Fanaway LED EVO1 Installation, Operation, Maintenance And Warranty Information
Retracting blade ceiling fan and light
Hide thumbs
Also See for LED EVO1:
- Installation operation & maintenance (12 pages) ,
- Installation instructions manual (68 pages) ,
- Installation instructions manual (24 pages)
Subscribe to Our Youtube Channel
Related Manuals for Fanaway LED EVO1
Summary of Contents for Fanaway LED EVO1
- Page 1 FANAWAY LED EVO1 Retracting Blade Ceiling Fan and Light INSTALLATION OPERATION MAINTENANCE WARRANTY INFORMATION CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. VER 1.1...
-
Page 2: Safety Precautions
Fanaway LED EVO1 Installation Instructions THANK YOU FOR YOUR PURCHASE Thank you for purchasing this quality Fanaway product. To ensure correct function and safety, please read and save all instructions before using the product. SAFETY PRECAUTIONS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 3: Before Installation
Fanaway LED EVO1 Installation Instructions BEFORE INSTALLATION Unpack your fan and check contents. You should have the following: Fig. 1 2 | P a g e V e r 1 . 1... -
Page 4: Installing The Fan
Fanaway LED EVO1 Installation Instructions Mounting bracket x 1 Retraction mechanism x 1 Canopy screws x 4 Lamp base x 1 Canopy x 1 LED board x 1 Down rod x 1 Lamp shade x 1 Bolt x 1 Wooden screws x 2 Bolt &... -
Page 5: Hanging The Fan
Fanaway LED EVO1 Installation Instructions ANGLED CEILING INSTALLATION This fan hanging system supports a maximum 15 degree angled ceiling installation. Fig. 3 HANGING THE FAN Installing the down rod Feed the down rod (5) through the canopy (4) and the bolt and pin cover (6). - Page 6 Fanaway LED EVO1 Installation Instructions Connect the upper plug (1) from the driver to the lower socket (1) in the LED board (3). Fig.7 Select the color temperature (3000K or 4000K) by sliding the switch (2). Connect the upper connector from the motor to the lower connector (1) from the driver. Fig.8 Finally install the lamp shade to the lamp base by turning it clockwise (No.13 –...
- Page 7 Fanaway LED EVO1 Installation Instructions ELECTRICAL WIRING DIRAGRAM PREPARE AND COMPLETE THE ELECTRICAL WIRING --- WIRING DIAGRAM (FIG. 9) WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A LICENSED ELECTRICIAN. NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED WIRING.
- Page 8 Fanaway LED EVO1 Installation Instructions USE WITH REMOTE WIRING DIAGRAM: (REMOTE sold separately) 1/ Remote without plugs Fig. 10 2/ Remote with plugs Fig. 11 7 | P a g e V e r 1 . 1...
-
Page 9: Finish The Installation
Fanaway LED EVO1 Installation Instructions FINISH THE INSTALLATION Connect the female plug (fan motor) and male plug (mounting bracket) together (1 – Fig.12). Slide the canopy (No.3– Fig. 1) onto the mounting bracket using the slotted holes. Align the other 2 holes and then install the 2 other screws. Tighten all four screws firmly. -
Page 10: After Installation
Fanaway LED EVO1 Installation Instructions This is not a product fault and as such is not covered under warranty. NOTE: Some dimmers have a minimum load of 20W. Before turning on the LED downlight, ensure the dimmer position is on the maximum setting. -
Page 11: Technical Information
Fanaway LED EVO1 Installation Instructions CARE AND CLEANING Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint free cloth to avoid scratching the paint finish. Please turn off electricity power when you do so.
