group...
  • Page 31 8 The chosen receiver (B-Tronic drive) has now been assigned to the group (New New group Drive B-Tronic group), and appears in the list of receivers Add / select contained in the group. receiver...

  • Page 32: Operation

    Operation Operating receivers 1. Press the button in order to open the "My house" menu. 2. Now select the room you want. 3. Then choose the receiver that is to be operated. 4. You can now operate the receiver. 5. Press the " "...

  • Page 33: Dimmer Receiver

    Dimmer receiver With B-Tronic receivers you get feedback on the current status and have the option of tapping the desired position on the status display in order to initiate a corresponding dimming command. UP button STOP button DOWN button Intermediate position 1 Intermediate position 2 Status display...

  • Page 34: Switch Receivers

    Switch receivers With B-Tronic receivers you get feedback on the current status. ON button OFF button Status display Operating groups Groups can only consist of receivers of the same type. Just like receivers, groups can be assigned to rooms. 1. Press the button in order to open the "My house"...

  • Page 35: Additional Configuration And Operation Options

    Our richly illustrated Assembly and Operating Instructions offer detailed information on the full range of available functions, their settings and operator controls and show you how to optimise the configuration of your CentralControl. To download these instruc- tions, please go to our homepage: http://www.becker-antriebe.net/centralcontrol/.

  • Page 36: Changing Batteries

    Changing batteries Dispose of exhausted batteries properly. Only replace batteries with ones of the identical type (LR03; AAA). 1. Open the cover of the battery com- partment. 2. Take out the batteries. 3. Insert the new batteries correctly. 4. Close the cover of the battery com- partment.

  • Page 37: Technical Data

    Technical data Supply voltage 230 V / 50 Hz Degree of protection IP 20 Permissible ambient temperature and air humid- 0°C to +40°C at a relative humidity of between 20% and 80% (non- condensing) Maximum emitted transmission output ≤ 25 mW Radio frequency 868.3 MHz / 2.4 GHz ARM9 454 MHz Memory 128 MB Operating system...

  • Page 38: Simplified Eu Declaration Of Conformity

    Simplified EU declaration of conformity Becker-Antriebe GmbH hereby declares that this radio control system complies with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following web ad- dress: www.becker-antriebe.com/ce Subject to technical changes without notice.
