Installing the
Dye Sublimation
Printing System
Instructions for
Epson B40W Printer
ArTainium UV+ B40W Bulk Ink Feeder
MAXX Heat Press - 28cm x 38cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the B40W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Epson B40W

  • Page 1 Installing the Dye Sublimation Printing System Instructions for Epson B40W Printer ArTainium UV+ B40W Bulk Ink Feeder MAXX Heat Press - 28cm x 38cm...
  • Page 2: Table Of Contents

    Index Page Contents Contact Information Unpacking and Preparing the Printer Unpacking the bulk ink feeder Installing the bulk ink feeder Installing the bulk ink feeder cont. Installing the bulk ink feeder cont. Installing the bulk ink feeder cont and Additional Supporting Notes Installing the Printer Driver Installing the Printer Driver cont.
  • Page 3 Thank You and Welcome Firstly, Thank you for purchasing your Dye Sublimation printing system from ISub (Education) Limited and we welcome you to the growing number of schools that have chosen to work with our company. We are a small, dedicated team of supportive staff, and our aim is to help you introduce or expand the use of Dye Sublimation within your school –...
  • Page 4: Unpacking And Preparing The Printer

    Unpacking and Preparing the Printer Open the printer box and remove the items in the top of the box. Retain these parts, but all the other parts are not required Remove the printer from the box and remove any shipping packaging from the printer.
  • Page 5: Unpacking The Bulk Ink Feeder

    Unpacking the Bulk Ink Feeder System & Installing. Due to the fact that each printer model has its own model of bulk ink feeder, the installation instructions do vary. The bulk ink feeder comes with specific installation instructions contained in the installation instructions booklet supplied with your bulk ink feeding unit, we are also supplying some more comprehensive instructions below.
  • Page 6 5. Remove the 4 small rubber bungs. Use a tissue to 6. Using the long needle attachment on the remove any ink from the rubber bungs and place 10ml syringe, draw any ink out of the them into the small plastic bag in step 4. centre air chamber (through the small hole).
  • Page 7 11. Remove the hinge clip (1) by pulling it towards the 12. Now remove the print head lid. right, away from the lid hinge spindle (2). 13. Manually push the print head to the far left and 14. Place the cartridges into the cartridge housing feed the cartridges and tubes as shown.
  • Page 8 17. Take the small tube support and remove the backing 18. Plug in the mains power cable and turn on the tape and attach it to the printer housing as shown. Ensure printer. The printer will go through its initial ink fill before that all slack / excess is pulled through this bracket so that your system is ready for use.
  • Page 9: Installing The Bulk Ink Feeder

    Do not worry if you see a small amount of air in the tubes when you first install the system. This will quickly find its way to the top of the cartridges during the initial head charge. ** This tiny amount of air in no way impedes ** ** the full working order of the system.
  • Page 10: Installing The Printer Driver

    Installing the Printer Driver on your PC To complete this process, you may require an Administrators log on for your PC ** ** Please consult your IT department for specific information ** Locate the CD containing the printer driver, the CD was supplied with your printer.
  • Page 11 9. Once the installation is completed you will see this 10. You are now given the option to register the confirmation screen. Click Finish product with Epson. To skip this section click cancel. Important: You now need to follow the steps to install the ICC profile. The ICC profile ensures correct colour output on your print outs.
  • Page 12: Installing The Icc Colour Profile

    Installing the ICC Colour Profile Locate the following CD and place in the CD drive of the PC that will run the Dye Sublimation printer. Note: You may need someone from IT to give you Administrator rights to be able to install software. Browse the CD’s contents and locate the following folder.
  • Page 13: Configuring The Printer Driver

    Configuring the Printer Driver on your PC 1. Browse to the CD 2. Locate and double click on this folder. Open this PDF file and follow the instructions to configure the printer driver. Important: Failure to complete this section will result in incorrect colours on your print outs.
  • Page 14: Performing A Head Clean

    Performing a Head Clean. Note: Instructions may differ based on operating system or printer driver versions installed. Occasionally a printer will not print all the colours correctly due to a blocked ink nozzle on the inkjet printing head. There can be a number of reasons for this, including the printer being left for a long time without running any prints or the printer being in a dusty / dirty environment or just simple daily use.
  • Page 15: Installing The Heat Press

    Installing the Heat Press ** You will need assistance to complete this section. The press requires two people to remove it from the box ** 1. Remove the Heat press from the box. It is secured to the wooden base. Note: We strongly recommend retaining this reinforced box in case the press ever needed to be returned at a later date.
  • Page 16 Setting the Temperature Locate the LED Display. Press the mode select button located in the center of the control panel. The SET) and (TEMP) lights located next to the display will illuminate indicating you are in the adjust temperature mode. Next, press the (-) button located to the left of the mode select button to lower the temperature setting, or press the (+) button...
